Position the Ceiling Mount
Ceiling
WAP
Position A
* Center line of the bracket is not necessarily the center line of the WAP when installed. Use the above guide to
understand the center line of the WAP when installing the bracket.
Center
Line*
Position 1
Ceiling Mount
Position B
Center
Line*
Position 2
