Clas Ohlson 31-3038 Manual

Key Ring with Projector Clock
• Shows month, date, hour, minutes and seconds
• 30 second alarm signal (can be shut off)
• Hourly chime (can be shut off)
• Projects the time
DisPlAy
In normal display mode, push MODE to change display in the following order: Normal display (hour,
minute) > Alarm time (hour, minute) > Month/Date (month, date) > Seconds (second).
set time
1. Push SET four times, the month digit is displayed. Change the setting by pushing MODE several
times until the correct month has been chosen. Push SET to save the setting and enter the date setup
mode.
2. Push MODE several times until the current date is displayed. Push SET to save. Do the same for the
hours and minutes.
3. Change to 24 hour display when needed: Push MODE several times whilst in hour setup mode until
H shows on the display.
set AlARm
1. In normal display mode, push SET once to change to setting of alarm time (hour, minute), AL is
shown on the display and the alarm time starts to blink.
2. Push SET again. The hour digit starts to blink.
3. Push MODE to go on to current hour. Push SET to save setting and open the minute setting. Push
MODE to go on to current minute. Push SET to save the minute setting.
ACtivAte/shut-off AlARm AnD houRly Chime
1. In normal display mode, push SET once to change to alarm display. The digits blink.
2. Activate the alarm by pushing MODE in the following order: alarm activated > hourly chime acti-
vated > alarm and hourly chime shut off.
3. When the alarm is activated a buzzer icon over AL is displayed. When the hourly chime is activated a
clock icon is displayed under AL.
4. Push MODE to shut off the alarm with Snooze function. The alarm sounds again after 4 minutes.
5. Push SET to shut off the alarm without Snooze function. The Snooze funciton can be activated by
pushing MODE within 30 seconds.
6. The buzzer sound automatically shuts off after 30 seconds.
PRojeCtion of time
Aim the lens of the clock towards a flat, light area at a distance of 0.8 ~ 1 metre and push LIGHT to display
the time.
BAtteRies
Operates on 3x G10/LR54 for clock and light. Follow local ordinances for disposal of batteries. Do not let
children play with batteries!
GREAT BRITAIN For consumer contact, please visit www.clasohlson.
co.uk and click on customer service. Internet: www.clasohlson.co.uk
ENGLISH
Article number: 31-3038
