Edifier Luna Eclipse - e25-Multimedia Speaker Manual

Table of Contents

Contents

1 Important safety instructions
2 Box Contents
3 Overview The Unit
4 Connectivity
5 Bluetooth
- 5.1 In Bluetooth Mode
6 Specifications
7 Troubleshooting
8 Documents / Resources
- 8.1 References
- 8.2 Download manual

Important safety instructions

To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.

Thank you for purchasing this EDIFIER product. For generations, EDIFIER tries to provide powered speaker products to satisfy the need of our end customers, even the most demanding ones. This product can add to your home entertainment, personal computer, and mini home theater great sound performance. Please read this manual carefully to obtain the best of this system.

shock hazard
The lightning flash with arrowhead inside thetriangle, is intended to alert the user to the presence of un-insulated dangerous voltage within the product's enclosure that may be of a sufficient magnitude to constitute a risk of electric shock to persons.

Risk of electric shock
Do not open
To prevent the risk of electric shock, do not remove cover (or back). No user-serviceable Parts inside. Refer servicing to qualified Service personnel only.

warning
The exclamation point inside the triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the product.

Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Do not use this apparatus near water.
Clean only with dry cloth.
Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.
Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.
Only use attachments/accessories specified by the manufacturer.
Unplug this apparatus during lightning storms or when unused for long periods of time.
Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
The MAINS plug or an appliance coupler is used as the disconnect device, the disconnect device shall remain readily operable.

FCC Caution:
"Changes or modifications not expressly approved by the part responsible for compliance could void the user's authority to operate the equipment."

FCC statement:
"This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

this device may not cause harmful interference, and
this device must accept any interference received, including interference that may cause undesired operation."

"This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help."

IC statement:
This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions:

this device may not cause interference, and
this device must accept any interference, including interference that may cause undesired operation of the device. This Class【B】digital apparatus complies with Canadian ICES-003..

Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

Correct Disposal of this product. This marking indicates that this product should not be disposed with other household wastes throughout the EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material resources. To return your used device, please use the return and collection systems or contact the retailerwhere the product was purchased. They can take this product for environmental safe recycling.

This equipment is a Class II or double insulated electrical appliance. It has been designed in such a way that it does not require a safety connection to electrical earth.

Box Contents

Overview The Unit

Front view

Standby/ON
Volume up
Volume down
Input indicator (blue: Bluetooth; red: AUX)

Rear view

Connect to audio connecting cable
Connect to power adapter
Connect to passive speaker
Connect to active speaker

Play/Pause: Touch " , +, " at the same time briefly.

To put the system into Standby/On: Touch and hold " " for approximately 2 seconds.

Remote control

Standby/ON
Volume up
Volume down
Battery compartment

Battery loading:
Insert a coin into the slot and rotate anti-clockwise to open the battery compartment, install the new CR 2025 battery and rotate the cover clockwise to close the compartment.

Note:

Do not place the remote control in places that are hot and humid..
Do not charge the batteries.
Remove the batteries when unused for long period of time.
The battery should not be exposed to excessive heat such as direct sun, fire or similar.

Connectivity

Bluetooth

Set you device (mobile phone, tablet device, MP3/MP4 player etc.) to search and select "EDIFIER Luna Eclipse"
Pair your device with "EDIFIER Luna Eclipse".
When the connection is made, the input indicator will change to blue.
Play the audio on your paired device and adjust the volume to a desired level.

In Bluetooth Mode

To skip to the next track:
Slide from to " "
To revert to the previous track:
Slide from " " to
To disconnect Bluetooth:
Touch and hold " , +, " at the same time for approximately 2 seconds.

Note:
When the Bluetooth is disconnected, the system will automatically switch to AUX mode.

Note:

To enjoy the full Bluetooth functions of this product, please ensure your mobile device has A2DP & AVRCP profile.
PIN code for connection is "0000" if needed.

Specifications

Power output:	RMS 15W × 2 (treble) + 22W × 2 (bass) (DRC ON)
Signal to noise ratio:	≥85dBA
Frequency response:	50Hz ~ 20KHz (+/-6dB)
Input type:	Bluetooth/AUX
Input sensitivity:	600mV ± 50mV
Adjustment:	Touch keys, remote control
Bass & mid-range unit:	3 inch (82mm), 6Ω
Treble unit:	Φ19mm silk dome, magnetically shielded, 6Ω
Dimension:	122(W) × 212(H) × 222(D) mm
Weight (net/gross):	Approx. 3.96kg/5.33kg

Troubleshooting

Switch the EDIFIER Luna Eclipse off then on and reconnect to the audio source.
Ensure Bluetooth function is enabled compatible on your Bluetooth devices.
Move the devices closer and retry the connection.
Try another Bluetooth device for connection.
Please check if power is connected, and if the wall outlet is switched on.
Please Switch the system off then on and reconnect to the audio source.
Please check if the system is in STBY.
Please check if the master volume is turned to minimum.
Please check if the audio input cable is connected correctly.
Please check if there is signal from audio source.
Keep a 0.2 ~1m distance between the speaker system and monitor or TV set to avoid magnetic interference.

If you have any further questions or concerns regarding EDIFIER Products...
Asia, Europe, Oceania:

Please visit our website at: www.edifier-international.com or email EDIFIER Support for further assistance at: enquiry@edifier.com,
Dear Customer, thank you for purchasing this EDIFIER product.
For the EDIFIER warranty applicable for this product, we refer you to the EDIFIER website www.edifier-international.com/warranty-terms.

Canada/USA/Mexico:
www.edifier.ca,
Email: service@edifier.ca
If you prefer, you may contact us by phone, Toll Free: 1-877-EDIFIER (334-3437) in Canada, 1-800-688-7406 in US.
