Summary of Contents for Furuno GPA-014
- Page 1 GNSS Antenna GPA-014 Installation Procedure (Document No. SE21-900-020-00) www.furuno.com...
- Page 2 Any information of this documentation shall not be disclosed to any third party without permission of the publisher, FURUNO ELECTRIC CO., LTD. FURUNO ELECTRIC CO., LTD. reserves the right to make changes to its products and specifications without notice. All brand and product names are registered trademarks, trademarks or service marks of their respective...
- Page 3 GNSS Antenna GPA-014 Installation Procedure SE21-900-020-00 Safety precautions ・Please read carefully before use. Be sure to follow these instructions. After reading this manual, be sure to keep it carefully. ・The precautions listed below are to prevent risk of harm to the user and others, as well as to prevent property damage.
- Page 4 GNSS Antenna GPA-014 Installation Procedure SE21-900-020-00 Revision History Version Contents Date First Release 2021.10.15...
- Page 5 GNSS Antenna GPA-014 Installation Procedure SE21-900-020-00 Contents Propose ····················································································································· 1 Materials ···················································································································· 1 Installation Procedure ································································································· 2...
- Page 6 GNSS Antenna GPA-014 Installation Procedure SE21-900-020-00 1 Propose This document shows the installation procedure for the following GNSS antenna: GPA-014. 2 Materials (1) GNSS Antenna: GPA-014 (2) Mast mounting bracket: CP20-00403（Separately sold） Rough sketch Outline Installing Spacer Hose Clamp (DIMENSION IN DRAWING ARE FOR REFERENCE ONLY.）...
- Page 7 GNSS Antenna GPA-014 Installation Procedure SE21-900-020-00 3 Installation Procedure (1) Connect the BNC(P) connector of the antenna to the BNC(J) connector. ・Connect the connectors straight to each other and lock them so they do not come off Roll the self-bonding tape...
- Page 8 ・The mounting prop that fits the hose clamp is φ25-70mm. ・Place the installing spacer between the GPA-014 and the prop, and tighten with the hose clamp to fix it. ・The hose clamp becomes tightened by turning clockwise the red circle in the figure with a slotted screwdriver.
