EURO EV600EESX Usage And Care Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
cooking
USAGE AND
CARE GUIDE
PRODUCT CODE:
EV600EESX

Advertisement

loading
Need help?

Need help?

Do you have a question about the EV600EESX and is the answer not in the manual?

Questions and answers

Related Manuals for EURO EV600EESX

Summary of Contents for EURO EV600EESX

  • Page 1 USAGE AND CARE GUIDE PRODUCT CODE: EV600EESX...

  • Page 3: Important Safety Warning

    SAVE THIS INSTRUCTION AT SAFETY PLACE FOR FUTURE REFERENCE Thank you for choosing us! Please read all instructions before using this appliance. This book contains valuable information about operation, care and service.Keep it in a safe place for future reference. Should the appliance be sold or transferred to another owner, or should you move house and leave the appliance, always ensure that the book is supplied with the appliance in order that new owner can be acquainted with the functioning of the appliance and relevant warnings.
  • Page 4 This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. Children should be supervised to ensure that they do not play with the appliance.
  • Page 5 12.This appliance must be used for the purpose for which it expressly designed. Any other use is considered to be improper and consequently dangerous. The manufacturer declines all responsibility for damage resulting from improper and irresponsible use. A numbe of fundamental rules mu followed when using l appliances.
  • Page 6 20. When using small electric appliances near the hob, keep t he supply cord away from the hot parts. 21. ake sure the knobs are in its “OFF” position when the appliance is not in use. Also make all potentiall y dangerous parts of the appliance, safe, above all for children who could play with the appliance.
  • Page 7 CAUTION: The cooking process has to be supe rvised. A short term cooking process has to be supervised continuously WARNING: Danger of fire: do not store items on the cooking surfaces. 32.WARNING:Use only hob gusrds designed by the manufacturer of the cooking appliance or indicated by the manufacturer of the appliance in the instructions for use as use of inappropriate guards can cause accidents.suitable or hob guards incorporated in the appliance.

  • Page 8: Installation

    Installation The following instructions should be read by a qualified technician to ensure that the appliance is installed, regulated and technically serviced correctly in compliance with current regulations. It is necessary to allow disconnection of the appliance from the supply after installation. Important: remember to disconnect the appliance from electricity by turn off the mains before regulating the appliance or carrying out any maintenance work.
  • Page 9 Cooker Hood Figure 1 Leveling Your Appliance Take out of the 4 cooker feet from oven cavity, which be packed together with backing rack, and then screw them into the 4 plinth in lower part of cooker. These feet level off the oven when necessary.
  • Page 10 Leveling Your Appliance Take out of the 4 cooker feet from oven cavity, which be packed together with backing rack, and then screw them into the 4 plinth in lower part cooker. These feet l e vel off the oven when necessary. The height of the cooker can be adjusted by means of adjustable feet in the plinth.
  • Page 11 ctrical conn ection NING – T HIS APPLIAN CE MUST BE EARTHE wer supply vo oltage and fre quency: 220 0-240V A.C. 50Hz-60Hz. The electric cooker without a power supply cable. The cooker is designed to operate on an electricity supply which conforms to the electrical data shown on the Rating label.
  • Page 12 When use properly your appliance is completely safe but as with any electrical product there are certain precautions that must be observed. PLEASE READ THE PRECAUTIONS BELOW BEFORE USING YOUR APPLIANCE. Always . Turn controls OFF when you have finished cooking and when not in use. .
  • Page 13 SAFETY ADVICE IN CASE OF A CHIP-PAN FIRE In the event of a chip pan fire or any other pan fire. 1.TURN OFF THE COOKER APPLIANCE AT THE WALL SWITCH. 2.COVER THE PAN WITH A FIRE BLANKET OR DAMP CLOTH, this will smother the flames and exetinguish the fire.
  • Page 14 roduct t Desc cription A. C ooktop B. Vi tro Ceram C. C ontrol Panel aking Rack aking Pan Adjustable F...

