  • Page 1 GNSS Antenna AU-217 Installation Procedure (Document No. SE21-900-019-01) www.furuno.com...
  • Page 2 Any information of this documentation shall not be disclosed to any third party without permission of the publisher, FURUNO ELECTRIC CO., LTD. FURUNO ELECTRIC CO., LTD. reserves the right to make changes to its products and specifications without notice. All brand and product names are registered trademarks, trademarks or service marks of their respective...
  • Page 3 GNSS Antenna AU-217 Installation Procedure SE21-900-019-01 Safety Precautions ・Please read carefully before use. Be sure to follow these instructions. After reading this manual, be sure to keep it carefully. ・The precautions listed below are to prevent risk of harm to the user and others, as well as to prevent property damage.
  • Page 4 GNSS Antenna AU-217 Installation Procedure SE21-900-019-01 Revision History Version Contents Date First Release 2021.10.15 Add descriptions in (1) of chapter 3 2022.08.24 Add descriptions in (2) of chapter 3...
  • Page 5 GNSS Antenna AU-217 Installation Procedure SE21-900-019-01 Contents Propose ····················································································································· 1 Materials ···················································································································· 1 Installation Procedure ································································································· 2...
  • Page 6 GNSS Antenna AU-217 Installation Procedure SE21-900-019-01 1 Propose This document shows the installation procedure for the following GNSS antenna: AU-217. 2 Materials (1) GNSS Antenna: AU-217 (2) Pole mount adapter: PM-001 (Separately sold) Rough sketch Outline φ21.34 φ14.9 TAP M18-1 12MM DEEP...
  • Page 7 If the TNC connector does not pass through the hole of PM-001, consider using a conversion cable (NJ-TP-3DXV-1). (2) Connect the TNC(J) connector of the GNSS antenna AU-217 to the TNC(P) connector of the coaxial cable. Recommended torque values for the TNC connector are Imperial: 4.1 - 6.1 in-lbs | Metric: 0.46 - 0.69 Nm.
  • Page 8 Prop on the protruding part under the installing spacer (4) Fix the PM-001 with AU-217 attached to the prop. Use the CP-20-01111 installing spacer and two Hose clamps for fixing. The mounting prop that fits the hose clamp is φ25-70mm.
