EURO EV45SMWB Operation Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
BUILT-IN COMBINATION STEAM OVEN
WITH HOT AIR AND MICROWAVE
OPERATION MANUAL
MODEL:
EV45SMWB
Read these instructions carefully before using your
microwave oven , and keep it carefully.
If you follow the instructions, your oven will provide you with
many years of good service.
SAVE THESE INSTRUCTIONS CAREFULLY

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EV45SMWB and is the answer not in the manual?

Questions and answers

Related Manuals for EURO EV45SMWB

Summary of Contents for EURO EV45SMWB

  • Page 1 BUILT-IN COMBINATION STEAM OVEN WITH HOT AIR AND MICROWAVE OPERATION MANUAL MODEL: EV45SMWB Read these instructions carefully before using your microwave oven , and keep it carefully. If you follow the instructions, your oven will provide you with many years of good service.

  • Page 2: Table Of Contents

    CONTENTS CONTENTS PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY ADDENDUM SPECIFICATIONS IMPORTANT SAFETY INSTRUCTIONS TO REDUCE THE RISK OF INJURY TO PERSONS GROUNDING INSTALLATION SETTING UP YOUR OVEN IMPORTANT INFORMATION ABOUT INSTALLING FITTED UNITS INSTALLATION DIMENSIONS BUILDING IN 10-11 BEFORE FIRST USE OPERATION INSTRUCTION...

  • Page 3: Precautions To Avoid Possible Exposure To Excessive Microwave Energy

    If the apparatus is not maintained in a good state of cleanliness, its surface could be degraded and affect the lifespan of the apparatus and lead to a dangerous situation. Specifications Model: EV45SMWB Rated Voltage: 230-240V~50Hz Rated Input Power(Microwave): 1 0W...

  • Page 4: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS WARNING To reduce the risk of fire, electric shock, injury to persons or exposure to excessive microwave oven energy when using your appliance, follow basic precautions, including the following: 13. Install or locate this oven only in 1.
  • Page 5 23. Microwave heating of beverages can result in delayed eruptive boiling, therefore care must be taken when handling the container. 24.Children should be supervised to ensure that they do not play with the appliance. 25.The appliances are not intended to be operated by means of an external timer or separate remote-control system.

  • Page 6: To Reduce The Risk Of Injury To Persons Grounding Installation

    To Reduce the Risk of Injury to Persons Grounding Installation DANGER 2)The extension cord must be a grounding- type 3-wire cord. Electric Shock Hazard 3)The long cord should be arranged so that Touching some of the interna components it will not drape over the counter top or can cause serious personal injury or death.
  • Page 7 UTENSILS See the instructions on "Materials you can use in microwave oven or to be avoided in microwave oven." There may be certain non-metallic utensils that are not CAUTION safe to use for microwaving. If in doubt, you can test the Personal Injury Hazard utensil in question following the procedure below.

  • Page 8: Setting Up Your Oven

    Materials to be avoided in microwave oven Utensils Remarks Aluminum tray May cause arcing. Transfer food into microwave-safe dish. Food carton with May cause arcing. Transfer food into microwave-safe dish. metal handle Metal or metal- Metal shields the food from microwave energy. Metal trim may trimmed utensils cause arcing.

  • Page 9: Important Information About Installing

    IMPORTANT INFORMATION ABOUT INSTALLING This appliance is NOT intended for use in a commercial environment. • Please observe the installation instructions provided and note that this appliance • should only be installed by a quali fied technician. The appliance is fitted with a plug and must only be connected to a properly •...

  • Page 10: Fitted Units

    Fitted units This appliance is only intended to be fully fitted in a kitchen. • designed to be used as a tabletop appliance or inside a cupboard. This appliance is not • The fitted cabinet must not have a back wall behind the appliance. •...
  • Page 11 Fully insert the appliance and centre it. Do not kink the connecting cable. Screw the appliance into place. The gap between the worktop and the appliance must not be closed by additional battens. <...

  • Page 12: Before First Use

    BEFORE FIRST USE Initial cleaning and heating Removing the microwave oven all of the protection foil on the front. For more information see the "CLEANING". Before the first use of the appliance, ￭ Remove all accessories and wash out of the microwave. ￭...

