- Page 1 2023 WaveRunner EX/EX SPORT EX DELUXE EX LIMITED OWNER’S/OPERATOR’S MANUAL U.S.A. Edition LIT-18626-13-98 Read this manual carefully before operating this watercraft. F3Y-F8199-16...
- Page 2 WARNING: Operating, servicing and maintaining a recreational marine vessel can expose you to chemicals including engine exhaust, carbon monoxide, phthalates, and lead, which are known to the State of California to cause cancer and birth defects or other reproductive harm. To minimize exposure, avoid breathing exhaust, service your vessel in a well-ventilated area and wear gloves or wash your hands...
- Page 3 A thorough under- service procedures are performed. standing of these simple instructions will help Yamaha will not disclose this data to a third you to obtain maximum enjoyment from your party except in the following cases. In addi- new Yamaha.
- Page 4 Important manual information EJU40401 Because Yamaha has a policy of continuing product improvement, this product may not be exactly as described in this owner’s/oper- ator’s manual. Specifications are subject to change without notice. This manual should be considered a perma-...
-
Page 5: Table Of Contents
Table of contents Steering system........ 32 General and important labels... 1 Cooling water pilot outlet ....33 Identification numbers ....1 Water separator........ 33 Primary Identification (PRI-ID) number..........1 Watercraft operation ...... 34 Hull Identification Number (HIN)..1 Watercraft operation functions ..34 Engine serial number...... - Page 6 Stopping the watercraft ....69 Consumer information ....97 Operating the watercraft in reverse Limited warranty ......97 or neutral (EX SPORT / EX YAMAHA EXTENDED SERVICE DELUXE / EX LIMITED) ....70 (Y.E.S.) ........99 Boarding the watercraft ....71 Starting off........74 Index..........
-
Page 7: General And Important Labels
YAMAHA MOTOR CO.,LTD. ASSEMBLED IN U.S.A. WITH FOREIGN AND DOMESTIC COMPONENTS. from a Yamaha dealer. Also record and keep ASSEMBLÉ EN U.S. AVEC DES COMPOSANTS ÉTRANGERS ET DOMESTIQUES. these ID numbers in a separate place in case your watercraft is stolen. -
Page 8: Emission Control Information
THIS ENGINE CONFORMS TO CALIFORNIA AND U.S. EPA EXHAUST REGULATIONS FOR SI MARINE ENGINES. REFER TO OWNER’S MANUAL FOR MAINTENANCE SPECIFICATIONS AND ADJUSTMENTS. ENGINE FAMILY : DISPLACEMENT : liters MAX POWER : EPA/CA FEL : HC+NOx , CO g/kW-h YAMAHA MOTOR CO.,LTD. -
Page 9: Manufactured Date Label
General and important labels 1 Emission control information label location EJU30441 Star labels This watercraft is labeled with a California Air Resources Board (CARB) star label. See be- low for a description of your particular label. EPA FEL: HC + NOx KNCNPLINEME2 , KYMXPTANKTK2 , KBEMPMDRN003 KYMXPVSSLYM1 EJU44460... - Page 10 General and important labels Two Stars - Very Low Emission Four Stars - Super Ultra Low Emission The two-star label identifies engines that The four-star label identifies engines that meet the Air Resources Board’s Personal meet the Air Resources Board’s Sterndrive Watercraft and Outboard marine engine 2004 and Inboard marine engine 2009 exhaust exhaust emission standards.
-
Page 11: Important Labels
General and important labels EJU30455 Important labels Read the following labels before using this watercraft. If you have any questions, consult a Yamaha dealer. -
Page 12: Warning Labels
General and important labels EJU35914 Warning labels If any of these labels are damaged or missing, contact a Yamaha dealer for replacements. - Page 13 General and important labels F3Y-U415B-00 F3Y-U415B-20 F4E-U41E1-40 F3V-U416A-00 F3V-U416A-20...
- Page 14 General and important labels EX SPORT F3K-U41D5-20...
