- Page 1 Magnetic Drilling Machine SWC 50 MAX SWC 50 MAX OPERATING MANUAL...
-
Page 2: Table Of Contents
5.4 Speed selection 6. Exploaded View 7. Helpful Tips 8. Troubleshooting This manual is for information only & not a legal document, the company has all SWC 50 MAX rights to change, cancel, amend any designs, specifications etc. without any prior notice. - Page 3 Use ear Use safety Use eye Please read protection helmet protection the manual Pacemaker Wear appropriate Disconnect before Use safety warning clothing opening chain Dangerous Warning for Don’t use in environment electrical shock wet places SWC 50 MAX...
- Page 4 WHEN ARC WELDING IS IN PROGRESS. D.C. CURRENT WILL EARTH BACK THROUGH THE MAGNET AND CAUSE IRREPARABLE DAMAGE. DO NOT USE MACHINE OUTSIDE OR IN WET ENVIRONMENT WITHOUT AN (RCD) RESIDUAL CIRCUIT DEVICE. RCD MUST BE USED. SWC 50 MAX...
- Page 5 6. Nobody should be in the area where the Drill machine is being used by the Operator. MANDATORY RULES TO ENSURE SAFETY 1. Before you start using the Drill machine, make sure you inspect the condition of the power cord and the plug. Replace them immediately if you see any damage. SWC 50 MAX...
- Page 6 Switch off the motor when it is not in use. 9. Add a certain amount of coolant to the equipment whenever you SWC 50 MAX...
- Page 7 17. The generation of the magnetic field affects devices such as watches, mobile phones and pacemaker installed to regulate the heartbeat. Make sure that the operator takes of the watch and keeps the mobile phone before operating the drilling machine and doesn't have a pacemaker installed in him. SWC 50 MAX...
- Page 8 EC Directive 2002/96/EC-WEEE, also known as Waste Electrical and Electronic Equipment. In case of doubts or queries, contact the Department of Waste Disposal. 2. Disposal of grease: Follow the instructions given by the lubricant's manufacturer. SWC 50 MAX...
-
Page 9: Accessories
Magnetic Drilling Machine Operating Manual OPTIONAL TOOLS & ACCESSORIES Weldon Drill Chuck Adaptor Weldon Tapping Adaptor Drill Chuck Weldon Counter Sink MT 2 / MT 3 Arbour Core Drill Pilot Pin Taper Drift SWC 50 MAX... -
Page 10: Description & Technical Data
Magnetic Drilling Machine SWC 50 MAX Operating Manual DESCRIPTION & TECHNICAL DATA SWC 50 MAX Motor power 1350 watt Spindle MT2, 19 mm (3/4”) Weldon Broach cutter (35 mm length) ø 12 mm - ø 50 mm Broach cutter(50 mm length) ø... -
Page 11: Operating Manual
Ensure that the magnetic drilling unit is secure on the working piece. Fill the arbor with lubrication/cutting oil in the special meant holes. Always use cutting oil from your dealer. Start the motor by pressing the green motor start button (I). SWC 50 MAX... -
Page 12: Drilling With Twist Drills
These adapters will allow you to attach a drill chuck on to the hole cutter arbor. Also twist drills with a direct Weldon connection are available (ranging from Ø 6 – Ø 12 mm) Place the machine at the desired position Switch on the magnet SWC 50 MAX... -
Page 13: Speed Selection
It might be possible that while shifting the gears it could have stuck with the already selected speed gear, adjust spindle of the machine by moving it clockwise and anti clockwise direction simultaneously moving the speed knob. SWC 50 MAX... -
Page 14: Exploaded View
Magnetic Drilling Machine Exploded View SWC 50 MAX Motor complete / Antriebseinheit 78.1 84.1 84.2 84.3 SWC 50 MAX... - Page 15 Magnetic Drilling Machine Exploded View SWC 50 MAX Motor complete / Antriebseinheit Part no. Article No. Article Description 0709311707812 Screw ST4.8x60 0709311707829 Motor cap SWC 40 0709311707836 Screw M4x12 0709311707843 Washer 0709311707850 Carbon brush 18x6.2x9.9 220V 0709311707867 Carbon brush holder 18x6.2x9.9...
- Page 16 Magnetic Drilling Machine Exploded View SWC 50 MAX Magnetic frame / Magnetbohrständer SWC 50 MAX Circuit Diagram / Schaltplan MAGNET Field Coil MOTOR ON/OFF SWITCH MAGNET SWITCH SWC 50 MAX...
- Page 17 Magnetic Drilling Machine Exploded View SWC 50 MAX Magnetic frame / Magnetbohrständer Part No. Article Article Description 0709311708253 Fuselage (blue) SWC 50 MAX 0709311708260 PCB Box 66x52x30.5 0709311708277 Cross screw M3x12 0709311708284 220V 0709311708291 PCB Box Cap 66x52x24 0709311708307 Screws...
-
Page 18: Helpful Tips
TIP: Most situations which cause problems or question marks have already occurred for other users. Contact Schifler or your dealer to see if a solution exists for your situation. (example: for drilling into non-magnetic material with your magnetic drill, a special vacuum system has been designed). -
Page 19: Troubleshooting
The connecting nipple has gotten clogged. Do a deep cleaning of the tank and the nipple. The lubricant tap is jammed or has gotten closed. Open the tap. Contact the Customer Service immediately if the steps and remedies described above do not solve your problem. SWC 50 MAX... - Page 20 Magnetic Drilling Machine Models : SWC 32, SWC 35, SWC 35AT, SWC 35 PD, SWC 40, SWC 50 MAX, SWC 50 MAX-T, SWC 50 PD, SWC 50, SWC 50 WT, SWC 50 PDT, SWC 50 WT SB, SWC 65, SWC 65 WT,...