  • Page 13: Operation Instruction

    OPERATION INSTRUCTION Control Panel This microwave oven uses modern electronic control to adjust cooking parameters to meet your needs better for cooking. 1.Clock Setting When the microwave oven is electrified, "00:00" will blink, buzzer will ring once. Press " " or " "...
  • Page 14 Microwave Power Chart Microwave Power 100% Display 900W 700W 450W 300W 100W You can see from the table below from which power levels you can choose and for which foods the power levels are suitable. Power level Food 900 W - Boiling water, reheating - Cooking chicken, fish, vegetables...
  • Page 15 4. Convection Cooking 1) Press the " " button to activate the microwave function. "01:00" displays and the microwave icon appears. Press " " or " " or " " to select convection mode. The default temperature is 180 degrees. 3) Press "...
  • Page 16 Microwave + Grill Cooking 1) Press the " " button to activate the microwave function. "01:00" displays and the microwave icon appears. 2) Press" " or " "or " " to select the " MW+GRILL" combination mode. 3) Press " "...
  • Page 17 7) Press" " to select the time setting mode. The default time is 10 minutes. Press" "or " " to select the cooking time . The MAX.time is 90 minutes. 9) Press " " button to start cooking. Microwave + Grill Fan Cooking 1) Press the "...
  • Page 18 Note: 1) For non-steam menu (P01-P20), press " " to confirm menu selection and enter the weight of menu selection state automatically, at this point, you can press " " or " ", choose the automatic menu weight cooking time display. 2) For the steam menu, at this time, if you need to adjust the default cooking time, you can press , and makes the default cooking time of flashing, at this point,...
  • Page 19 12. Steam Function 1) In standby mode, press " " button, enter the steam mode, time lights up by default 10:00. The icon is displayed, signs light up, there is no Parallax display "10:00", "Min" and " ℃ "symbol lit, tank icon on the right show the current water level (Water, lack of water).
  • Page 20 14. Microwave+Steam Function 1) In standby mode, press " " button, enter the steam mode, time lights up by default 10:00. Press " " or " " or " " to select MW+Steam mode. The icon is displayed, then displays 300W. 2) Press "...
  • Page 21 16. Display Specification (1) When setting, if no other operation,it will confirm automatically after 10 seconds. Except clock setting for the first time. (2) During setting program, after adjusted for 3 seconds, it will confirm automatically Except auto menu, it will confirm after adjusted for 10 seconds. (3) When the oven is in setting state or pause state, including auto menu and defrost program, if no operation in 5 minutes, it will enter into the off state.
  • Page 22 Defect codes Below defect codes may occur during steam functions : E-06: 1-Water tank is not close well. E-05: water system abnormal, need to contact for Engineer to check, below is the possibilities. 1-The water sensor is abnormal. 2-The water pipe is abnormal. 3-The water pump is abnormal.
  • Page 23 STEAM MENU WEIGHT POWER DISPLAY AUTO-MENU S t e a m 1 0 0! Trout +300W S t e a m 1 0 0! Salmon Filet +100W S t e a m 1 0 0! Pikeperch +300W Prawns S t e a m 1 0 0! S t e a m 1 0 0! Halibut filet +300W...
  • Page 24 S t e a m 1 0 0! Crab +300W S t e a m 1 0 0! + 3 0 0 W Chicken leg Chicken S t e a m 1 0 0! breast +300W S t e a m 1 0 0! Meatball +300W Turkey...
  • Page 25 2 0 0 S t e a m 1 0 0! + 3 0 0 W Eggplant/ Aubergine S t e a m 1 0 0! +300W Beans 2 0 0 S t e a m 1 0 0! Broccoli S t e a m 1 0 0! +300W Cauliflower...
  • Page 26 S t e a m 1 0 0! Bell peppers S t e a m 1 0 0! Hot peppers S t e a m 1 0 0! + 3 0 0 W Mushrooms S t e a m 1 0 0! + 3 0 0 W Leeks S t e a m 1 0 0!
  • Page 27 NO-STEAM MENU DISP AUTO-MENU WEIGHT POWER 450W 450W Melt chocolate 450W 450W 450W Melt butter 450W 1 0 0 W + 2 2 0! 1 0 0 W + 2 2 0! Sweet potato 1 0 0 W + 2 2 0! 1 0 0 W + 2 2 0! 1000 1 0 0 W + 2 2 0!
  • Page 28 4 5 0 W + 2 2 0! 4 5 0 W + 2 2 0! 4 5 0 W + 2 2 0! 4 5 0 W + 2 2 0! Roast Pork 4 5 0 W + 2 2 0! 4 5 0 W + 2 2 0! 1000 4 5 0 W + 2 2 0!
  • Page 29 (+800ml cold water) 700W Pasta (+1000ml cold water) (+1200ml cold water) 900W Soup Pizza 900W Muffin 900W 50+500ml water 100+1000ml water Oatmeal 900W/450W 150+1500ml water Baked Apple 700W Sandwich 900W Popcorn 900W Fudge Brownies 100W+180! Bread Grill Level3 Chick nuggets 100W+220 ! ench Fries 100W+220!
  • Page 30 peanut chocolate P r e - h e a t / 1 8 0! cookies hanburg 1 0 0 W + 2 2 0 Muffin P r e - h e a t / 1 8 0! (70g*12)

  • Page 31: Troubleshooting

    TROUBLE SHOOTING It is forbidden to run the unit without any food inside. It is very dangerous. According to Waste of Electrical and Electronic Equipment (WEEE) directive, WEEE should be separately collected and treated. If at any time in future you need to dispose of this product please do NOT dispose of this product with household waste.
  • Page 32 PN:16170000A53237...
