- Page 1 WKP120 Series 1U Rackmount KVM Switch USER MANUAL www.i-techcompany.com Phone 888-483-2418 Fax 510-372-2736 sales@i-techcompany.com Rev 1.0...
-
Page 2: Table Of Contents
TABLE OF CONTENTS INTRODUCTION……………….……………………………………..2 FEATURES…………...……………………………………………….2 PACKAGE CONTENTS……………...…………..……………………3 TECHNICAL SPECIFICATIONS………..…………………………….4 LCD Monitor SPECIFICATIONS………..…………………………….4 SYSTEM REQUIREMENT…………………………………………..6 CABLE DIAGRAMS………………………………………………….6 INSTALLATION………………………………………………………7 LCD MONITOR OSD Setting……………………………………9 Touch Pad…………………………........10 KVM Switch……………………….……………………………………11 HOT PLUG……………………………………………………………16 TROUBLESHOOTING………………………..…………………….16 ACCESSORIES……………………………………………………...17 CERTIFICATES……………………………………………………..18 i-Tech Company, LLC www.i-techcompany.com... -
Page 3: Introduction
The WKP series rackmount KVM is only 1U -- 4 in 1 control center (KEYBOARD, LCD,Touchpad and KVM). The WKP120 series KVM is only 1U Four in one control center (KEYBOARD, LCD,MOUSE and KVM). The Displays are 20” TFT LCD Panel Resolution is support 1600x1200(Analog VGA Input). -
Page 4: Package Contents
Model No.: WKP120-16e (16 port Slim Rack Mount KVM Switch) 16 port PS2 Control Center 1 PCS User’s manual 1 PCS AC to DC Power Adapter 1 PCS Rack Mount Kit 1 SET CB-K15P Cable(options) 0 SET CB-K15UP Cable(options) 0 SET i-Tech Company, LLC www.i-techcompany.com... -
Page 5: Technical Specifications
MAX PC Connection Housing Metal Power in DC 12V 4A (with one AC to DC power Adapter) 0~50℃ Operation Temperature -20 ~ 60℃ Storage Temperature Humidity 10~90%, Non-Condensing Size 19” Rack Mount / 1U 19” Rack Mount/ 1U i-Tech Company, LLC www.i-techcompany.com... -
Page 6: Lcd Monitor Specifications
0~50℃ Operation Temperature -20 ~ 60℃ Storage Temperature Humidity 8~95% Cable Diagrams PC Port Special Cable: HDB15 pin Male to 15 pin male to one HDDB 15 pin and Mini Din 6 pin special cables ------------ i-Tech Company, LLC www.i-techcompany.com... -
Page 7: Installation
Rack Mount Accessories shows how to one personal to Easy-installation Kit for WKP series rackmount KVM with standard 19-inch cabinet. Step 1: Figure 1: Attaching left and right easy-installation mounting rails to inside of the rack Step 2: i-Tech Company, LLC www.i-techcompany.com... - Page 8 Figure 2: Remove screws Step 3: Figure 3: take WKP series rackmount KVM slide-in rack mount bracket Step 4: Figure 4: screw–in hold WKP series rackmount KVM in left/right position i-Tech Company, LLC www.i-techcompany.com...
-
Page 9: Lcd Monitor Osd Setting
OSD V.Pos c. OSD Timer d. Back 5. Language a. English b. Francais c. Deutsch d. Espanol e. 繁體中文 f. 简体中文 g. 日本語 6. Misc a. Signal Source b. Reset c. Factory Mode d. Back 7. Exit i-Tech Company, LLC www.i-techcompany.com... -
Page 10: Touch Pad
Click/Select. for example: Content Menu, Run, Zoom in ...etc. 3 Finger (Right Button) It’s same as the right button of mouse. And it could be setup as the function as selected. for example: Click/Select, Content Menu, Run ...etc. i-Tech Company, LLC www.i-techcompany.com... -
Page 11: Kvm Switch
Front panel, hot-key, and full-function OSD menu for PC selection Cascadable to expand the connected PCs Keyboard/Video Monitor/Mouse signal RESET function Automatic KVM type detection for optimum setup Auto Scan monitoring function Integrated HD15 3-in-1 KVM cable, easy connect and save space i-Tech Company, LLC www.i-techcompany.com... - Page 12 (4), and connect KVM cable CB-K15P-xxx, plug HDB-15 end to a selected switch channel and the other end of the cable to the second-tier’s user console – keyboard, mouse, and monitor ports and then plug the adapter into the switch. Then follow step (3) and (4) to connect PCs. i-Tech Company, LLC www.i-techcompany.com...
- Page 13 B. Auto Scan: Press <Scroll Lock>+<Scroll Lock>+<F4> to automatically scan power-on computers. You may change scan rate by go to the OSD screen and press < > to change scan interval from 1-255 secs. Scroll Scroll = Auto scan Lock Lock i-Tech Company, LLC www.i-techcompany.com...
- Page 14 “ ” to indicate a switch, you may press <Enter> to go to second-tier switch to select its connected PCs. You can press <Esc> to leave OSD menu. Scroll Scroll = To activate OSD menu Lock Lock i-Tech Company, LLC www.i-techcompany.com...
- Page 15 By not entering any character, you can cancel the password or enter new password to activate password protect. Entering Password E. F3(Scan Set): After you activate OSD function, you can use <↑> or <↓> to move to preferred i-Tech Company, LLC www.i-techcompany.com...
- Page 16 C. The direct vendor also reserves the right to revise or update the product or documentation without obligation to notify any user of such revisions or updates. For further information, please contact your direct vendor. i-Tech Company, LLC www.i-techcompany.com...
-
Page 17: Hot Plug
Don’t press any keys on the keyboard while the selected computer is booting up. Otherwise, it might cause the keyboard error or keyboard is not detected at PC side. The computer boot up fine, but keyboard doesn’t work Make sure the keyboard works when directly plugged into the computer. i-Tech Company, LLC www.i-techcompany.com... -
Page 18: Accessories
If forgetting the “ password ” you typed, please contact your supplier. Accessories HDDB15 Male to DB15 Male + Mini Din*2 CDB-6-PS2--- PS/2 CDB-6-PS2-USB--- USB+PS/2 Ordering information: xxx = 180:180cm cable 300:300cm cable 500:500cm cable 1000:10M cable 1500:15M cable 2000:20M cable 3000:30M cable i-Tech Company, LLC www.i-techcompany.com... - Page 19 (1) This device may not cause harmful interference (2) This device must accept any interference received. Including interference that may cause undesired operation. CE – Certificate This equipment is in compliance with the requirements of the following regulations: EN 55 022: CLASS B i-Tech Company, LLC www.i-techcompany.com...
