- Page 1 OVP-H4XL USER MANUAL Version：V1.0 Date：2020.5.26...
-
Page 2: Statement
Statement Without the written permission of the company, any unit or individual may not copy, copy, copy or translate Part or all of this manual. Do not use this manual in any form or in any way (electronic, mechanical, photocopying, recording or other possible ways) to spread or use the product for any commercial or profit-making purpose. -
Page 3: Table Of Contents
Directory Statement................................... 1 Directory.....................................2 INSTRUCTION................................... 3 Safety Notice................................3 About software................................. 3 FUNCTION..................................4 Description..................................4 Features....................................4 Panel instruction................................5 Front panel.................................5 Back panel..................................6 Basic steps..................................7 Menu....................................8 1.1 Menu key operation..............................8 1.2 Initial menu status..............................8 Initial menu status..............................8 Main menu.................................9 Output configuration............................11 Image effect menu.............................. -
Page 4: Instruction
INSTRUCTION Safety Notice There are high voltages in this product, so non-maintenance personnel must not open the case or repair the equipment by yourself to avoid danger. The input voltage range of this product's AC power supply is 100 ~ 240V, 50 / 60Hz, please use the correct power supply. -
Page 5: Function
FUNCTION Description OVP-H4XL dual-picture video controller is a mid-to-high-end video processing equipment developed and produced by our company for the LED large screen display, application in showing and rental, conference room, studio and other markets. This product adopts 4K image processing technology specially designed for small-pitch LED display. -
Page 6: Panel Instruction
All input signal sources and output modes can be quickly and seamlessly switched; With 5 ultra high definition (UHD) digital and analog input interfaces; Support open double pictures and arbitrary layout; Support 3 digital input ports DVI \ HDMI \ DP custom input resolution setting ... -
Page 7: Back Panel
output is black. FUNCTION 区 [LOAD]：fast switch to user mode [SAVE]：fast switch to user save mode [BRIGHT]：fast switch to brightness adjust hot key. [MODE] ：fast switch to system fixed mode menu. [TEXT]：keep the function button [FREEZE]：image freeze hot key IMAGE area [IMG1]- [IMG2]：You can select the opened screen 1 ~ screen 2 window, and the LED light indicates the currently selected window. -
Page 8: Basic Steps
Video input source Extended input port, default is DVI, HDMI or SDI or wireless screen input is optional DVI interface HDMI HDMI Audio input/out put port HDMI audio HDMI video input port built-in AUDIO_IN Analog audio input port AUDIO_OUT Analog audio output port Control interface Network control port USB input port... -
Page 9: Menu
Menu 1.1 Menu key operation The key operation area which includes a knob, a confirmation key [OK], a return key [ ] and a [GUIDE] key. In the initial state of the system, short press [OK] to enter the main menu setting interface. When pressing the return key, the menu system will return to the previous menu until it returns to the initial state. -
Page 10: Main Menu
Input： It displays the input source selection information, including the input source signal format detected by the system. output： The first line: display the actual LED screen size set by the user The second line: display the prompt information Upper right corner：... - Page 11 Input resolution (horizontal width, vertical height, refresh rate) Advance Input hot backup VGA settings (automatic adjustment, horizontal start, vertical start) Timed switching (task 1, task 2, ...) Other settings (image rotation, sound settings, screen projection equipment) Test chart (closed, Figure 1 to Figure 8) Key lock (open, closed) Factory setting (VGA ADC calibration, VGA DDC programming, comment, factory reset, firmware version)
-
Page 12: Output Configuration
Output configuration In the non-menu state, click the [OK] button to enter the main menu, and then select "Output Settings", the following menu will pop up: LED screen size In the non-menu state, click [OK] to enter the main menu, then select "Output Settings", and then select "LED Screen Size"... -
Page 13: Image Effect Menu
LAN output setup In the non-menu state, click [OK] to enter the main menu, then select "Output Settings", and then select "Network Port Output Settings" to enter the network port output settings menu: Note: (1)As mentioned above, when the PC screen control software completes the settings of the “connect card access”... -
Page 14: Image Crop Menu
Brightness: The adjustment range is 0-100, and the default value is 50. Contrast: the adjusting range is 0-100, and the default value is 50. Saturation: the adjustment range is 0-100, and the default value is 50. Sharpness: the adjustment range is 0-10, and the default value is 5. ... -
Page 15: Advance
Capture switch: The input image intercept function is on or off, and the default is off. Capture width: the minimum value is 128, and the maximum value is "the width of the input signal". Capture height: The minimum value is 128, and the maximum value is "the height of the ... - Page 16 The input resolution setting provides users with DVI / HDMI input signal source EDID editing function, and sets the recommended resolution of the input signal source. The WIN7 computer graphics card can automatically read the recommended EDID resolution of the input DVI / HDMI port of the device. Output recommended resolution; after WIN10 input resolution setting is completed, you must manually select "Recommended Resolution"...
