User Guide
Guía del usuario
ILLUMINATE • POWER • CHARGE • JUMP
Rechargeable LED Flashlight / Portable Power
Bank / Jump Starter
Model/Modelo: UltraTec-8000
LUMEN OUTPUT: 8000
PEAK STARTING CURRENT: 500 Amps
USB OUTPUT: (2)x5V/2.4A
BATTERY CAPACITY: 10000mAh
FULLY CHARGE IMMEDIATELY AFTER PURCHASE.
Fully recharge after each jumpstarting, or every 3 months to ensure
long battery life.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Smartech UltraTec-8000
Summary of Contents for Smartech UltraTec-8000
- Page 1 User Guide Guía del usuario ILLUMINATE • POWER • CHARGE • JUMP Rechargeable LED Flashlight / Portable Power Bank / Jump Starter Model/Modelo: UltraTec-8000 LUMEN OUTPUT: 8000 PEAK STARTING CURRENT: 500 Amps USB OUTPUT: (2)x5V/2.4A BATTERY CAPACITY: 10000mAh FULLY CHARGE IMMEDIATELY AFTER PURCHASE.
- Page 2 To reduce risk of battery explosion, follow these instructions and those published by battery manufacturer and manufacturer of any equipment intended to be used in vicinity of battery. Review cautionary marking on these products and on engine. ULTRATEC-8000 USER GUIDE PAGE 2...
-
Page 3: Safety Information
10. When jump starting your vehicle do not place Jump Starter on the ground or at a height less than 18 inches. 11. Never charge or jump start a frozen battery. Store this item and charger in a cool dry place. ULTRATEC-8000 USER GUIDE PAGE 3... - Page 4 State of California to cause cancer and birth defects or other reproductive harm (California law requires this warning to be given to customers in the State of California). Wash hands after handling. ULTRATEC-8000 USER GUIDE PAGE 4...
- Page 5 ABOUT THE ULTRATEC-8000 Features 8000 lumen recharable LED flashlight with 10000mAh power bank with Built-In jump starter function. The jump starter features: Spark Proof Protection, Reverse Polarity Protection, Short Circut Protection, Over Current Protection, Over Discharge Protec- tion, Over Charge Protection, Self Discharging Protection and Over Heat Protection.
- Page 6 ULTRATEC-8000 USER GUIDE PAGE 6...
-
Page 7: Technical Specifications
Medium Brightness 1500 Lumens Low Brightness 150 Lumens Operating Temperature -22°F - +122°F Charging Temperature 32°F - +104°F Storage Temperature -22°F - +122°F (For 3 months) Flashlight Specifications: Brightness in Lumens Beam Distance Hours of Operation ULTRATEC-8000 USER GUIDE PAGE 7... - Page 8 CHARGING THE ULTRATEC-8000 Option 1: Home Charging To charge the UltraTec-8000, plug the USB C to USB charging cable into the back of the UltraTec-8000 flashlight. Plug the other end of the cable into the wall charger adaptor. Plug the wall charger adaptor into a wall outlet.
-
Page 9: Charging Cable
Option 2: Car Charging To charge the UltraTec-8000 from your car, plug the USB C to USB charging cable into the back of the UltraTec-8000 flashlight. Plug the other end of the cable into the 12V to USB adaptor. Plug the USB adaptor into the car cigarette lighter socket power outlet. -
Page 10: Using The Led Flashlight
USING THE LED FLASHLIGHT The UltraTec-8000 has 6 light modes. Turbo (highest brightness) High Medium Strobe S.O.S To turn on the flashlight, press the round power button. Press the power button repeatedly to cycle through the High/Medium/Low/ Strobe/S.O.S. modes. Quick Access: Double click to Strobe mode. - Page 11 USING THE COLORED LED FLASHLIGHT LENSES The UltraTec-8000 comes with three colored lenses: green, red and blue, that you can easily attach to the front of the UltraTec-8000. To attach the lens, gently screw To remove the lens, simply it onto the front of the flashlight.
-
Page 12: Status Led
ABOUT THE SMART JUMPER CABLES STATUS LED EC5 Plug Positive Clamp Negative Clamp ULTRATEC-8000 USER GUIDE PAGE 12... -
Page 13: Jump-Starting Procedure
This unit is only for emergency use, not for frequent commercial use! ENGINE START socket is ALWAYS activated! Do not attempt to jumpstart your vehicle when the UltraTec-8000 Power Bank battery capacity is below 30%. Turn off the vehicle ignition and all accessories (radios, lights, air conditioners, etc.), and disconnect electronic devices. - Page 14 5 seconds of engine cranking. The jumpstart feature is designed for short term operation only, and more than 5 seconds may cause damage to the unit. Allow the UltraTec-8000 to cool down for at least 3 minutes after each jumpstarting.
- Page 15 POWER / CHARGE USB DEVICES To power or charge your USB devices, connect the USB device to either of the 2 included USB ports on the UltraTec-8000 flashlight with the included multi device USB output cable (For Apple® for Apple® products, it’s better to use the original cable that came with the device).
-
Page 16: California Proposition
Crystalline silica from bricks and cement and other masonry products • Arsenic and chromium from chemically treated lumber. Your risk from exposure to these chemicals varies, depending on how often you do this type of work. To reduce your exposure, work ULTRATEC-8000 USER GUIDE PAGE 16... - Page 17 Contact Smartech Inc. Customer Service and Smartech Inc. will troubleshoot any issue via phone or e-mail. If the problem is not corrected by this method, Smartech Inc. will, at its option, authorize evaluation, repair or replacement of the defective part or component at a Smartech Inc.
- Page 18 Problems caused by parts that are not original parts. Limits of Implied Warranty and Consequential Damage Smartech Inc. disclaims any obligation to cover any loss of time, use of this product, freight, or any incidental or consequential claim by anyonefrom using this product. THIS WARRANTY IS IN...
- Page 19 Published by: Smartech Inc. Copyright © 2019 by Smartech Inc. Reproductions of this work, in whole or in part, without written permission of the publisher are strictly prohibited. The publisher does not assume and herby disclaims any liability to any party for any loss or damage caused by any error or omission in this manual, whether such error results from negligence, accident, or any other cause.
