- Page 1 OVP-M2 User Manual OVP-M2 user manual...
- Page 2 Statement Any companies or privates cannot copy, transcribe or translate part or whole content of this file without our written permission. And cannot use it on any business or benefit filed with any forms. The specifications and information which are mentioned on the file is for reference only, if there’s update, we will not inform you.
-
Page 3: Table Of Contents
CATOLOG Instruction................................2 Characteristics..............................2 Hardware instruction..............................3 Front panel picture............................. 3 Backside panel picture............................4 Connect the device..............................5 Port connection picture............................. 6 MENU INSTRUCTION.............................. 6 Output menu............................... 9 image effect menu............................10 Image crop menu............................. 11 Image layout menu............................12 Mode save menu..............................13 Advanced setting menu.......................... - Page 4 Brief instructions Safety Notes Input voltage is 220V, voltage range is from 100V-240V, please make sure the quality of the power supply of OVP series. Please make sure that all the power supply cables are plugged off when you want to connect or plug off any signal or controlling cables.
-
Page 5: Instruction
Instruction OVP-M2 is a type of high performance video processor .it is specially developed for controlling large full color led display screen ,Using professional video image processing chip, internal 12-bit digital processing, the image is clearer and more colorful. It can be configured with LedshowTV software, convenient to configure multiple format video input parameters. -
Page 6: Hardware Instruction
Cut and Fade function of input signal source Support customized DVI input resolution, as to be the same with LED screen resolution, and to display point to point Support customized output resolution, the maximum width pixel is 3840 and the maximum height ... -
Page 7: Backside Panel Picture
There are total 4 buttons：[BRI]button、[PIP]button、[PART]button、 [MODE]button [BRI]button：brightness adjustment button for output image，change the value by turning the knob clockwise or FUNCTION counterclockwise.short press the [OK]button to save area [PIP]button：PIP menu shortcut button. [PART]button：Interception input image full screen or local display, initial for full screen display, switch local display.，[PART]button light on。... -
Page 8: Connect The Device
SDI port ：SDI Video input port embedded. SDI LOOP port： extend module SDI input loop out. COM port：serial port communication port ,connected with computer port ： Analog audio input/output port, when the output is selected input signal source audio.The input can be external audio, via the sending card to the LED screen. -
Page 9: Port Connection Picture
OVP-M2 uses a LCD screen to display menu system,users can use the Rotating button and panel buttons to adjust the parameters. The flowing will introduce the menu system of OVP-M2 in details according to the button function and the display content of LCD screen Button instruction OVP-M2 have three areas：INPUT、FUNCION、MENU. - Page 10 PIP screen is opened, the PIP screen input signal source can be switched. The system will automatically check the input signal format, if format of the current input signal source is right ,the button lamp always bright, if there is no signal or the format is not supported, button lamp light will flicker.
- Page 11 Title Name of input signal source LED screen Resolution format of input signal Resolution format of input signal source,corresponding to the physical resolution source of LED screen Status area, to show you the status of this machine by many icons. There are 4 icon areas from left to right, and it shows only 3 in original status Status of “PART”...
-
Page 12: Output Menu
Main menu In the initial status,press [OK]button to enter into main screen.the main screen as the follows The main menu includes the following functions: Output setting---output resolution ratio of system,LED screen display size,LED screen starting position Image effect---Brightness,contrast,saturation and dynamic contrast ... -
Page 13: Image Effect Menu
LED screen parameters：set the system output resolution format, in real application,we suggest select the same resolution with the LED screen. LED screen width：range from 320-3840，set the LED screen horizontal width LED screen height：range from 240-1920，set the LED screen vertical height. ... -
Page 14: Image Crop Menu
image effect interface can adjust the brightness、contrast、saturation、dynamic contrast and color temperature Image effect Brightness Contrast Saturation Dynamic contrast Color temperature → Brightness： range from 0-100。 contrast：range from 0-100。 saturation：range from 0-100。 Dynamic contrast：range from 0-4，0 is close ,1 is default value,not valid to the input VGA signage source. -
Page 15: Image Layout Menu
Crop width：minimum is 128，maximum is “the width of present output resolution ratio”. Crop height ：minimum is 128，maximum is “the height of present output resolution ratio”. Crop horizontal start：minimum is 0，maximum is the difference of“width of present output resolution ratio”and“Crop width” Crop vertical start：minimum is 0，maximum is the difference of“height of present output resolution ratio”and“Crop height”... -
Page 16: Mode Save Menu
PIP horizontal start：minimum is 0，maximum is the difference of“width of present output resolution ratio”and“PIP width” PIP vertical start：minimum is 0，maximum is the difference of“height of present output resolution ratio”and“PIP height” Graphic &text overlay parameters： Graphic&text overlay close text input source HDMI Text background color blue... -
Page 17: Advanced Setting Menu
8 kinds of save mode：main screen input signal source, led screen width and height,and start location,PIP signal source,PIP width and height,start location ,Image brightness, image contrast, image saturation Advanced setting menu Advance set menu options is shown as bellow: Advanced options 1.Language Chinese 2.Into navigation... - Page 18 Input frequency: refresh rate of custom resolution In order to make the resolution of input image and output image consistent and the user can manually input DVI resolution format. The parameters (input width, input height) are set according to the resolution.physical resolution of LED screen.
-
Page 19: Guide Mode
Guide mode When the machine is power on,it will show the following interface Press [OK] button to run into the “input” interface，as shown in picture Switch the signage source by press the front panel signage selection key ,short press the [OK] button to save the data and enter the "LED screen parameters setting"... -
Page 20: User Setting
Adjust the parameters by rotate the OK button ,make the value bigger or smaller ,then return to the current menu and select” effective”to save data then restart the device. User setting Guiding the users to quickly use the machine,the following will show you the common functions of the video processor:Partly display ,mode save, mode cover,clear mode,switch mode,check saved mode parameter etc. -
Page 21: Switch ,Review Mode
Mode save, cover ,clear In initial status ,short press [OK] button to main menu, use the rotating button to enter save menu,press [OK] button for twice to save it to mode 1,if mode 1 has already used ,press [OK] button to clear or overwrite mode,then press [OK] to confirm it. -
Page 22: Faq
The Video processor is a professional equipment, users should have professional knowledge when use some of functions. When users encounters problems, please try to adjust the machine yourself. If the steps listed below can’t help, please contact local dealer or contact our after-sales service team directly. - Page 23 ）.if so enter advance setting menu to unresponsive close it（Button lock close icon ） CONTACT US SHANGHAI ONBON TECHNOLOGY INC. Shanghai Head Office Add: Floor 7, Tower 88, 1199#, North Qinzhou Road,Xuhui District, Shanghai ,China Kunshan factory address: No.1299 fuchunjiang road,kunshan development zone,jiangsu,China...
