Cooper Lighting Neo-Ray 93-DIP Specification Sheet

NEO-RAY ™
OMNI
93-DIP
D I R E C T- I N D I R E C T
• High efficiency 50/ 50 light
distribution.
• Wide direct and indirect light
distribution for 1.8 to 1
spacing to mounting ratio.
• Parabolic louver designed
for continuous unbroken
appearance.
• Satin low glare louver finish.
• Die formed steel housing,
nominal lengths – 3', 4', 6'
and 8'.
718
COOPER LIGHTING
3-3/8"
[86mm]
10-3/8" [264mm]
Construction: Formed 20-gauge cold rolled steel
with internal structural bracing. Nominal 3', 4', 6' or
8' illuminated sections.
Shielding: Pearlescent parabolic baffle.
Electrical: 120, 277, 347 or Universal Voltage
electronic ballast. Luminaires and electrical
components certified to UL and CUL standards.
Finish: Durable, low gloss, white, powder coated
acrylic finish.
Mounting: Pendant: Single stem (standard); single
cable; single swivel stem (EQ). Canopy: 5" diameter
cover (standard).
R O W C O N F I G U R AT I O N
NOTES: For complete product data, refer to the Neo-Ray Specification Binder. Specifications and dimensions subject to change without notice. Products may be
modified for use in international markets. Please contact your Cooper Lighting Sales Representative for availability and ordering information.
ORDERING INFORMATION:
Sample number: 93-DIP-2T8-ST56-1EB-SI-S79
Series
93=Omni
18"
[457mm]
Light Output
MIN.
DIP=Direct Indirect Pendant
Number of Lamps
2=2 Lamps 3=3 Lamps
Lamp Type
T8
Pendant Type
ST=Single Stem
Run Length
Overall Nominal Run Length__ft. (Any combination of 8', 6', 4' and 3'
sections)
1
Voltage
1=120V 2=277V
Ballast
EB=Electronic Ballast (Standard)
Switching
SI=Single Switching
Emergency
EM=Emergency Pack (Consult Factory)
Fusing
GLR GMF
Shielding
S79=Semi-Specular Aluminum Parabolic Baffle
1 Due to various constraints, some options may not be combined with others.
2 Available with 7° or earthquake 45° swivel canopy assembly.
(per cross section) (not included)
2 SC=Single Cable
3=347V U=Universal
DB=Dimming Ballast
DU=Dual Switching
