- Page 1 SLIPSTREAM US Patent: D715,917 INSTRUCTION MANUAL WARRANTY CERTIFICATE...
- Page 2 This product is protected by United States Federal and/or State Law including Patents, Trademark, and/or Copyright Laws. ©2019 Minka Lighting Inc. Manual design and all elements of manual design are protected by United States Federal and/or State Law including Patents, Trademark, and/or Copyright Laws.
- Page 3 * The warranty is void once the original purchaser or user ceases to own the fan or the fan is moved from its original point of installation. * The warranty is void with the use of any hanger bracket (non-Minka Aire or non-fan specific) other than the hanger bracket supplied & installed...
- Page 4 To obtain warranty service during the warranty period, the purchaser should return the fan with the sales receipt to the original place of purchase. The authorized Minka-Aire® dealer, at its sole discretion, will either repair or replace the fan after verifying the legitimacy of the warranty claim.
-
Page 5: Table Of Contents
CONTENTS SAFETY RULES................... INSTALLING THE MOUNTING PLATE............. PACKAGE CONTENTS................INSTALLING THE LED LIGHT KIT .............. INSTALLING THE FAN................INSTALLING THEGLASS SHADE ............. HANGING THE FAN................OPERATING THE REMOTE CONTROL/WALL CONTROL..... ELECTRICAL CONNECTIONS.............. CARE OF YOUR FAN..................FINISHING THE INSTALLATION............TROUBLESHOOTING................... ATTACHING THE FAN BLADES............ -
Page 6: Safety Rules
SAFETY RULES 1. Before you begin installing the fan, shut power off at the circuit breaker of the fuse box. 2. Be cautious! Read all instructions and safety information before installing your new fan. Review accompanying assembly diagrams. 3. Make sure that all electrical connections comply with local codes, ordinances, or National Electrical Codes. Hire a qualified electrician or consult a do-it-yourself wiring handbook if you are unfamiliar with installing electrical wiring. - Page 7 NOTE: NOTE: The important safeguards and instructions appearing in this manual are not meant to cover all possible conditions and situations that may occur. It must be understood that common sense, caution and care are factors which can not be built into this product. These factors must be supplied by the person (s) installing, caring for and operating the unit.
-
Page 8: Package Contents
PACKAGE CONTENTS Unpack your fan and check the contents. You should have the following items: 1. Fan blades (8) 14. 12V MN21/A23 battery 15. Balancing kit 2. Blade support plates (8) 3. Hanger bracket A. Mounting hardware: 4. Canopy #10 x 1.5" Wood screws (2 PCs.) 5. -
Page 9: Installing The Fan
To hang your fan where there is an existing fixture but no ceiling joist, you may need to install UPSIDE HANGER RECESSED BRACKET ® OUTLET BOX a hanger bar as shown in Fig. 4 (available at your Minka-Aire dealer). FIG. 3 FIG. 4... -
Page 10: Hanging The Fan
The use of other parts, the Lock Pin and Hitch Pin previously removed, tighten Set Screws. (Fig. 9) ® hardware or components not supplied by Minka Aire with the fan will ®... - Page 11 DOWNROD DOWNROD RUBBER COVER OUTLET BOX CANOPY DOWNROD CROSS PIN COUPLING COVER SET SCREWS CANOPY COVER HITCH LOCK HANGER SUPPLY BALL REGISTRATION SET SCREW SET SCREWS WIRES SLOT DOWNROD HANGER BRACKET Fig. 5 Fig. 6 Fig. 7 Fig. 8 Fig. 10 LOCK PIN HITCH PIN Fig.
-
Page 12: Electrical Connections
(Fig. 11) No frequency change is necessary, should you desire to install another Minka Aire DC motor fan within the same home or area with a separate frequency code please see the "frequency interference" troubleshooting section of this instruction manual to learn how to change the frequency. - Page 13 Step 1. Motor to House Supply Wires Electrical Connections: Connect the WHITE wire (Neutral) from the outlet box to the WHITE wire marked "AC in N" from the motor. Connect the BLACK wire (Hot) from the outlet box to the BLACK wire marked "AC in L" from the motor. Secure all wire connections with the plastic wire nuts provided.
