Installation & Operation Manual
30P-STGL, 30P-STGL-LX, 40P-STGL,
40P-STGL-LX, 30P-STGM, 30P-STGM-LX,
40P-STGM and 40P-STGM-LX
Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury
or death. Read the installation, operating and maintenance instructions thoroughly before installing or
M
R
ANUAL 10158
EV 4 (09/21)
$21.00
UniVerse Skillet™
Gas Tilting Skillets
Model 30P-STGM
servicing this equipment._
CROWN FOOD SERVICE EQUIPMENT
70 Oakdale Road, Downsview (Toronto) Ontario, Canada, M3N 1V9
Telephone: 919-762-1000
WARNING
A Middleby Company
www.crownsteamgroup.com
UNIVERSE SKILLET™ GAS TILTING SKILLETS
IMPORTANT FOR FUTURE REFERENCE
Please complete this information and retain this
manual for the life of the equipment:
Model #: ___________________________
Serial #: ___________________________
Date Purchased: _____________________
M
S
ANUAL
ECTION
CO
Advertisement
Related Manuals for Market Forge Industries UniVerse Skillet 30P-STGL
Summary of Contents for Market Forge Industries UniVerse Skillet 30P-STGL
- Page 1 IMPORTANT FOR FUTURE REFERENCE Please complete this information and retain this manual for the life of the equipment: Model #: ___________________________ Serial #: ___________________________ Date Purchased: _____________________ Installation & Operation Manual UniVerse Skillet™ Gas Tilting Skillets 30P-STGL, 30P-STGL-LX, 40P-STGL, 40P-STGL-LX, 30P-STGM, 30P-STGM-LX, 40P-STGM and 40P-STGM-LX Model 30P-STGM WARNING...
-
Page 2: Important Notes For Installation And Operation
Safety Precautions UniVerse Skillet™ Gas Tilting Skillets SAFETY PRECAUTIONS Before installing and operating this equipment, be sure everyone involved in its operation is fully trained and aware of precautions. Accidents and problems can be caused by failure to follow fundamental rules and precautions. The following symbols, found throughout this manual, alert you to potentially dangerous conditions to the operator, service personnel, or to the equipment. -
Page 3: Table Of Contents
UniVerse Skillet™ Gas Tilting Skillets Table of Contents RETAIN THIS MANUAL FOR FUTURE REFERENCE. Table of Contents Important Notes For Installation and Operation ..............2 Service Connections ......................4 Installation Instructions ......................5 Operation ..........................8 Maintenance ......................... 10 Cooking Guidelines ....................... 11 Troubleshooting ........................ -
Page 4: Service Connections
Service Connections UniVerse Skillet™ Gas Tilting Skillets ERVICE ONNECTIONS DIMENSIONS ARE IN INCHES [MM] 1.68 [43] 1.68 [43] SHOWN WITH OPTIONAL DRAIN PAN ASSEMBLY & DRAW-OFF VALVE REAR FLANGE FOOT DETAIL 2 EQUALLY SPACED Ø 7/16 [11mm] HOLES ON 2.5 [63] B.C. OPTIONAL 2”... -
Page 5: Installation Instructions
UniVerse Skillet™ Gas Tilting Skillets Installation NSTALLATION NSTRUCTIONS NPACKING IMMEDIATELY INSPECT FOR SHIPPING DAMAGE Immediately after unpacking the steamer, check for possible shipping damage. If the steamer is found to be damaged, save the packaging material and contact the carrier within 15 days of delivery. Prior to installation, verify that the electrical service agrees with the specifications on the machine data plate which is located on the left side panel. - Page 6 Installation UniVerse Skillet™ Gas Tilting Skillets UniVerse Tilting Skillet with Electronic Ignition General Installation 1. Remove carton from skid, being careful not to dent or scratch finished surfaces of unit. 2. Inspect unit carefully for shipping damage. File claim with carrier immediately if damage is found. 3.
