- Page 1 - f r e e z e r INSTRUCTION BOOK ERN 2930 2222 258-31...
- Page 3 Before use Setting the temperature The freezer compartment Freezing fresh food Frozen food storage Thawing Making ice cubes Fresh food refrigeration Normal operating sounds Movable shelves Positioning the door shelves Bottle holder Internal cleaning External cleaning When the appliance is not in use Changing the light bulb Defrosting Positioning...
- Page 4 Remove all securing tapes. Wash inside the appliance with lukewarm water and bicarbonate of soda (5 ml to 0.5 litre of water). The temperature inside the refrigerator and the freezer is regulated by a single thermostat with 6 temperature positions and an “OFF” (O) position. Position 1 = minimum coldness Position 6 = maximum coldness Turn the thermostat dial to the required position.
- Page 5 Frozen food, prior to being used, can be thawed in the fridge or at room temperature depending on the time available. Small food items may even be cooked from frozen; in this case cooking will take longer. Any frozen food which is allowed to thaw accidentally should either be eaten as soon as possible or thrown away.
- Page 6 The walls of the refrigerator have runners so that the shelves can be positioned as desired . For better use of space, the front half-shelves can lie over the rear ones. D338 To permit storage of food packages of various sizes, the door shelves can be adjusted in height.To make these adjustments proceed as follows: Gradually pull the shelf in the direction of the arrows...
- Page 7 • To obtain the best results from your appliance, neither hot foods nor liquids which may evaporate, should be placed in the larder compartment. • Keep the time between buying chilled food and placing it in your fridge as short as possible. •...
- Page 8 Before any maintenance or cleaning work is carried out, DISCONNECT the appliance from the ELECTRICITY supply. Clean the inside and accessories with warm water and bicarbonate of soda (5ml to 0.5 litre of water). Rinse and dry thoroughly. When the appliance is not in use for long periods, disconnect from the electricity supply, empty all foods and clean the appliance, leaving the doors ajar to prevent unpleasant smells.
- Page 9 Remember to wash the defrost cleaner in hot soapy water at regular intervals. Dry throughly before replacing. When the frost has reached a thickness of up to 4mm it can be removed using the ice scraper provided with the appliance. During this operation it is not necessary to disconnect the appliance from the mains and remove the food.
- Page 10 If you call out an engineer to a fault listed below, or to repair a fault caused by incorrect use or installation a charge will be made, even if the appliance is under guarantee. contacting your local Service Force Centre, check the following points: No power to the appliance The light does not come on The temperature in the fridge or freezer section is...
- Page 11 The model and serial number of the appliance (found on the rating plate) The purchase date For general enquiries concerning your Electrolux appliance or for further information on Electrolux products, please contact our Customer Care Department by letter or telephone at the address below or visit our website at www.electrolux.co.uk...
- Page 12 We, Electrolux, undertake that if within 12 months of the date of the purchase this Electrolux appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option repair or replace the same FREE OF CHARGE for labour, materials or carriage on condition that: The appliance has been correctly installed and used only on the electricity supply stated on the rating plate.
- Page 13 POWER SUPPLY VOLTAGE AND FREQUENCY TOTAL POWER ABSORBED AVERAGE DAILY UNITS ELECTRICITY * GROSS CAPACITY NET CAPACITY STAR RATING This figure is based on standard test results in accordance with European Standard EN 153. Actual consumption will depend on how the appliance is used and where it is located. 220-240 V / 50 Hz 120 W 0.87 kWh...
- Page 14 IF YOU ARE DISCARDING AN OLD APPLIANCE THAT HAS A LOCK OR CATCH ON THE DOOR, YOU MUST ENSURE THAT IT IS MADE UNUSABLE TO PREVENT YOUNG CHILDREN BEING TRAPPED INSIDE. Depending upon the position which you choose for your appliance, you may wish to reverse the way in which the door opens.
- Page 15 The plug must not be used if the fuse cover/carrier is lost. The cover/carrier is indicated by the coloured insert at the base of the plug. A replacement cover/carrier must be obtained from your local Electrolux Service Force Centre. This appliance complies with the following E.E.C. Directives: (Low Voltage Directive) and subsequent modifications;...
- Page 16 1. Unscrew the upper pin and remove the spacer 2. Remove the upper door 3. Unscrew the middle hinge and the brackets and refit them on the opposite side 4. Refit the upper door, the upper pin and the spacer on the opposite side 5.
- Page 17 Push appliance into housing until stop strip (A) touches the kitchen unit. D023 Open the door and push the appliance against the side of the kitchen unit opposite to that of appliance hinges. Fasten the appliance with 4 screws provided in the kit included with the appliance.
- Page 18 Separate parts A, B, C, D as shown in the figure PR266 Place guide (A) on the inside part of the furniture door, in the upper and lower position as shown in the figure and mark the position of external holes. Having drilled the holes, fix the guide with the screws supplied.
- Page 19 PR168 PR167/1 D734...
