3-2
C
3: N
HAPTER
ETWORK
Accessing the User
Interface
I
C
C
NTERFACE
ARD
ABLING
To access the UI of the corresponding NAC, connect the following cables
to the NIC's console port.
Callout Number
1
2
3
Description
RJ-45 connector to NIC's console port
DB-25 male connector to modem for remote operations
DB-25 female-to-female null modem adapter to PC or
terminal COM port
TO K E N
R IN G N IC
RS-232
C
H
1
RS-232
C
H
2
TOK EN
RIN G
S
T
P
TOK EN
RIN G
U
T
P
