Instruction Manual
Universal Table Top TV Stand
Thank you for choosing our product! We strive to provide the best quality
and services for our customers. Would you kindly share your experience
on Amazon if you are satisfied? If you have any questions, please feel
free contact us.
forgingmount888@163.com
Email：
We're ready to help!
HY4101
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Forging Mount HY4101
Summary of Contents for Forging Mount HY4101
- Page 1 ® Instruction Manual Universal Table Top TV Stand HY4101 Thank you for choosing our product! We strive to provide the best quality and services for our customers. Would you kindly share your experience on Amazon if you are satisfied? If you have any questions, please feel free contact us.
- Page 2 Exceeding the weight capacity can result in serious personal injury or damage to equipment! It is the installer’s responsibility to make sure the combined weight of HY4101 and the display does not exceed 88 ibs(40kg).Use with heavier televisions may result in instability causing tip over resulting in death or serious injury! This product contains small items that could be a choking hazard if swallowed.
- Page 3 Put tempered glass(O) on the table. Put Gasket(R) and M6x25 Bolt(L) under tempered glass(O).Make sure the paperside of the gasket(R) face to the tempered glass(O). Turn Plastic Cover(Y) and Support Pillar(P) upside down under tempered glass(O) and then tighten the bolts(L) with the Allen key(V). If you find the support pillar(P) is not in the correct direction, please see figure 1.3 below.
- Page 4 (J)Wire Clip Inserting wire clips(J) Step 3 Measure VESA and Check TV screws on the Back of TV Measure the distance between the holes located at the back of your TV (these measures may form the shape of a square, or a rectangle) and check that these taken measures are within the VESA (*) range for this TV stand .
- Page 5 When attaching brackets to the flat screen, be careful not to over tighten screws and be sure that screws do not bottom out in the mounting holes. Too Short Too Long Correct Correct Step 4 Mounting the Monitor Brackets(N) to your TV (N)Monitor Bracket (A)M4x30 Bolt (B)M6x16 bolt...
- Page 6 Attaching TV to TV Plate(M) and Cable management (K) Safety lock CAUTION: Avoid potential personal injury or property damage! Make sure your locking screws are tightened BEHIND the mounting plate so the TV is securely fastened in place. monitor bracket(N) Safety lock(K) screwdriver (Not included)