-
Page 15: Other Labels
General and important labels EJU44221 Other labels RATED PERSON CAPACITY:3 MAXIMUM LOAD:225 kg (496 lb) YAMAHA F3Y-U41G1-20 F3Y-U41G1-30 F0V-U41F5-01 F1B-U41F5-01... - Page 16 General and important labels F3Y-U418E-40 F3Y-U418E-50 XXX-XXX XXX-XXX XXX-XXX XXX-XXX NEOPRENE...
-
Page 17: Safety Information
Safety information EJU30675 EJU30733 Limitations on who may The safe use and operation of this water- operate the watercraft craft is dependent upon the use of proper Make sure that the operator is 16 years of riding techniques, as well as upon the age or older and has taken a boater safety common sense, good judgment, and ex- course. -
Page 18: Cruising Limitations
Safety information the left handlebar grip can be used to EJU44481 Cruising limitations change the direction of the jet thrust so that Scan constantly for people, objects, and the watercraft moves in reverse or is in neu- other watercraft. Be alert for conditions tral. -
Page 19: Operation Requirements
Safety information nearby. If you operate further than swim- EJU43123 Operation requirements ming distance from shore, you should be All riders must wear a personal flotation de- accompanied by another boat or water- vice (PFD) that is approved by the appro- craft, but make sure you stay a safe dis- priate authorities and is suitable for tance away. - Page 20 Safety information in certain kinds of accidents and that it should hold on firmly, either to the person could injure you in others. in front of them or to the handgrip provid- A helmet is designed to provide some head protection.
- Page 21 Safety information Scan carefully for swimmers and stay away from swimming areas. Swimmers are hard to see and you could accidentally hit some- one in the water. Avoid being hit by another boat. You should always take the responsibility to watch for traffic;...
-
Page 22: Recommended Equipment
mirror can also be used as an emergency strong magnetic force near the throttle le- signal. Contact a Yamaha dealer or the ver or RiDE lever (EX DELUXE / EX U.S. Coast Guard for more information. LIMITED). The electronic throttle mecha-... -
Page 23: Watercraft Characteristics
(paralysis), facial injuries, and broken decreasing ability to steer without throttle. legs, ankles, and other bones. You could This model is equipped with the Yamaha also damage the shift mechanism. Engine Management System (YEMS) that EX SPORT: Reverse can be used to slow ... -
Page 24: Wakeboarding And Water-Skiing
Safety information craft. Make sure that there are no obstacles EJU30947 Wakeboarding and water- or people behind you before shifting into skiing reverse. You can use the watercraft for wakeboarding Keep away from the intake grate while the or water-skiing if it has the seating capacity to engine is on. - Page 25 Safety information Normal swimwear does not adequately er’s or water-skier’s ability, as well as water protect against forceful water entry into the and weather conditions. rectum or vagina. The person being pulled When preparing to pull a wakeboarder or should wear a wetsuit bottom or clothing water-skier, operate the watercraft at the that provides equivalent protection.
-
Page 26: Rules Of The Road
EJU30962 Rules of the Road The vessel which does not have the right-of- Your Yamaha watercraft is legally consid- way has the duty to take positive and timely ered a powerboat. Operation of the water- action to stay out of the way of the stand-on craft must be in accordance with the rules vessel. - Page 27 Safety information Meeting Overtaking If you are meeting another power-driven ves- If you are passing another vessel, you are the sel head on, and are close enough to run the give-way vessel. This means that the other risk of collision, neither of you has the right- vessel is expected to maintain its course and of-way.
- Page 28 Safety information the International Rules. Vessels with trolling state. The Uniform State Waterway Marking System has been devised for these waters. lines are not considered fishing vessels. Fish- ing vessels have the right-of-way regardless This system uses buoys and signs with dis- of position.
- Page 29 Safety information Remember, markings may vary by geograph- ic location. Always consult local boating au- thorities before riding your watercraft in unfamiliar waters.
