Transmission Medium:
Network Lobe Distance:
Data Transfer Rate:
STP Connector Cable Specifications
Wire Type:
Maximum Cable Distance:
Nominal Direct Current
Resistance:
Nominal Outside Diameter: .310 inch x .455 inch
Nominal Impedance:
Nominal Velocity of
Propagation:
Token Ring (UTP Connector)
Electrical Specification:
Connector:
Accessing Scheme:
Topology:
Maximum Nodes for
Physical Network:
Transmission Medium:
Network Lobe Distance:
Data Transfer Rate:
Technical Specifications
Type 1-Individual Shielded Pair
100 meters (328 feet) suggested maximum
4 or 16 Mbps
Belden 96888 or equivalent, 4 conductors in two
individually shielded pairs, copper braid shield overall
328 feet, 100 meters
22 gage solid copper
.0255 inches diameter
16 ohms/1000 feet
52.5 ohms/kilometer
150 ohms
8.5 picofarads/foot
27.9 picofards/meter
IEEE 802.5
8-position modular jack, Stewart 88-360808 or
equivalent
Token Passing
Star Wired Ring
72
Type 3-unshielded Twisted Pair
100 meters (328 feet) suggested maximum, Level 4
4 or 16 Mbps
A-3
