TABLE B-1
Pin
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
24 SunSwift PCI Adapter Installation and User's Guide • August 1997
Single-Ended Connector Signals (Continued)
Signal
SCSI_GND
SCSI_GND
SCSI_GND
SCSI_GND
SCSI_GND
SCSI_GND
SCSI_GND
SCSI_GND
SCSI_GND
SCSI_GND
SCSI_TERMPOWER
SCSI_TERMPOWER
OPEN
SCSI_GND
SCSI_GND
SCSI_GND
SCSI_GND
SCSI_GND
SCSI_GND
SCSI_GND
SCSI_GND
SCSI_GND
SCSI_GND
SCSI_GND
SCSI_GND
SCSI_GND
SCSI_GND
SCSI_GND
Pin Signal
41 SCSI_D<1>_
42 SCSI_D<2>_
43 SCSI_D<3>_
44 SCSI_D<4>_
45 SCSI_D<5>_
46 SCSI_D<6>_
47 SCSI_D<7>_
48 SCSI_DATA_PARITY0_
49 SCSI_GND
50 SCSI_GND
51 SCSI_TERMPOWER
52 SCSI_TERMPOWER
53 OPEN
54 SCSI_GND
55 SCSI_ATN_
56 SCSI_GND
57 SCSI_BSY_
58 SCSI_ACK_
59 SCSI_RST_
60 SCSI_MSG_
61 SCSI_SEL_
62 SCSI_CD_
63 SCSI_REQ_
64 SCSI_IO_
65 SCSI_D<8>_
66 SCSI_D<9>_
67 SCSI_D<10>_
68 SCSI_D<11>_
