Operator's Manual
Manual del Usuario
JUMP STARTER AIR COMPRESSOR AC POWER DC POWER USB POWER
JUMP STARTER AIR COMPRESSOR AC POWER DC POWER USB POWER
12V, 950A Portable Power Station
Central eléctrica portátil 12V, 950A
Model/Modelo JSL-950
CAUTION:
Read and follow all safety
rules and operating instructions
before every use of this product.
SAVE THESE INSTRUCTIONS.
FULLY CHARGE IMMEDIATELY AFTER PURCHASE. Fully recharge after
each use, or every 1 month to ensure long battery life.
ATENCIÓN:
Lea y siga todas las reglasde seguri-
dad e instrucciones de uso
antes de cada uso de este producto.
GUARDE ESTAS INSTRUCCIONES.
Advertisement
Table of Contents
Related Manuals for Smartech JSL-950
Summary of Contents for Smartech JSL-950
- Page 1 JUMP STARTER AIR COMPRESSOR AC POWER DC POWER USB POWER JUMP STARTER AIR COMPRESSOR AC POWER DC POWER USB POWER 12V, 950A Portable Power Station Central eléctrica portátil 12V, 950A Model/Modelo JSL-950 CAUTION: ATENCIÓN: Read and follow all safety Lea y siga todas las reglasde seguri-...
-
Page 2: Important Safety Instructions
A battery can produce a short circuit cur- rent high enough to weld a ring to metal, causing a severe burn. 6. Never smoke or allow a spark or flame in the vicinity of the battery or engine. JSL-950 USER’S MANUAL PAGE 2... - Page 3 18. WARNING: RISK OF ELECTRIC SHOCK! Incorrect operation of this product may result in damage and personal injury. The output of this product is 120V AC and can shock or electrocute the same as any ordinary household AC wall outlet. JSL-950 USER’S MANUAL PAGE 3...
- Page 4 JUMP STARTER FEATURES The Smartech JSL-950 Power Station is also equipped with LED flashlight, USB power output, 12V DC power output, air compressor and 120V AC power inverter. Technical Specification: Battery Type Lead-Acid Battery Capacity 12AH Peak Current 950A LED Flashlight 2.5W...
-
Page 5: Front View
AC Charging Adaptor BACK VIEW Air Compressor Hose Storage Area Air Compressor On/Off Switch Input Charging Indicator LED Air Compressor Gauge 15V/1A Input Port Cables with Clamps Clamp Storage Holders Inflation Adaptors Fuse & Screws JSL-950 USER’S MANUAL PAGE 5... - Page 6 Monitor the progress of the charge by pressing the Battery Voltage and % Indicator button and do disconnect immediately after battery is fully charged. Completely disconnect the charger cable when the engine is not running. JSL-950 USER’S MANUAL PAGE 6...
-
Page 7: Jump Starting
Turn the switch to the ON position. Crank the engine for no more than 8 seconds. If the engine does not start, wait 3 minutes before cranking again. JSL-950 USER’S MANUAL PAGE 7... -
Page 8: Usb Power
WATTAGE RUN TIME Cellular phones, 4 watts 36 hrs Fluorescent lights Radios, Fans, 9 watts 16 hrs Depth finders Camcorders, DVD 15 watts 9.6 hrs players, Spotlights Electrical tools, Bilge 24 watts 6 hrs pumps JSL-950 USER’S MANUAL PAGE 8... -
Page 9: Fuse Replacement
Step 1: Use screwdriver to take the screws out. Remove the rubber bottom panel first. Then remove the rear panel. WARNING: Unplug AC charging adaptor from Portable Power unit before attempting to replace fuse. Step 2: You will find the fuse box shown below. Fuse Box JSL-950 USER’S MANUAL PAGE 9... -
Page 10: Air Compressor
The inverter in this product uses a uses a modified sine waveform, which is not quite the same as power company electricity. We strongly recommend that you check the device’s manual to make sure it is compatible with JSL-950 USER’S MANUAL PAGE 10... - Page 11 It is important to know the continuous wattage of the device you plan to use with the inverter. The Smartech JSL-950 Power Station must be used with devices drawing 400 watts or less. If powering more than one device, start one device at a time to avoid a power surge and/or inverter overload.
- Page 12 This warranty gives you specific legal rights, and you may also have other rights which vary from state to state. Product distributed in the United States by Smartech Inc. 8700 Larkin Rd. Suite B Savage, MD 20763 www.SmartechProduct.com...
