Laptop Tray & Desk & Desk M Desk Mount Mount
Instruction Manual
Model: STAND- STAND V001L
Email: help@vivo-us.com
Live chat: www.vivo-us.com
Call: 1-800-371-5654
-
Scan the QR code with your mobile device or follow the link to
helpful videos and specifications related to this product.
https: STAND- / /vivo us.com/products/stand v001l
-
Tools Required: STAND-
phillips screwdriver
P ack Mount a ge C ontents
A (x1)
B (x1)
Pole
Clamp
E (x1)
F (x3)
VESA Plate
M5x14 Bolt Bolt
I (x1)
J (x1)
M10 Washer Bolt
Sup p ort Plate
M (x1)
N1 (x1)
Gromme t Base
Wire Clip
Plate
P (x1)
Q (x4 Bolt )
Wre nch
M4 Bolt x 12 Thumb-Bolt Bolt
-
T (x1)
U (x4 Bolt )
Lap top Tray
M4 Bolt x 10 Washer Bolt
-
C (x1)
D (x1)
Clamp Brace
Swive l Arm
G (x2)
H (x1)
M8x12 Bolt
Nut
K (x1)
L (x1)
M10 Washer Washe r
Sp ring Washer Washe r
N2 (x2)
O (x1)
Wire Clip
Alle n Ke y
S (x4 Bolt )
R (x4 Bolt )
M4 Bolt x 30 Washer Bolt
M4 Bolt Sp ace r
V (x4 Bolt )
W-1 1 (x1)
-
W-1 2 (x1)
-
M4 Bolt Nut
Soft Pad
Soft Pad
1