-
Page 30: To Get More Boating Safety Information
NASBLA-ap- proved courses. Yamaha is the watercraft industry’s leading manufacturer to build awareness and sup- port for boating education. In 1997, Yamaha launched its GET W.E.T. (Watercraft Educa- tion and Training) initiative and has since... -
Page 31: Enjoy Your Watercraft Responsibly
Safety information When you ride responsibly, with respect and EJU30992 Enjoy your watercraft courtesy for others, you help ensure that our responsibly waterways stay open for the enjoyment of a You share the areas you enjoy when riding variety of recreational opportunities. your watercraft with others and with nature. -
Page 32: Description
The left side of the watercraft when facing forward. Bilge water Water that has collected in the engine compartment. Yamaha Engine Management System (YEMS) YEMS is an integrated, computerized management system that controls and adjusts ignition timing, fuel injection, engine diagnostics, and the off-throttle steering (OTS) system. -
Page 33: Location Of Main Components
Description EJU31012 Location of main components Exterior 1 Hood 9 Reboarding grip (page 44) 2 Handlebar 10 Sponson 3 Footwell 11 Gunwale 4 Seat (page 43) 12 Cooling water pilot outlet (page 33) 5 Pull-up cleat (EX LIMITED) (page 45) 13 Bow eye (page 44) 6 Boarding platform 7 Fuel filler cap (page 48) - Page 34 Description 1 Cleat (page 45) 2 Reboarding step (EX SPORT / EX DELUXE / EX LIMITED) (page 44) 3 Stern eye (page 45) 4 Stern drain plug (page 52) 5 Intake grate 6 Ride plate 7 Jet thrust nozzle 8 Reverse gate (EX SPORT / EX DELUXE / EX LIMITED) (page 34)
- Page 35 Description EX DELUXE / EX LIMITED EX / EX SPORT 1 RiDE lever (EX DELUXE / EX LIMITED) (pa- ge 34) 2 Start switch (page 31) 3 Engine shut-off switch (page 31) 4 Rearview mirror (EX SPORT / EX DELUXE / EX LIMITED) 5 Clip (page 31) 6 Throttle lever (page 32)
- Page 36 Description Engine compartment 1 Water separator (page 33) 9 Spark plug/Ignition coil 2 Fuel tank 10 Fire extinguisher holder (page 47) 3 Air filter case 11 Seat storage compartment (page 47) 4 Flushing hose connector (page 78) 5 Oil tank filler cap/Dipstick (page 50) 6 Oil tank 7 Battery (page 58) 8 Fuse box...
-
Page 37: Control Function Operation
Control function operation EJU31027 Watercraft control functions EJU31154 Engine stop switch “ ” The engine stop switch (red button) stops the engine when the switch is pushed. EJU44350 Start switch “ ” ECJ01311 Do not run the engine over 4000 r/min on land. -
Page 38: Throttle Lever
Control function operation The engine will not start under any of the fol- lowing conditions: Clip is removed from the engine shut-off switch. Throttle lever is squeezed. Throttle lever is malfunctioning. EX DELUXE / EX LIMITED: RiDE lever is ... -
Page 39: Cooling Water Pilot Outlet
It will take about 60 seconds for the water This model is equipped with the Yamaha En- to reach the outlet after the engine is start- gine Management System (YEMS) that in- cludes an off-throttle steering (OTS) system. -
Page 40: Watercraft Operation
Watercraft operation EJU40014 Watercraft operation functions EJU40522 Reverse system (EX SPORT) EWJ01231 Do not use the reverse function to slow down or stop the watercraft as it could cause you to lose control, be ejected, or impact the handlebars. 1 Reverse gate Make sure that there are no obstacles or ... - Page 41 Watercraft operation squeezed, the reverse gate lowers and de- flects the water jet being discharged from the jet thrust nozzle so that the watercraft moves in reverse or is in neutral. When the throttle le- ver is squeezed, the reverse gate rises and the watercraft moves forward.
- Page 42 Watercraft operation 1 Reverse gate 1 Throttle lever 2 Neutral position 1 Reverse gate 2 Forward position 1 “N” (Neutral position) Although the neutral position helps keep the watercraft from moving even when the en- gine is running, some movement may occur. To shift into forward: (1) Release the RiDE lever.
