Installation Guide
For Model:
BLV54ABZ5
E206035
net weight of fan: 19.4 lb. (8.8 kg)
READ THESE INSTRUCTIONS AND
SAVE THEM FOR FUTURE USE
Table of Contents:
Safety Tips. pg. 1
Unpacking Your Fan. pg. 2
Parts Inventory. pg. 2
Installation Preparation. pg. 3
Hanging Bracket Installation. pg. 3
Fan Assembly. pgs. 4 - 5
Wiring. pg. 6
Canopy Assembly. pg. 6
Blade Assembly. pg. 7
Switch Housing Assembly. pg. 7
Testing Your Fan. pg. 8
Troubleshooting. pg. 9
Parts Replacement. pg. 9
Warranty. pg. 9
PRINTED IN CHINA
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Craftmade ELLINGTON BLV54ABZ5
Summary of Contents for Craftmade ELLINGTON BLV54ABZ5
-
Page 1: Table Of Contents
READ THESE INSTRUCTIONS AND SAVE THEM FOR FUTURE USE Installation Guide For Model: BLV54ABZ5 Table of Contents: Safety Tips. pg. 1 Unpacking Your Fan. pg. 2 Parts Inventory. pg. 2 Installation Preparation. pg. 3 Hanging Bracket Installation. pg. 3 Fan Assembly. pgs. 4 - 5 Wiring. -
Page 2: Safety Tips
SAFETY TIPS. WARNING: To reduce the risk of electrical shock, turn off the electricity to the fan at the main fuse box or circuit panel before you begin the fan installation or before servicing the fan or installing accessories. READ ALL INSTRUCTIONS AND SAFETY INFORMATION CAREFULLY BEFORE INSTALLING YOUR FAN AND SAVE THESE INSTRUCTIONS. -
Page 3: Unpacking Your Fan
1. Unpacking Your Fan. Carefully open the packaging. Remove items from Styrofoam inserts. Remove motor housing and place on carpet or Styrofoam to avoid damage to finish. Do not discard fan carton or Styrofoam inserts should this fan need to be returned for repairs. -
Page 4: Installation Preparation
3. Installation Preparation. 3. Installation Preparation. blade edge To prevent personal injury and damage, ensure inches 7 feet that the hanging location allows the blades a (2.13m) (76cm) clearance of 7 feet (2.13m) from the floor and 30in. (76 cm) from any wall or obstruction. This fan is suitable for room sizes up to 400 square 12ft. -
Page 5: Fan Assembly. Pgs
5. Fan Assembly. set screw hole set screw If you wish to extend the hanging length of your fan, stop pin you must remove the hanging ball from the 6in. downrod provided to use with an extended downrod (sold separately). [If you wish to use the 6in. downrod, please proceed to instructions following the dotted line hanging ball below.]... - Page 6 5. Fan Assembly. (cont.) With the hanging bracket secured to the outlet safety cable loop box and able to support the fan, you are now wood ready to hang your fan. Grab the fan firmly with ceiling joist two hands. Slide downrod through opening in wood screw hanging bracket and let hanging ball rest on and washer...
-
Page 7: Wiring
6. Wiring. white supply wire CAUTION: Be sure outlet box is properly grounded ground (green or bare) and that a ground wire (GREEN or Bare) is present. black supply wire Make sure all electrical connections comply with from ceiling Local Codes or Ordinances and the National wire Electrical Code. -
Page 8: Blade Assembly
8. Blade Assembly. Time Saver: Washers for blade screws can be motor housing set on each blade screw prior to installing blades. blade attachment Locate 15 blade attachment screws and screws and washers washers in hardware pack. Hold blade arm up to blade and align holes. -
Page 9: Testing Your Fan
10. Testing Your Fan. It is recommended that you test fan before finalizing installation. Restore power from circuit box and light switch (if applicable). Test fan speeds with pull chain. (diagram 1) Start at the OFF position (no blade movement). First pull will set the fan to HI. -
Page 10: Troubleshooting
Return fan, shipping prepaid, to 2. Verify that reverse switch is set completely in Craftmade/Ellington. We will repair or ship you a either direction. replacement fan, and we will pay the return shipping cost.
