COOPER LIGHTING - SURE-LITES
6V, 12V METAL
HEAD REMOTES
S i n g l e a n d D o u b l e
R e m o t e H e a d s
6V, 12V
WEATHERPROOF
METAL HEAD
REMOTES
S i n g l e a n d D o u b l e
R e m o t e H e a d s
626
COOPER LIGHTING
D E S C R I P T I O N
Lamp housing is made of
corrosion resistant 22 gauge die
formed spun aluminum with a
powder coat finish. Die cast
aluminum swivel assembly allows
80° adjustment from vertical with
358° rotation. Stainless steel
mounting plate mounts flush on
wall or ceiling and is designed for
installation on standard electrical
box. (Single head remotes are
supplied with single gang plate,
double head remotes are supplied
with three gang plate). UL 924
Listed, CSA Certified.
D E S C R I P T I O N
Designed to perform in wet
locations. Lamp housing is
made of corrosion resistant 22
gauge die formed spun
aluminum with a powder coat
finish and a die cast aluminum,
gasketed mounting plate.
Sealed swivel and coated lamp
terminals resist oil, water and
dust. Available in standard
industrial white finish-specify
color when ordering; other
finishes available. Heads
adjust 80° from vertical with
358° rotation. Supplied
complete with a 5" diameter
die cast, grey finished,
gasketed mounting plate. UL
924 Listed, CSA Certified. City
of Chicago Code (see catalog
numbers with*), UL Wet
Location Listed.
Catalog
Notes:
WH – White (standard finish),
GY – Grey,
BK – Black
* Meets City of Chicago Code
(1) Consult your Cooper Lighting
Representative.
®
O R D E R I N G I N F O R M AT I O N
Lamp Housing +
Mounting Plate
Catalog No. Finish
6 Volt Single Metal Head Remotes
6T6MHWH White
6T12MHWH White
6X7MHWH White
6 Volt Double Metal Head Remotes
6T6DMHWH White
6T12DMHWH White
12 Volt Single Metal Head Remotes
12T12MHWH White
12T50MHWH White
12 Volt Double Metal Head Remotes
12T12DMHWH White
12T50DMHWH White
Alternate Lamps (1)
Other Finishes (1)
O R D E R I N G I N F O R M AT I O N
6 Volt Single Metal Weatherproof
Catalog Heads Lamp Type
6X7WMHWH One Incandescent - Sealed Beam
6X8WMHWH One Incandescent - Sealed Beam
6X12WMHWH One Incandescent - Sealed Beam
6X18WMHWH One Incandescent - Sealed Beam
6X25WMHWH* One Incandescent - Sealed Beam
6T6WMHWH One Halogen - Sealed Beam
6T8WMHWH One Halogen - Sealed Beam
6T10WMHWH One Halogen - Sealed Beam
6T12WMHWH* One Halogen - Sealed Beam
6T20WMHWH* One Halogen - Sealed Beam
6XW54WMHWH One Wedge Base - Incandescent
6XW7WMHWH One Wedge Base - Incandescent
6XW9WMHWH One Wedge Base - Incandescent
12 Volt Single Metal Weatherproof
Catalog Heads Lamp Type
12X12WMHWH One Incandescent - Sealed Beam
12X18WMHWH One Incandescent - Sealed Beam
12X25WMHWH* One Incandescent - Sealed Beam
12X30WMHWH* One Incandescent - Sealed Beam
12T8WMHWH One Halogen - Sealed Beam
12T12WMHWH* One Halogen - Sealed Beam
12T37WMHWH* One Halogen - Sealed Beam
12T50WMHWH* One Halogen - Sealed Beam
12XW9WMHWH One Wedge Base - Incandescent
12XW12WMHWH One Wedge Base - Incandescent
6 Volt Double Metal Weatherproof
Catalog Heads Lamp Type
6X7DWMHWH Two Incandescent - Sealed Beam
6X8DWMHWH Two Incandescent - Sealed Beam
6X12DWMHWH Two Incandescent - Sealed Beam
6X18DWMHWH Two Incandescent - Sealed Beam
6X25DWMHWH* Two Incandescent - Sealed Beam
6T6DWMHWH Two Halogen - Sealed Beam
6T8DWMHWH Two Halogen - Sealed Beam
6T10DWMHWH Two Halogen - Sealed Beam
6T12DWMHWH* Two Halogen - Sealed Beam
6T20DWMHWH* Two Halogen - Sealed Beam
6XW54DWMHWH Two Wedge Base - Incandescent
6XW7DWMHWH Two Wedge Base - Incandescent
6XW9DWMHWH Two Wedge Base - Incandescent
12 Volt Double Metal Weatherproof
Catalog Heads Lamp Type
12X12DWMHWH Two Incandescent - Sealed Beam
12X18DWMHWH Two Incandescent - Sealed Beam
12X25DWMHWH* Two Incandescent - Sealed Beam
12X30DWMHWH* Two Incandescent - Sealed Beam
12T8DWMHWH Two Halogen - Sealed Beam
12T12DWMHWH* Two Halogen - Sealed Beam
12T37DWMHWH* Two Halogen - Sealed Beam
12T50DWMHWH* Two Halogen - Sealed Beam
12XW9DWMHWH Two Wedge Base - Incandescent
12XW12DWMHWH Two Wedge Base - Incandescent
Lamp Type Volts Watts Lamp No.
Halogen Sealed Beam 6 6
Halogen Sealed Beam 6 12
Incandescent Sealed 6 7.2
Beam
Halogen Sealed Beam 6 6
Halogen Sealed Beam 6 12
Halogen Sealed Beam 12 12
Halogen Sealed Beam 12 50
Halogen Sealed Beam 12 12
Halogen Sealed Beam 12 50
Volts Watts
6 7
6 8
6 12
6 18
6 25
6 6
6 8
6 10
6 12
6 20
6 5.4
6 7.2
6 9
Volts Watts
12 12
12 18
12 25
12 30
12 8
12 12
12 37.5
12 50
12 9
12 12
Volts Watts
6 7
6 8
6 12
6 18
6 25
6 6
6 8
6 10
6 12
6 20
6 5.4
6 7.2
6 9
Volts Watts
12 12
12 18
12 25
12 30
12 8
12 12
12 37.5
12 50
12 9
12 12
029-37
029-15
029-75
029-37
029-15
029-79
029-135
029-79
029-135
Lamp Number
029-75
029-03
029-39
029-13
029-09
029-37
029-14
029-36
029-15
029-18
XW029121
XW02988
XW02984
Lamp Number
029-26
029-19
029-08
029-126
029-16
029-79
029-134
029-135
XW02986
XW029132
Lamp Number
029-75
029-03
029-39
029-19
029-09
029-37
029-14
029-36
029-15
029-18
XW029121
XW02988
XW02984
Lamp Number
029-26
029-19
029-08
029-126
029-16
029-79
029-134
029-135
XW02986
XW029132