- Page 43 Watercraft operation (2) Lightly squeeze and release the RiDE le- ver. The “N” (neutral) shift indicator will be displayed. 1 “N” (Neutral position) If the RiDE lever is squeezed continuously, the reverse gate will move to the reverse po- sition.
-
Page 44: Instrument Operation
By switching the display units, the speed can EJU35028 be shown in kilometers per hour “km/h” or Information display miles per hour “MPH”. The information display shows watercraft op- erating conditions. “MPH” is selected as the display unit at the Yamaha factory. - Page 45 Instrument operation To switch the speedometer display units: Start the engine, stop the engine, and then push the engine stop switch 3 times, pushing the switch for 0.4 seconds or more each time, before the multifunction information center turns off. The speedometer display units change.
- Page 46 If the battery voltage has ris- en significantly, “HI” is displayed. If “Lo” or “HI” is displayed, immediately return to shore and have a Yamaha dealer service the water- craft. 1 Hour meter and voltmeter If the engine is stopped after the check en-...
- Page 47 If the oil level is sufficient, cator, and the “WARNING” indicator light have a Yamaha dealer check the watercraft. blink, and the buzzer sounds intermittently for EJU43902 30 seconds.
- Page 48 If the check engine warning is activated, im- mediately reduce the engine speed, return to EJU44691 Check engine warning shore, and have a Yamaha dealer check the If a sensor malfunction or a short circuit is de- engine. tected, the check engine warning indicator and the “WARNING”...
-
Page 49: Equipment Operation
Equipment operation EJU40338 Equipment EJU44600 Seat The seat is removable. Remove the seat to access the fire extin- guisher holder, seat storage compartment, and engine compartment. To remove the seat: (1) Pull the seat latch up, and then lift up the rear of the seat. -
Page 50: Reboarding Grip
Equipment operation 1 Handgrip 1 Reboarding step EJU37383 Reboarding grip The reboarding grip is used when boarding the watercraft from the water. ECJ00743 Use the reboarding step only to board the 1 Reboarding grip watercraft in the water. Do not use the re- EJU34867 boarding step for any other purpose. -
Page 51: Stern Eyes
Equipment operation 1 Bow eye 1 Cleat EJU34883 EJU34895 Stern eyes Pull-up cleats (EX LIMITED) The stern eyes are used to attach a rope to The pull-up cleats are used to attach a rope the watercraft when transporting or mooring to the watercraft when mooring it. - Page 52 Equipment operation Make sure that the storage compartments are closed securely before operating the wa- tercraft. EJU44660 Bow storage compartment The bow storage compartment is located un- der the hood. To open the bow storage compartment: Unhook the hood latches, and then lift up the rear of the hood.
-
Page 53: Fire Extinguisher Holder
Equipment operation Glove compartment: Capacity: 14.0 L (3.7 US gal, 3.1 Imp.gal) Load limit: 3.0 kg (7 lb) To close the glove compartment: Push the lid down to securely lock it in place. EJU44501 Fire extinguisher holder The fire extinguisher holder is located under the seat. -
Page 54: Operation And Handling Requirements
10% ethanol can cause fuel system damage tremely flammable. To avoid fires and or engine performance problems. explosions and to reduce the risk of in- Yamaha does not recommend gasohol con- jury when refueling, follow these in- taining methanol because it can cause fuel structions. - Page 55 Operation and handling requirements 1 Fuel filler cap 1 Top of the fuel tank 2 Approximately 50 mm (2 in) from top of the (5) Slowly add fuel to the fuel tank. fuel tank Fuel tank capacity: 50 L (13.2 US gal, 11.0 Imp.gal) 1 Top of the fuel tank 2 Approximately 50 mm (2 in) from top of the fuel tank...
-
Page 56: Engine Oil Requirements
API SG, SH, SJ, SL water in the engine oil can cause serious engine damage. Why Yamalube YAMALUBE oil is a Genuine YAMAHA Part born of the engineers’ passion and belief that When checking the engine oil level on land, ... - Page 57 1 Dipstick 2 Maximum level mark 3 Minimum level mark (8) If the engine oil level is significantly above the maximum level mark, consult a Yamaha dealer. If the engine oil level is...
