Instruction Manual
Universal Table Top TV Stand
Thank you for choosing our product! We strive to provide the best quality
and services for our customers. Would you kindly share your experience
on Amazon if you are satisfied? If you have any questions, please feel
free contact us.
forgingmount888@163.com
Email：
We're ready to help!
HY4105
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Forging Mount HY4105
Summary of Contents for Forging Mount HY4105
- Page 1 ® Instruction Manual Universal Table Top TV Stand HY4105 Thank you for choosing our product! We strive to provide the best quality and services for our customers. Would you kindly share your experience on Amazon if you are satisfied? If you have any questions, please feel free contact us.
- Page 2 UNPACKING INSTRUCTIONS AND IMPORTANT SAFETY INFORMATION • Carefully open the carton, remove contents and lay out on cardbard or other protective surface to avoid damage. • Check to assure that all components were received undamaged. Do not use damaged or defective parts.lf you require replacement parts, contact customer service at forgingmount888@163.com •Install and operate this product with care.
- Page 3 at the four corners Assemble upper and lower support columns (d1, d2) tightening M6x10 bolts (l) and 6.5x18x2 washers (u2) insert upper column into the low column with Allen key (y) Step 1-3 Attach support column to swivel pad (g) First, slide plastic cover (e) onto column.
- Page 4 Connecting the TV Plate to Support Column Attach TV plates (a1) to TV plate connector (a2) using M6x10 bolts (l) and washers (m) and tighten C bubble level with the Allen key(y) Attach TV plate to support column at desired height using M6x10 bolts (l) and washers (m) .
- Page 5 Step 3 Mounting the Monitor Brackets(b) to your TV Select the Screws or 5/16”(8mm) Mounting Monitor Brackets t, u1, v n, p, r o, q, s t, u1, v t, u1, v First, make sure the diameter of the bolt(n to s) fits your TV. Then, please see the diagram above. You will need to thread the bolt into the TV using the correct washer (t,u1,v) and spacer (w , x) if necessary with a screwdriver(Not included).
- Page 6 Attaching TV To TV Plate and Managing the Wires S t e p 4 Hang the TV on to Stand, there are two gears that can be adjus ted! 2.56” Hang the T V o n the b rac kets (a) a nd a djus t the p os ition. T hen u s e the s c rewdriver to l oc k t he b uc kle(A ) a nd s c rews (B ) tight.
- Page 7 Attaching the Security Steel Wire to the TV S t e p 5 If your TV is located nearby the wall as the Diagram 5a, then a steel wire can be attached for added security. Attaching the two ends of steel wire to the top two holes on the back of TV, shown in Diagram 5b. Wall Diagram 5a Diagram 5b...
- Page 8 Thank you for choosing our product! We strive to provide the best quality and services for our customers. Would you kindly share your experience on Amazon if you are satisfied? If you have any questions, please feel free contact us. forgingmount888@163.com Made in China...
