Cooper Lighting Cambria 920 Specification Sheet

SAMPLE NUMBER: 920-50MR16-12-BK
MODEL
920 36" hook arm & mounting plate
14-3/8"
[365mm]
4-5/8"
[117mm]
ø2-1/4"
[57mm]
SAMPLE NUMBER: 922-50MR16-12-BK
MODEL
922 14-3/8" straight arm &
mounting plate
922-CRS 33-1/16" arm, center rear
swivel & mounting plate
SAMPLE NUMBER: 403-50T4-12-BK-HA24
MODEL
403 Mini-flood with 1/2" NPS
adjustable stem
Note: See "Accessories" section for Low Voltage Cable & Transformers, Mounting Accessories, Glare Shields, Lenses, Louvers, Color Filters and Lamps.
SOURCE VOLTS
Halogen
50MR16 50W / MR16 / GU5.3 12
12V remote transformer required - not included
Lamp not included
Mounting canopy w/ screws included
4-1/4"
[108mm]
4-5/8"
[117mm]
922
ø2-1/4"
[57mm]
SOURCE VOLTS
Halogen
50MR16 50W / MR16 / GU5.3 12
12V remote transformer required - not included
Lamp not included
Mounting canopy w/ screws included
SOURCE VOLTS
Halogen
50T4 50W / T4 / GY6.35 12
12V remote transformer required - not included
Lamp not included
FINISH OPTIONS
Painted
BK Black HA24 24" hook arm in lieu
BZ Bronze of standard 36" arm
CS City silver HA30 30" hook arm in lieu
VE Verde of standard 36" arm
WT White
33-1/16"
[840mm]
[108mm]
922-CRS
OPTIONS
FINISH
Painted
BK Black SA24 24" straight arm in
BZ Bronze lieu of standard
CS City silver arm
SA30 30" straight arm in
VE Verde
WT White lieu of standard
arm
SA36 36" straight arm in
lieu of standard
arm
FINISH OPTIONS
Painted
BK Black HA24 24" hook arm
BZ Bronze HA30 30" hook arm
CS City silver HA36 36" hook arm
VE Verde SA24 24" straight arm
WT White SA30 30" straight arm
SA36 36" straight arm
`
LUMIERE
CAMBRIA 920
MR16 Halogen
Low Voltage (12V)
FEATURES
• Includes 36" hook arm & mounting plate
• Machined aluminum construction
• Stainless steel hardware
• S.P.S. Siphon Protection System
• Holds up to 3 optical accessories
• UL / cUL listed
• Three (3) year warranty
4-1/4"
CAMBRIA 922
MR16 Halogen
Low Voltage (12V)
FEATURES
• Includes straight arm & mounting plate
• Machined aluminum construction
• Stainless steel hardware
• S.P.S. Siphon Protection System
• Holds up to 3 optical accessories
• UL / cUL listed
• Three (3) year warranty
Shown with Glare
Shield accessory
(order separately).
CARMEL 403
Low Voltage (12V)
FEATURES
• Use with or without optional mounting
arms
• 200° tilt, 360° rotation
• Die-cast housing, machined stem
• Stainless steel hardware
• S.P.S. Siphon Protection System
• UL / cUL listed
• Three (3) year warranty
COOPER LIGHTING
®
50W (max)
50W (max)
50W (max)
T4 Halogen