-
Page 58: Draining The Bilge Water
Operation and handling requirements as dirt or sand. Otherwise, the stern EJU40022 Draining the bilge water drain plugs could be damaged, allow- ECJ01302 ing water to enter the engine compart- ment. Check the O-rings on the stern Do not run the engine at full throttle when drain plugs and make sure that the bilge water remains in the engine com- plugs are tightened securely before... -
Page 59: Transporting On A Trailer
Operation and handling requirements gine has been restarted. Bilge water in the EJU33465 Transporting on a trailer engine compartment can splash into the When transporting the watercraft on a trailer, engine, which can result in severe dam- secure the tie downs to the trailer through the age. -
Page 60: First-Time Operation
First-time operation EJU32787 Engine break-in ECJ00432 Failure to perform the engine break-in could result in reduced engine life or even severe engine damage. The engine break-in is essential to allow the various components of the engine to wear and polish themselves to the correct operat- ing clearances. -
Page 61: Pre-Operation Checks
Do not operate the watercraft if you find any prob- lem. If a problem cannot be corrected by the procedures provided in this manual, have the watercraft inspected by a Yamaha dealer. EJU41237 Pre-operation checklist Before using this watercraft, be sure to perform the checks in the following checklist. - Page 62 Pre-operation checks ITEM ROUTINE PAGE Check the stern drain plugs for damage and foreign Stern drain plugs material and check that they are securely installed. Hood Check that the hood is securely closed. Seat Check that the seat is securely installed. POST-LAUNCH CHECKS ITEM ROUTINE...
-
Page 63: Pre-Operation Check Points
Pre-operation checks EJU32282 Pre-operation check points EJU44551 Pre-launch checks Perform the pre-launch checks in the pre-op- eration checklist while the watercraft is on land. To perform the pre-launch checks: (1) Remove the seat, seat storage compart- ment, and fire extinguisher holder. (See page 43 for seat removal and installation EJU34215 procedures, page 47 for information on... - Page 64 Pre-operation checks 1 Water separator 1 Dipstick 2 Maximum level mark EJU40182 Engine unit check 3 Minimum level mark Check the exterior of the engine unit for dam- EJU32456 Bilge water check age or other problem. Make sure that no bilge water has collected in EJU41561 Engine oil level check the engine compartment.
- Page 65 Pre-operation checks Make sure that the battery is securely held in place. EJU32614 Steering system checks Turn the handlebars to the right and left sev- eral times to make sure that operation is smooth and unrestricted throughout the whole range, and that the free play is not ex- cessive.
- Page 66 Pre-operation checks out the whole range. Also, make sure that the throttle lever returns automatically to its fully closed (idle) position when released. EJU32666 Engine shut-off cord (lanyard) check Make sure that the engine shut-off cord (lan- yard) is not damaged. If the cord is damaged, replace it.
- Page 67 To check the operation of the switches: with this watercraft. If you do not have one, (1) Push the start switch to make sure that contact a Yamaha dealer or a fire extinguish- the engine starts. er dealer to obtain one meeting the proper (2) As soon as the engine starts running, specifications.
-
Page 68: Post-Launch Checks
Pre-operation checks EJU43221 Jet thrust nozzle and reverse gate check (EX SPORT / EX DELUXE / EX LIMITED) Check the jet thrust nozzle and reverse gate for damage or other problem. EJU44252 Stern drain plug checks Loosen the stern drain plugs and remove them, and then make sure that the plugs and O-rings on the plugs are not damaged and that there is no foreign material on the... - Page 69 Pre-operation checks EJU32715 1 Shift indicator Multifunction information center check 2 “F” (Forward position) Make sure that the multifunction information 3 “N” (Neutral position) center operates properly. (See page 38 for in- 4 “R” (Reverse position) formation on proper operation of the multi- function information center.) EJU40172 Engine idling speed check...