  • Page 15: Shelf Placement Warning

    ACCESSORIES Wire shelf: For grill, dishes, cake pan with items for roasting and grilling. Slider bracket : For cooking larger size food, these shelf support rails on the right and left sides of the oven can be removed, dishes and tray can be put on the oven floor, using functions as Radiant grilling, Double grilling, Double grill with fan.
  • Page 16 Op p eration Instructions Oven power power indicator indicator...
  • Page 17 Oven controls - the function and temperature controls To use an oven function, first select the function with the left hand dial and then set the temperature of the function with the right hand dial. Set the timer in the middle.The indicator light will illuminate. When the temperature inside your oven reaches the temperature you set, the thermostat will cut off the heating element and the indicator light will go off.
  • Page 18 Sy y mbol Function d d escription Oven Lamp:Enables the user to observe the progress of cooking without opening the door.Oven lamp will lighting for all cooking functions,for the cooker with this optional function. except ECO function. Defrost:The circulation of air at room temperature enables quicker thawing of frozen food,(without the use of any heat).It's a gentle but quick way to speed up the defrosting time and thawing of ready-made dishes and cream filled produce etc.
  • Page 19 The temperature is set individually for each cooking zone, using the respective temperature controls. The controls can be turned clockwise and back again. The desired temperature canbe adjusted continuously. The power control lamp indicates that it goes out when all Multi-stage cooking zones controls are off. Control settings =Location of the cooking zone =Off...
  • Page 20 Hotplates General Information Notes Always Never Use gauze, metal pan diffusers,asbestos Use good quality flat -based cook ware on all mats and stands e.g. Wokstands - they electric heat sources. can use overheating. Use utensils with skirts or rims e.g. Always ensure pans have clean, dry bases buckets and some kettles.

  • Page 21: Oven Control

    Choosing Your Utensils Do not use utensils with rough bases. Do n use lightweight utensils with thin,distorted or uneven bases. Do n ot use lightweight enameled steel utensils. Do n ot use cast iron utensils. Do n ot use utensils with recessed, scrolled or ridged bases. Do not use a utensil which has a base concavity greater than 1mm as this will reduce the performance of the hob.
  • Page 22 Semi-automatic cooking is the function which allows a cooking operation to be started and then ended after a specific length of time set by the user. use the keys Press the key and the display will light up showing the figures 5seconds after setting the cooking duration,the count of the programmed cooking duratino will start and the display will show the current time together with...
  • Page 23 The set cooking data and timer data can be modified at any time. Press any function keys as follows: , then press the keys to change the value. Canceling cooking Having programmed a manual, semi-automatic or automatic cooking operation, to switch off the appliance, return all knobs to the 0 setting or press the keys togethe r.
  • Page 24 Removing the door for easier cleaning recommend you have someone to assist you dur f o l 1. pen the door completely . both hinges. the door slightly as if closing, and then with both hands supporting the door, pull it away from the oven.
  • Page 25 rouble e shoot ting stomer servi cooker, your cooker. Prooblem Slight odour or small amount of smoke This is normal and should cease after a short when using the cooker for the first time. period. Is the main cooker wall switch turned on? There may be no electricity supply.
  • Page 26 echnic cal Ch aracte eristics 60*60*85cm Cooker 950W p element 1100W Bott tom elemen 2000W Gril l element* 2000W nvection ele ment* nvection fan n motor* Roti isserie moto 1200W*2 hilig ght 165mm( RF, LR) 1800W*2 hilig ght 200mm( RR, LF) 2000/1100W hilig ght 270-165m...
  • Page 27 Maintenance schedule: To ensure the appliance continues to operate at peak performance, we recommend a routine service call years for the life of the appliance. FOR SPARE PARTS OR TO FIND THE ADDRESS OF YOUR NEAREST STATE SPARE PARTS CENTRE IN AUSTRALIA Eurostyle Group Pty Ltd 65 Glynburn Road Glynde S.A.
