Tilt Wall Mount
Instruction Manual
Model: MOUNT VW100T
Email: help@vivo-us.com
Live chat: www.vivo-us.com
Call: 1-800-371-5654
-
Scan the QR code with your mobile device or follow the link
to helpful videos and specifications related to this product.
https://vivo us.com/products/mount vw100t
-
Tools Required:
phillips screwdriver
Package Contents
A (x1)
C (x1)
D (x2)
M A (x4)
-
M B (x4)
-
M6x14
M5x14
M E (x4)
-
M F (x4)
-
M8x30
W A (x6)
-
W B (x6)
-
-
B (x1)
E (x1)
M C (x4)
-
M D (x4)
-
M8x20
M6x30
M G (x8)
-
M H (x4)
-
W C (x6)
-
1