-
Page 70: Operation
Consult a Remember: This watercraft is designed to Yamaha dealer about any control or func- carry the operator and up to 2 passengers. tion that you do not fully understand. Fail-... -
Page 71: Riding Position
Operation jects, and other watercraft. Be alert for EJU32804 Launching the watercraft conditions that limit your visibility or block When launching the watercraft, make sure your vision of others. that there are no obstacles around you. You should grip the handlebars firmly and If the watercraft is launched from a trailer, keep both feet on the floor of the footwell. -
Page 72: Stopping The Engine
Operation that the engine shut-off cord (lanyard) to avoid. A collision could result in severe is attached correctly. If the engine injury or death. [EWJ00602] shut-off cord (lanyard) is not attached correctly, it may not pull free when the operator falls off, allowing the water- craft to continue to run and cause an accident. -
Page 73: Turning The Watercraft
Operation EX DELUXE / EX LIMITED: When the throttle lever is squeezed, the “F” (forward) shift indicator will be displayed and the watercraft will move forward. While the “F” (forward) shift indicator is displayed, the watercraft will move forward at trolling speed even if the throttle lever is in the fully closed (idle) position. - Page 74 Operation the watercraft to slide sideways or spin, throwing the operator and passenger(s) overboard, which could cause an injury. EX DELUXE / EX LIMITED: Take early action to avoid collisions. The RiDE sys- tem is not a braking device for avoiding dangerous situations.
-
Page 75: Stopping The Watercraft
90 m (300 ft) 1 Reverse gate This model is equipped with the Yamaha En- gine Management System (YEMS) that in- cludes an off-throttle steering (OTS) system. EX DELUXE / EX LIMITED: If the RiDE lever is... -
Page 76: Operating The Watercraft In Reverse Or Neutral (Ex Sport / Ex Deluxe / Ex Limited)
Operation EWJ01971 Allow adequate stopping distance. Stay far enough away from others so you can always safely coast to a stop. Take early action to avoid collisions. Re- member, watercraft and other boats do not have brakes. Operate defensively at safe speeds and ... -
Page 77: Boarding The Watercraft
Operation 1 “R” (Reverse position) 1 “N” (Neutral position) Make sure that there are no obstacles or peo- EJU36088 Boarding the watercraft ple behind you before shifting into reverse. EWJ01113 This model is equipped with a function which Be sure the operator and any passengers limits the engine speed in reverse. - Page 78 Operation intake, causing impeller damage and en- gine overheating. [ECJ00473] 60 cm (2 ft) (3) Attach the engine shut-off cord (lanyard) to your left wrist, and then attach the clip to the engine shut-off switch. (4) Grip the handlebars with both hands and EX SPORT / EX DELUXE / EX LIMITED: This place both feet on the floor of the foot- watercraft is equipped with a reboarding...
- Page 79 Operation engine is running, the reverse gate may move down and a person boarding could be pinched. The heavier the total weight of the operator and passenger(s), the more difficult it will be to balance the watercraft. Do not operate the watercraft when the total weight exceeds 225 kg (496 lb) including any cargo.