-
Page 14: Finishing The Installation
FINISHING THE INSTALLATION OUTLET BOX Step 1. Remove 1 of the 2 screws from the bottom of the hanger bracket and loosen the other one half a turn from the screw head. HANGER BRACKET Step 2. Slide the canopy up towards the hanger bracket and place the key hole on the canopy over the screw on the hanger bracket, turn canopy until it locks in place at the narrow HANGER section of the key holes. -
Page 15: Attaching The Fan Blades
ATTACHING THE FAN BLADES SLOT Insert one fan blade into the blade slot on the motor housing and secure with the blade support plate, lock washers, and screws. Securely tighten screws. Repeat process with other blades. (Fig 14) Secure the last screw through the blade hole. -
Page 16: Installing The Mounting Plate
600-1 INSTALLING THE MOUNTING PLATE (PL019) PL-190C Step 1. Remove 1 of 3 screws from the mounting ring and loosen the other 2 screws. (Do not remove) Step 2. Place the key holes from the mounting plate over the 2 screws previously loosened from the mounting ring, turn mounting plate until it locks in place at the narrow section of the key holes. -
Page 17: Installing The Led Light Kit
INSTALLING THE LED LIGHT KIT NOTE: Before starting installation, make sure power is turned off at the circuit breaker. NOTE: If you do not wish to install the light kit, skip this step and proceed to next step. CAUTION: The light source is designed for this specific application and can overheat if serviced by untrained personnel. -
Page 18: Installing Theglass Shade
INSTALLING THE GLASS SHADE Raise glass shade up against bottom of fan housing and secure it to the fan by turning the glass shade clockwise until snug. DO NOT OVERTIGHTEN. (Fig. 18) NOTE: The metal light cover included with your fan is an option to replace the glass for the light in the event that you prefer not to use the light METAL feature of your fan. -
Page 19: Operating The Remote Control/Wall Control
OPERATING THE REMOTE CONTROL/WALL CONTROL Remote Control only: Install a A23 12 volt battery (included). To prevent damage to transmitter remove the battery if not used for long periods of time. IMPORTANT: THIS REMOTE CONTROL & DC FAN MOTOR ARE DESIGNED TO PERFORM A ONE TIME SELF CALIBRATION TEST. THIS TEST WILL IMPORTANT: THIS REMOTE CONTROL &... - Page 20 Note: The auto learning function will only shut off when the self calibration test has power after 30 seconds if interruption occurs. mandate within 60 seconds when turning the finished. The total self calibration test will last Please remove obstacles before re-set. about 6 minutes.
- Page 21 Speed settings for warm or cold weather depend on factors such as room size, ceiling height and number of fans. NOTE: To change the direction of the rotation of the blades the fan must be in operation mode. Warm Weather (forward) A DOWNWARD airflow creates a cooling effect as shown in Figure 20.
-
Page 22: Care Of Your Fan
CARE OF YOUR FAN Here are some suggestions to help maintain your fan. 4. Use a lint free lightly damp cloth or duster to remove dust from the blades. 1. Because of the fan's natural movement some connections may become loose. -
Page 23: Troubleshooting
TROUBLESHOOTING SYMPTOM SYMPTOM Fan will not start Fan Sounds Noisy SOLUTION SOLUTION Check to make sure the wall switch is turned on. Allow a 24-hour "break in" period. Most noises associated with a new fan will go away during this time. Check circuit fuses or breakers. - Page 24 SYMPTOM SYMPTOM Fan Wobble Fans/Light Turn On and Off Unexpectedly SOLUTION SOLUTION This is caused by interference, Please see "Frequency interference" for NOTE: All blade sets are grouped by weight. Because wood and steps to change the frequency. plastic blades vary in density, the fan may wobble even though blades are matched.
- Page 25 SYMPTOM Frequency Interference SOLUTION Turn the power off to your ceiling fan. Please use a small size tool to change the frequency settings on the control system. Return power to the unit. Note: After the AC power is on, do not press any other button on the transmitter before pressing the "Stop" button, doing so will cause the procedure to fail.
-
Page 26: Specifications
SPECIFICATIONS Fan Size Speed Volts Amps Watts N.W. G.W. C.F. These are typical readings. Your actual fan may vary. They do not include amps and wattage used by the light(s). 0.11 5.81 65" 11.79 13.30 2.48' High 0.43 30.75... - Page 27 For any additional information about your ● Airflow Efficiency: 285 Cubic Minka Aire Ceiling fan, please write to: Cost Range of Similar Models (19” – 84”) Feet Per Minute Per Watt ● Based on 12 cents per kWh and 6.4 hours use per day ●...