- Page 7 UniVerse Skillet™ Gas Tilting Skillets Installation Installation with Casters 1. Installation shall be made with a connector that complies with the Standard for Connectors for Moveable Gas Appliances, ANSI Z21.69, CAN/CGA-6.16, and a quick-disconnect device that complies with the Standard for Quick- Disconnect Devices for Use with Gas Fuel, ANSI Z21.41 or the Standard for Quick-Disconnect Devices for Use with Gas Fuel, CAN-6.9.
-
Page 8: Operation
Description The Market Forge Industries UniVerse Models 30P-STGL (93,000 BTU input) and 40P-STGL (126,000 BTU input) are electrically operated skillets, tilting type, with 30- and 40-gallon capacities, respectively. They are equipped with a solid state thermostat and high-limit control with a 100 °F to 450 °F temperature scale. - Page 9 UniVerse Skillet™ Gas Tilting Skillets Operation CAUTION: BE SURE TO READ • Disconnect the power supply to skillet before cleaning or servicing. (Note: “LX” models should have the skillet raised to washing position before disconnecting power supply.) • Keep this appliance area free and clear of combustibles. •...
-
Page 10: Maintenance
Maintenance UniVerse Skillet™ Gas Tilting Skillets Maintenance WARNING Disconnect the power supply to the appliance before cleaning or servicing. Replacement of Temperature Control 1. Place circuit breaker in off position. 2. Remove skirted dial knob by loosening two set screws in the knob. (Use a 5/64 Hex key to loosen screws). 3. -
Page 11: Cooking Guidelines
UniVerse Skillet™ Gas Tilting Skillets Cooking Guidelines OOKING UIDELINES Cooking Portions and Times 1. The UniVerse Skillet is one of the most versatile pieces of equipment to be found in any restaurant or institutional kitchen. 2. This unit will stew, simmer, pan-fry, braise, grill, and sauté – and all with a very uniform heat pattern. NOTICE DO NOT ATTEMPT TO DEEP FRY WITH YOUR SKILLET! 3. - Page 12 Cooking Guidelines UniVerse Skillet™ Gas Tilting Skillets 18. The unit can also be used as a holding cabinet by adding water and settling the thermostat at approximately 175 °F. 19. When using water over and over for vegetable cookery, be sure to add water occasionally to keep level at about 3 - 4 inches.
- Page 13 UniVerse Skillet™ Gas Tilting Skillets Cooking Guidelines 30 GALLON PER LOAD 40 GALLON PER LOAD PORTION BATCHES ITEM TEMP. (°F) SIZE PER HOUR QTY. YIELD QTY. YIELD MEAT-POULTRY Bacon 3 slices 2 lb 3 lb Ham Steak 3 oz 10 lb 15 lb Pork Chops 5 oz...
- Page 14 Cooking Guidelines UniVerse Skillet™ Gas Tilting Skillets 30 GALLON PER LOAD 40 GALLON PER LOAD PORTION BATCHES ITEM TEMP. (°F) SIZE PER HOUR QTY. YIELD QTY. YIELD VEGETABLES (continued) FROZEN Beans, French Green 3 oz 15 lb 22-1/2 lb Lima Beans 3 oz 15 lb 22-1/2 lb...
-
Page 15: Troubleshooting
UniVerse Skillet™ Gas Tilting Skillets Troubleshooting ROUBLESHOOTING PROBLEM PROBABLE CAUSE REMEDY 1. Uneven or poor heating. a. Temperature control out of calibration or defective. a. Replace temperature control. b. Unit attached to wrong gas supply. b. Compare to specifications on data plate. c. - Page 16 UniVerse Skillet™ Gas Tilting Skillets 30P-STGL, 30P-STGL-LX, 40P-STGL, 40P-STGL-LX, 30P-STGM, 30P-STGM-LX, 40P-STGM and 40P-STGM-LX UniVerse Skillet™ Gas Tilting Skillets A product with the Market Forge name incorporates the best in durability and low maintenance. We all recognize, however, that replacement parts and occasional professional service may be necessary to extend the useful life of this appliance.