-
Page 80: Starting Off
Operation (7) Attach the engine shut-off cord (lanyard) to your left wrist, and then attach the clip to the engine shut-off switch. (8) Look in all directions, start the engine, and then start off slowly. EJU33085 Starting off EWJ00714 To avoid collisions: Scan constantly for people, objects, and ... -
Page 81: Capsized Watercraft
Operation on the gunwale with your other hand or EJU33115 Boarding and starting off from a dock your foot. (1) Board the watercraft from the side. (2) Attach the engine shut-off cord (lanyard) to your left wrist, and then attach the clip to the engine shut-off switch. -
Page 82: Beaching And Docking The Watercraft
Operation (4) After reaching land, stop the engine, and EJU44390 Beaching and docking the watercraft then get off the watercraft and pull it up To beach the watercraft (EX / EX on the beach. SPORT): To dock the watercraft (EX / EX SPORT): (1) Make sure that there are no boats, swim- (1) Make sure that there are no boats, swim- mers, or obstacles near the beach. -
Page 83: After Removing The Watercraft From The Water
Operation area, clean the jet intake. (See page 93 for in- formation on the jet intake.) EJU40243 After removing the watercraft from the water ECJ01311 Do not run the engine over 4000 r/min on land. Also, do not run the engine for more than 15 seconds without supplying water, otherwise the engine could overheat. -
Page 84: Care And Storage
Care and storage EJU37148 Post-operation care EWJ00332 Always place the watercraft upright in a horizontal position when storing it, other- wise fuel could leak out into the engine or engine compartment, which could create a fire hazard. After using the watercraft, always take it out 1 Garden hose adapter of the water, clean it, and store it. -
Page 85: Cleaning The Watercraft
Care and storage (2) If the watercraft will be stored for a week or more, rustproof the internal engine components to help prevent corrosion. (See page 82 for information on rust- proofing the internal engine compo- nents.) (3) Rinse the engine and engine compart- ment with a small amount of water. - Page 86 Checking the battery voltage and charging Batteries produce explosive gases. Keep the battery It is recommended to have a Yamaha dealer sparks, flames, cigarettes, etc., well away. check the battery voltage and charge the bat- If using or charging the battery in an en- tery.
-
Page 87: Long-Term Storage
(3) Apply water-resistant grease to the bat- to ensure against deterioration. It is advisable tery terminals. to have the watercraft serviced by a Yamaha dealer prior to storage. Recommended water-resistant grease: However, the following procedures can be YAMALUBE MARINE GREASE performed easily by the owner. -
Page 88: Rustproofing
Care and storage EX SPORT: Shift cable (reverse gate end) and ball joint Disconnect the shift rod from the ball joint be- fore lubricating. EJU44781 Rustproofing Rustproofing the hull, deck, and engine Spray metallic parts of the hull, deck, and en- gine with a rust inhibitor such as Yamalube Silicone Protectant &... - Page 89 Care and storage (3) Release the hooks on the port side of the air filter case, and remove the air filter case cover. 1 Intake opening (5) Place the air filter case cover in its origi- nal position, and then fit the hooks onto the cover.
-
Page 90: Maintenance
The most im- portant points of watercraft inspection and lubrication are explained on the following pa- ges. See a Yamaha dealer for genuine Yamaha re- placement parts and optional accessories designed for your watercraft. Remember, failures that are the result of the... -
Page 91: Periodic Maintenance Chart
Yamaha dealer perform the checks in the following chart. However, maintenance may need to be performed more frequently depending on your operating conditions. If you have any questions, consult a Yamaha dealer. This “√” mark indicates items to be checked and serviced by a Yamaha dealer. Initial Thereafter every... - Page 92 Maintenance Initial Thereafter every 50 hours hours or hours or Item Operation Page or 12 10 hours months months months Check for damage, and √ Air intake hoses — check clamps √ Throttle body Lubricate throttle valve — Check for exhaust leak- √...
-
Page 93: Engine Oil And Oil Filter
Do not run the engine with too much or not enough oil in the engine, otherwise the en- gine could be damaged. It is recommended to have a Yamaha dealer change the engine oil and the engine oil filter. However, if you choose to change the oil and... -
Page 94: Specifications
Specifications EJU45433 Specifications Watercraft capaci- Maximum people on board: 3 person Maximum load capacity: 225 kg (496 lb) Dimensions and 3.13 m (123.2 in) (EX) weight: Length: 3.14 m (123.6 in) (EX SPORT / EX DELUXE/ EX LIMITED) Width: 1.13 m (44.5 in) Height: 1.15 m (45.3 in) 262 kg (578 lb) (EX) - Page 95 Specifications Fuel and oil: Recommended fuel: Regular unleaded gasoline Minimum octane rating (PON): Minimum octane rating (RON): Recommended engine oil: YAMALUBE 4W or 4-stroke motor oil SAE 10W-30, 10W-40, 20W-40, Recommended engine oil type SAE: 20W-50 Recommended engine oil grade API: API SG, SH, SJ, SL Fuel tank total capacity: 50 L (13.2 US gal, 11.0 Imp.gal)
-
Page 96: Trouble Recovery
Troubleshooting If you have any trouble with your watercraft, use the troubleshooting chart to check for the possible cause. If you cannot find the cause, consult a Yamaha dealer. EJU44430 Troubleshooting chart Confirm the possible cause and remedy, and then refer to the applicable page. - Page 97 Fuel Fuel tank empty Refill as soon as pos- larly or stalls sible Stale or contaminat- Have serviced by — Yamaha dealer Fuel tank Water or dirt present Have serviced by — Yamaha dealer Spark plug Fouled or defective Have serviced by —...
