Araknis Networks AN-X20-AP-I Quick Start Manual

Araknis Networks AN-X20-AP-I Quick Start Manual

Wi-fi 6 wireless access point
Hide thumbs

Advertisement

Quick Links

Download this manual
AN-X20-AP-I
Wi-Fi 6 Wireless Access Point
Quick Start Guide

Advertisement

loading
Need help?

Need help?

Do you have a question about the AN-X20-AP-I and is the answer not in the manual?

Questions and answers

Related Manuals for Araknis Networks AN-X20-AP-I

Summary of Contents for Araknis Networks AN-X20-AP-I

  • Page 1 AN-X20-AP-I Wi-Fi 6 Wireless Access Point Quick Start Guide...

  • Page 2: Welcome To Araknis Networks

    Welcome to Araknis Networks™ Thank you for choosing an Araknis™ Wi-Fi 6 Wireless Access Point (WAP). With circular housing, an easy mounting system, convenient PoE power, and the latest Wi-Fi 6 wireless technologies, these products are ideal as staples in both residential and commercial applications.
  • Page 3 Step 1: Unbox Wireless Access Point Mounting Bracket Tile Ceiling Backing Plate Quick Start Guide (WAP) Male-to-Female Tile Ceiling Drywall Wood Surface Mounting Hardware Mounting Hardware Mounting Hardware Category Jumper Cable Note: This manual uses the 820 WAP for illustrative purposes throughout.
  • Page 4 Step 2: Install Ceiling Mount How to Remove the Cable Bay Cover Push to Release the Cable Bay Cover Push In Release Copyright © 2021, Snap One, LLC. All rights reserved. Note: Use the ceiling back plate on top of acoustic ceiling tiles to prevent the mounting nuts from pulling through.
  • Page 5 Position the Ceiling Mount Ceiling Ceiling Mount Center Center Line* Line* Position 2 Position 1 Position A Position B * Center line of the bracket is not necessarily the center line of the WAP when installed. Use the above guide to understand the center line of the WAP when installing the bracket.
  • Page 6 Recommended use of the Jumper Cable You can mount your access point to the electrical box in one of two positions, shown below. These options are provided to provide cable bend relief for cables of different lengths and thicknesses. Illustrations do not reflect pre-install steps.
  • Page 7 Step 3: Connect Internet Router PoE Switch Internet Router Switch PoE Injector (not included) Internet Router Switch DC Power Supply (not included)

  • Page 8: Step 4: Operation

    Step 4: Operation LED States AP State LED State Description No LED The AP is not powered on Solid White The AP is in a startup process at the uboot stage Blinking White The AP is in a startup process at the kernel stage Operational States Solid Blue...