- Page 17 VGA setup Select VGA setting in "Advanced Options", then enter the VGA setting menu: Horizontal start: adjustment range 0-300. Vertical start: the adjustment range is 0-300. Note: (1)The actual adjustable range of horizontal start and vertical start is determined by the internal calculation of the system.
- Page 18 task settings are also completed by the PC software;( (3) When the timing switch is turned on and the task is valid, the timing switch can be turned off or on at any time through the LCD menu. Other setup There are three adjustment items in "Other Settings": Image rotation: contains three special effects of "HV mirror", "horizontal mirror"...
-
Page 19: User Mode Save And Recall
Factory reset: Reset to factory default. Firmware version: Used to query the current software and hardware version number, and the factory date. User mode save and recall User mode save Press the front panel shortcut "SAVE" to quickly switch out the user mode save menu: After selecting the save mode, press [OK] to save. -
Page 20: Intelligent Navigation
keys 1 ~ 9 to directly view, and then press "OK" key to directly call. Intelligent navigation Intelligent navigation provides users with a means to quickly debug the splicer when using the splicer for the first time. The LED screen is set up through three simple steps. The software is simple, convenient, and practical. -
Page 21: Faq
This system is a professional device, and the use of certain functions requires the user to have considerable professional knowledge. When users encounter problems, they can try to adjust the machine by themselves. If you still can't solve the problem according to the steps listed below, please do not contact your local distributor or directly contact our after-sales service department. -
Page 22: Specification
Check whether the key lock is turned on on the LCD There is no response to panel screen（start ） ， Presstheknobtoenterthemainmenu,setthekeylock key function operation. inthe"Advanced"menutoclose（close ） 。 Specification Image input port VGA×1 VESA standard：1600×1200@75Hz or belowcompatible HDMI×1 VESA standard ：HDMI 2.0，3840×2160@60Hz or below compatible DVI×1 VESA standard, compatible with HDMI 1.4，1920×1080@60Hz or below... - Page 23 Single network port: horizontal width x vertical height <= 655360 pixels Audio input/output port Audio input×1 3.5mm audio port Audio output×1 3.5mm audio port Complete device specification Input voltage 100-240V~50/60Hz Power ≤50W Working -10℃~45℃ tempearutre Environmental 15%~85% humdity Operation LCD menu, panel keys, LAN, USB, wifi, PC configuration software mode Demension 482.6mm×300mm×66.6mm...
- Page 24 CONTACT US Shanghai ONBON Technology Co.,ltd (Headquarters) Address: 7 Floor, Tower 88, 1199#, North Qinzhou Road, Xuhui District, Shanghai City, China Tel Phone:0086 15921814956 Website: www.onbonbx.com ONBON (Jiangsu) Optoelectronic Industrial Co.,LTD Address: 1299#, Fuchun Jiang Road, Kunshan City, Jiangsu Province, China...