- Page 98 Watercraft slow or Cavitation Jet intake clogged Clean loses power Impeller damaged or Have serviced by worn Yamaha dealer Engine over- Engine speed reduc- Clean jet intake and heat warning tion control activated cool engine Oil pressure Engine speed reduc-...
-
Page 99: Emergency Procedures
Trouble recovery EJU34625 Emergency procedures EJU44592 Cleaning the jet intake and impeller EWJ00783 Before attempting to remove weeds or de- bris from the jet intake or impeller area, shut the engine off and remove the clip from the engine shut-off switch. Severe in- jury or death could result from coming in contact with the rotating parts of the jet pump. -
Page 100: Raising The Reverse Gate (Ex Deluxe / Ex Limited)
1 Reverse gate After raising the reverse gate so that the wa- 2 Forward position tercraft can move forward, immediately re- turn to shore and have a Yamaha dealer While the shift rod is disconnected, the re- service the watercraft. -
Page 101: Towing The Watercraft
The towline should be long enough so compartment. Then, have a Yamaha dealer that the watercraft will not collide with service the watercraft as soon as possible. the towing boat when slowing down. - Page 102 (See page 52 for informa- tion on draining the bilge water.) (3) Have the watercraft serviced by a Yamaha dealer as soon as possible. NOTICE: Be sure to have a Yamaha dealer inspect the watercraft. Other- wise, serious engine damage could result.
-
Page 103: Consumer Information
OBTAINING REPAIRS UNDER WARRANTY. During the period of warranty, any authorized Yamaha WaveRunner Watercraft Dealer will, free of charge, repair or replace, at Yamaha’s option, any part adjudged defective by Yamaha due to faulty workmanship or material from the factory. All parts replaced under warranty will become the property of Yamaha Motor Corporation, U.S.A. - Page 104 If you should move after you have purchased your new watercraft, please advise us of your new address by sending a postcard listing your Yamaha model name, engine number, dealer number [or dealer’s name] as it is shown on your warranty card, your name and new mailing address.
-
Page 105: Yamaha Extended Service (Y.e.s.)
This excellent Y.E.S. plan coverage is only available to Yamaha owners like you, and only while your Yamaha is still within the Yamaha Limited Warranty period. So visit your authorized Yamaha dealer to get all the facts. He can show you how easy it is to protect your investment with Yamaha Extended Service. -
Page 106: Index
Index Enjoy your watercraft responsibly.... 25 After removing the watercraft from the Equipment..........43 water............. 77 Approval label of emission control Fire extinguisher check ......61 certificate ..........2 Fire extinguisher holder......47 Fire extinguisher holder checks ....61 Battery care..........79 Flushing the cooling water passages.. - Page 107 Riding position ......... 65 Watercraft control functions..... 31 Rules of the Road ........20 Watercraft operation functions ....34 Rustproofing ..........82 YAMAHA EXTENDED SERVICE Safety equipment check ......61 (Y.E.S.) ..........99 Seat............43 Seat storage compartment ...... 47...
- Page 109 Genuine Yamaha Accessories – Yamaha only offers accessories that meet our high standards for quality and performance. Buy with confidence, knowing your Genuine Yamaha Accessories will fit right and perform right – right out of the box. Yamalube – Take care of your Yamaha with legendary Yamalube oils, lubricants, and care products.
- Page 110 *F3YF8199160080* Printed in U.S.A. August 2022–1.2 × 1 CR...
