• After unfolding or assembling the rollator always ensure that the seat support is securely locked by
the pulling strip mechanism for securing the lock and that the frame does not move anymore.
• Always ensure that both arm support inner tubes are securely locked in the main frame tube with
the two wing knobs to prevent the accidental sliding in of the inner tubes when forced.
• Always test that both armrests are set on the same height and that they are properly fastened on
top of the inner tube. It is not allowed to use a defective device.
• Always make sure that after everything has been secured, nothing can move.
• Always test to see that the rollator and attachments are properly and safely locked in place
BEFORE using.
• Failure to follow these warnings can result in personal injury.
Folding
- Unlock the pulling strap
- Lift the pulling strap on the seat to fold the rollator.
- Fold the rollator until the red button locks.
(1)
Adjusting height of the arm pads
- Unlock the pulling strap
- Release the height adjustment's locking knob,
- Make adjustment to your desired height.
- Tighten the knob.
- Fasten the stabilizing strap (3), to ensure full rigidity and stability of the structure.
06 / 2019 5/29
(2)
(3)
