- Page 1 IC E MAKER INSTRUCTIO N MANUAL Model: ICM1550 THANK YOU FOR CHOOSING OUR ICE MAKER PLEASE READ THE MANUAL CAREFULLY BEFORE OPERATING...
-
Page 2: Important Notices
IMPORTANT NOTICES When using an electrical appliance, basic safety precautions should always be followed to reduce the risk of fire, electric shock, and/or injury, including the following: 1. Read all instructions before using. 2. Remove all packing material and carefully check your ice maker to ensure it is in good condition and that there is no damage to the ice maker or power cord and plug. - Page 3 children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. Children should be supervised to ensure that they do not play with the appliance. 13.
- Page 4 This symbol indicates the refrigerant R600a and the non-metallic materials of the appliance are flammable. It’s a warning symbol. Warning: Risk of fire / flammable materials. WARNING: When positioning the appliance, ensure the supply cord is not trapped or damaged. WARNING: Do not locate multiple portable socket-outlets or portable power supplies at the rear of the appliance.
-
Page 5: Specifications
SPECIFICATIONS Model Number: ICM1550 Voltage: 120V/60Hz Power Consumption: 150 W Daily Ice Output: 15kg / 24 hours Ice Storage Capacity: 1.8L/700 g Water Reservoir Capacity：2.3 L N.W: G.W: Ice Making Mode: big and small Compression-type Refrigeration: 120V/60Hz Cooling Agent: R600a environmental friendly refrigerant... -
Page 6: Indicator Lamp
DESCRIPTION CONTROL PANEL INDICATOR LAMP BUTTONS TOP LID REAR HOUSNG ICE BASKET AIR VENT WATER TANK FRONT HOUSING... - Page 7 FEATURE Quick ice making Two different sizes of ice can be made Prompt when the ice is full and water is insufficient Bullet ice 10 pcs ice can be made in 8-9 minutes. 1. During transportation, do not tilt the machine more than 45 degrees, do not reverse the machine.
-
Page 8: Control Panel Operation
CONTROL PANEL OPERATION POWER：Power Supply SELECT：Mode selection S: small ice selection L: big ice selection ICE FULL: water full alarm ADD WATER: water shortage alarm 1. Plug in the power supply and the “L” indicator flashes. Press the “POWER” button, the “L” indicator light is always on, the machine will start the deicing function first, then automatically make the ice according to the selected mode, deicing after the completion of ice making, and then enter the deicing function,... - Page 9 means water shortage in the water tank. You need to add water and press the “POWER” button to restart the machine. 4. ICE FULL: ice full alarm. When the ice reaches the maximum amount of ice storage container, the "ICE FULL" light flashes and the machine stops.
- Page 10 1. When the indoor temperature is lower than 20 degrees, please choose small ice. When the indoor temperature is higher than 30 degrees, it is recommended to choose large ice. 2. The three cycles used for the first time, the ice produced is small and irregular.
- Page 11 please drain the water out and clean it up. 5. If the compressor takes a strike action for shortage water, fully water or interruption of power supply, it will delay for 3mins to start up after restarted. 6. When the machine is used again after a long time, please start the cleaning function first.
-
Page 12: Troubleshooting
TROUBLE SHOOTING PROBLEM POSSIBLE CAUSE SUGGESTED SOLUTIONS The compressor works The voltage is lower than Stop the Ice maker and do not restart abnormally with a recommended until the voltage is normal. buzzing noise 1.Add to some water until it reaches Water shortage 1.There is no water MAX position... - Page 13 The machine has been working, but the water Solenoid valve failure Replace the solenoid valve has been warming When the ice is full, the Ice full sensor damaged Replace the ice full sensor machine does not Solar light interference Call the service hotline display the ice full Icon Water supply pump Call the service hotline to replace...
- Page 14 6. Children should be supervised to ensure that they do not play with the appliance. 7. Do not immerse in water. Correct Disposal of this product This marking indicates that this product should not be disposed with other household wastes throughout the EU.
-
Page 15: Warranty
We warrant that your kumio ice maker will be free of defects in materials and workmanship under normal home use for 2 years from the date of original purchase.
