Araknis Networks AN-420-AP-D Quick Start Manual

Araknis Networks AN-420-AP-D Quick Start Manual

Wi-fi 6 tri-band access point
Hide thumbs

Advertisement

Quick Links

Download this manual
AN-420-AP-D
Wi-Fi 6 Tri-band Access Point
Quick Start Guide

Advertisement

loading
Need help?

Need help?

Do you have a question about the AN-420-AP-D and is the answer not in the manual?

Questions and answers

Related Manuals for Araknis Networks AN-420-AP-D

Summary of Contents for Araknis Networks AN-420-AP-D

  • Page 1 AN-420-AP-D Wi-Fi 6 Tri-band Access Point Quick Start Guide...

  • Page 2: Welcome To Araknis Networks

    Welcome to Araknis Networks™ Thank you for choosing an Araknis™ Wi-Fi 6 Tri-band Access Point (AP). With improved thermal performance by way of a die-cast aluminum bottom and desktop mounting for convenient use, this tri-band access point has the versatility to maintain performance in both wireless and wired installs for home applications.
  • Page 3 Step 1: Unbox Access Point 12V 3A DC power supply 2ft category patch cable Quick Start Guide (AP) Note: You must use the 12V 3A DC power supply.
  • Page 4 Step 2: Install Place the AP on a desk, table, or shelf. Perform a thorough site survey to determine the best area to install the AP in the house.
  • Page 5 Step 3: Connect Internet Router Switch DC power supply...

  • Page 6: Step 4: Operation

    Step 4: Operation LED States AP State LED State Description No LED The AP is not powered on Solid White The AP is in a startup process at the uboot stage Operational Blinking White The AP is in a startup process at the kernel stage States Solid Blue The AP started correctly and is running in an operational state...

  • Page 7: Reset Procedures

    Reset Procedures Reset Button The reset button AP’s cable bay. Reset Button Action LED State Description Hold the reset button for 1-9 seconds Blinking Green Restarts the AP Hold the reset button for 10-19 seconds* Blinking Orange Resets the username and password only Hold the reset button for more than 20 seconds Blinking Red Resets the AP to factory defaults...
  • Page 8 Step 5: Configuration Araknis APs can be configured through OvrC or the local interface. The local interface is accessible using OvrC’s WebConnect feature, typing the AP’s DHCP address into your browser’s address bar, or using the AP’s default IP address. Configuring the AP in OvrC OvrC provides Wi-Fi management, remote device management, real-time notifications, and intuitive customer management, using your computer or mobile device.
  • Page 9 Logging in to the Local Interface Log into the AP using the default credentials: Username araknis Password araknis You must update the password after initial login. Pro Tip: Strong passwords are long and unrelated to the client’s public details. For example, thepepperonipizzas is stronger and easier to remember than P@ssword or thesmiths.
  • Page 10 Saving and Applying Changes Click the Save button after applying changes to a page. This holds the new settings in the Apply Changes field. After all desired changes have been made, click the flashing Apply Changes button, at the bottom of the left menu, to review the new settings.
  • Page 11 Other Access Methods: DHCP IP Address The AP is configured to DHCP by default so that the DHCP server can assign an IP address when the AP is connected to the network (the DHCP server is usually the router). This address can be used for accessing the web interface. Use one of these methods to find the IP address of the AP: •...
  • Page 12 Accessing the AP Using the Default IP Address If the AP is not given an IP address on the network, or needs to be accessed while not connected to a network, you can configure your computer’s network connection to access the AP using the default IP address, 192.168.20.253. Windows 10 screenshots shown for reference.
  • Page 13 Windows 10 screenshots shown for reference. Click Change adapter Select Internet Protocol Right-click the icon for the settings. Version 4 (TCP/IPv4), then wired network connection, then left-click Properties. click Properties.
  • Page 14 Windows 10 screenshots shown for reference. In the General tab, click Use Open a browser Set your computer’s IPv4 the following IP address: Properties back to Obtain an and navigate to https://192.168.20.253/. IP address automatically, and enter the IP address and subnet mask, then click OK.

  • Page 15: Fcc Statement

    FCC Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
  • Page 16 FCC Statement This device has been evaluated to meet general RF exposure requirement. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 cm between the radiator and a human body.
  • Page 17 ISED Statement This device contains licence-exempt transmitter(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: (1) this device may not cause interference, (2) this device must accept any interference, including interference that may cause undesired operation of the device. L’émetteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence.
  • Page 18 ISED Statement This equipment complies with ISED radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 cm between the radiator and a human body. Cet équipement est conforme aux limites d'exposition aux rayonnements ISED établies pour un environnement non contrôlé.
  • Page 19 Snap One, LLC (formerly known as Wirepath Home Systems, LLC), in the United States and/or other countries. 4Store, 4Sight, Control4, Control4 My Home, SnapAV, Araknis Networks, and OvrC are also registered trademarks or trademarks of Snap One, LLC. Other names and brands may be claimed as the property of their respective owners. Snap One makes no claim that the information contained herein covers all installation scenarios and contingencies, or product use risks.