  • Page 9: Reset Procedures

    Reset Procedures The reset button can be found in the WAP’s cable bay. Reset Button Reset Password UI Toggle Reset Button Action LED State Description Reset button held for 1-9 Blinking Green The AP restarts seconds Reset Password UI Toggle Reset button held for 10-19 Only the username and Blinking Orange...
  • Page 10 Step 5: Configuration Araknis WAPs can be configured through OvrC or the local interface. The local interface is accessible using OvrC’s webconnect feature, typing the WAP’s DHCP address into your browser’s address bar, or using the WAP’s default IP address. Configuration Through OvrC OvrC gives you Wi-Fi management, remote device management, real-time notifications, and intuitive customer management, right from your computer or mobile device.
  • Page 11 Logging in to the Local Interface Log into the WAP using the default credentials: Username araknis Password araknis You must update the password after initial login. Pro Tip: Strong passwords are long and unrelated to the client’s public details. For example, thepeppero- nipizzas is stronger and easier to remember than P@ssword or thesmiths.
  • Page 12 Saving and Applying Changes Click the Save button after applying changes to a page. This holds the new settings in the Apply Changes field. After all desired changes have been made, click the flashing Apply Changes button, at the bottom of the left menu, to review the new settings.
  • Page 13 Other Access Methods: DHCP IP Address The WAP is configured to DHCP by default so that the DHCP server can assign an IP address when the WAP is connected to the network (the DHCP server is usually the router). This address can be used for accessing the web interface. Use one of these methods to find the IP address of the WAP: •...
  • Page 14 Other Access Methods: Default IP Address If the WAP is not given an IP address on the network, or needs to be accessed while not connected to a network, you can configure your computer’s network connection to access the WAP using the default IP address, 192.168.20.253.
  • Page 15 Windows 10 screenshots shown for reference. Click Change adapter Select Internet Protocol Right-click the icon for the settings. Version 4 (TCP/IPv4), then wired network connection, then left-click Properties. click Properties.
  • Page 16 Windows 10 screenshots shown for reference. In the General tab, click Use Open a browser Set the IPv4 Properties back the following IP address: to Obtain an IP address and navigate to http://192.168.20.253/. automatically, then click OK. and enter the IP address and subnet mask, then click OK.
  • Page 17 Snap One, LLC (formerly known as Wirepath Home Systems, LLC), in the United States and/or other countries. 4Store, 4Sight, Control4, Control4 My Home, SnapAV, Araknis Networks, and OvrC are also registered trademarks or trademarks of Snap One, LLC. Other names and brands may be claimed as the property of their respective owners. Snap One makes no claim that the information contained herein covers all installation scenarios and contingencies, or product use risks.
  • Page 18 Electrical Safety Advisory Sécurité électrique consultatif Important Safety Instructions Consignes de sécurité importantes Read the safety instructions before using this product. Lisez les consignes de sécurité avant d'utiliser ce produit. 1. Read these instructions. Lisez ces instructions. 2. Keep these instructions. Conservez ces instructions.
  • Page 19 11. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
  • Page 20 This product requires a properly grounded outlet for safety. This plug is designed to be inserted into a NEMA 5-15 (three-prong grounded) outlet only. Do not force the plug into an outlet that is not designed to accept it. Never dismantle the plug or alter the power cord, and do not attempt to defeat the grounding feature by using a 3-to-2 prong adapter.
  • Page 21 WARNING – No user serviceable parts inside. If the product is not operating properly, do not remove any part of the unit (cover, etc.) for repair. Unplug the unit and consult the warranty section of the owner’s manual. AVERTISSEMENT – Aucune pièce réparable par l'utilisateur à l'intérieur. Si le produit ne fonctionne pas correctement, ne retirez aucune pièce de l'appareil (couvercle, etc.) pour réparation.
  • Page 22 USA & Canada Compliance FCC Part 15, Subpart B Unintentional Emissions Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a residential installation.

  • Page 23: Professional Installation Instruction

    Notice: The term “FCC ID:” and “IC:” before the certification number signifies that FCC and Industry Canada technical specifications were met. FCC ID: 2AJAC-AN520API IC: 7848A-AN520API This equipment must be installed by qualified professionals or contractors in accordance with FCC Part 15.203 & IC RSS-247, Antenna Requirements. Do not use any antenna other than the one provided with the unit.

  • Page 24: Instructions D'installation Professionnelle

    les dispositifs fonctionnant dans la bande de 5 150 à 5 250 MHz sont réservés uniquement pour une utilisation à l’intérieur afin de réduire les risques de brouillage préjudiciable aux systèmes de satellites mobiles utilisant les mêmes canaux; (ii) pour les dispositifs munis d’antennes amovibles, le gain maximal d’antenne permis pour les dispositifs utilisant les bandes de 5 250 à...
  • Page 25 3. Procedure d'installation Consulter le manuel d'utilisation. 4. Avertissement Choisir avec soin la position d'installation et s'assurer que la puissance de sortie ne depasse pas les limites en vigueur. La violation de cette regle peut conduire a de serieuses penalites federales.
  • Page 26 This product can be put into service in all of the EU member states, European Free Trade Association (EFTA) and EU candidate countries without any restriction. The frequency and maximum transmitted power in EU are listed as below: 2412~2472MHz ：19.35 dBm 5180~5240MHz ：22.44 dBm 5260~5320MHz ：22.47 dBm 5500~5700MHz ：29.10 dBm...
  • Page 27 customers that it needs to be recycled, and (2) provide a way for their products to be appropriately disposed of or recycled at the end of their product lifespan. For collection or recycling of Snap One products, please contact your local Snap One representative or dealer. Australia &...
