B
A P P E N D I X

Interface Signals

SunSwift PCI Adapter Connectors

68-pin SCSI-2 Connector
FIGURE B-1

Single-Ended SCSI-2 Connector Signals

TABLE B-1
Pin
1
2
3
4
5
6
34
68
SunSwift PCI Adapter Backplate
Single-Ended Connector Signals
Signal
SCSI_GND
SCSI_GND
SCSI_GND
SCSI_GND
SCSI_GND
SCSI_GND
1 8
1
35
RJ-45 Connector
Pin Signal
35 SCSI_D<12>_
36 SCSI_D<13>_
37 SCSI_D<14>_
38 SCSI_D<15>_
39 SCSI_DATA_PARITY1_
40 SCSI_D<0>_
23
