MONITOR DESK MOUNT
Thanks for choosing our product! We strive to provide the best quality and services
for our customers. Would you kindly share your experience on Amazon if you are
satisfied? If you have any questions, please feel free contact us.
Email: forgingmount888@163.com
75*75mm
100*100mm
INSTALLATION MANUAL
Model：FM4545
We're ready to help!
MAX
36"
26.4LBS
MAX
1
Advertisement
Related Manuals for Forging Mount FM4545
Summary of Contents for Forging Mount FM4545
- Page 1 MONITOR DESK MOUNT INSTALLATION MANUAL Model：FM4545 Thanks for choosing our product! We strive to provide the best quality and services for our customers. Would you kindly share your experience on Amazon if you are satisfied? If you have any questions, please feel free contact us.
- Page 2 IMPORTANT SAFETY INFORMATION Read the entire instruction manual before you start installation and assembly. If you have any questions regarding any of the instructions or warnings, please contact US via: forgingmount888@163.com BE CAREFUL ！ CAUTION: Exceeding the weight capacity can result in serious personal injury or damage to equipment! 1.
-
Page 3: Packing List
PACKING LIST 1（×1） 2（×1） 3（×1） Base Clip Plate Long Bolt 5（×1） 4（×1） 6（×1） 7（×1） Clamp Bracket Lower Arm Upper Arm 8（×1） 9（×1） 10（×1） VESA Plate Cable Cover Anti-slip Pad M8×20（×1） M4×10（×4） M5×10（×4） M6×10（×2） 3MM（×1） 4MM（×1） 5MM（×1）... - Page 4 Installation Method 1 Clamp Installation 1a-1 1a-2 1a-3a 1a-3b 2 : 1 1a-4 2 : 1...
- Page 5 Installation Method 2 Grommet Base Installation 1b-1 1b-2...
- Page 6 Connect with Monitor Use a wrench (G) to screw the screws (A/B) into the four 1 : 1 holes at the back of the monitor to avoid damaging the monitor by over tightening the screws. 1 : 1 1 : 1 1 : 1 When the display is inserted After insertion, rotate the knob...
- Page 7 Case 1： Monitor/Arm Fall Down (After Install Your Monitor) Press the arm to make it keep it in horizontal position and then use the Allen Key to adjust the screw on the arm.Turn counter-clockwise(”+ ” direction) to increase gas spring tension till can hold the weight of your monitor. Note: You may need to turn the screw by many circles to tighten the arm.
- Page 8 Adjustment Adjust Flexiblity Turn clockwise to tighten Turn counterclockwise to loose If the pitching angle too tight or too loose when adjusting the mount, please adjust the screw Limit Screw This limit screw can prevent the head from sinking. It can also be disassembled if necessary...
- Page 9 Cable Management Adjustable Instruction +90° 180° 360° -45° 360° 360°...
- Page 10 Thank you again for choosing this forgingmount product!
