Short manual GMK 210

Capacitive moisture measurement caravan and boat

1 Display elements

2 Control elements

2 + 3 together:

Depth switch:

(on the right side)

1: current moisture (%u) or water content (%w)

2: selected material (see chapter 6 respectively 7)

3: Moisture rating (dry, wet)

4: HLD - The measuring value is 'frozen' (hold-key)

1: on/off key

2: sort up

3: hold

sort down Material selection: downwards

Sliding switch up: ca. 10 mm measuring depth (d 10)

Sliding switch down: ca. 25 mm measuring depth (d 25)

Press long:

switch device off;

Press shortly: activation of backlight

Material selection: upwards

press shortly: Value is ‚frozen' ('HLD' in display)

press for 2sec.: Zeroing function

H68.0.02.6HC-05

Need help?

Do you have a question about the Greisinger GMK 210 and is the answer not in the manual?

Page 1 GHM GROUP - Greisinger GHM Messtechnik GmbH | Hans-Sachs-Str. 26 | 93128 Regenstauf | GERMANY Tel.: +49 9402 9383-0 | Fax: +49 9402 9383-33 | info@greisinger.de H68.0.02.6HC-05 Short manual GMK 210 Capacitive moisture measurement caravan and boat 1 Display elements...
Page 2: Zeroing Function
3 Zeroing function press key “hold” for 2 seconds - in the air. Please pay attention not to influence the zeroing function with your hands. The best way to ensure this is shown left. Note: The zeroing function adjusts the zero-point for both 10 mm and 25 mm at the same time.
Page 3: Error And System Messages
5 Hold the Device The water content of the hand has an impact on the measuring value, if the device is held inappropriately. The best results will be obtained if you hold it the way as shown in picture 3. Picture 2: laid down –...
Page 4 8 Wood types table...
Page 5 Abachi d.45 Gum, Sweet d.50 Meranti, White- d.55 Poplar, Black- d.45 Afzelia d.75 Hemlock d.45 Meranti, Yellow- d.55 Redcedar, Western- d.45 Ash, American- d.65 Hickory d.75 Merawan d.70 Rengas d.60 Ash, European- d.65 Iroko d.65 Merbau d.75 Rimu d.50 Ash, Manchurian- d.60 Jarrah d.75...
