TruVision TVPA-S01-1202-360-G Configuration Manual

360 camera
Hide thumbs Also See for TVPA-S01-1202-360-G:

Advertisement

Quick Links

TruVision 360° Camera
Configuration Manual
P/N 1093-EN • REV A • ISS 10FEB23

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TVPA-S01-1202-360-G and is the answer not in the manual?

Questions and answers

Summary of Contents for TruVision TVPA-S01-1202-360-G

  • Page 1 TruVision 360° Camera Configuration Manual P/N 1093-EN • REV A • ISS 10FEB23...
  • Page 2 Carrier, except where specifically permitted under US and international copyright law. Trademarks and TruVision names and logos are a product brand of Aritech, a part of Carrier. patents Other trade names used in this document may be trademarks or registered trademarks of the manufacturers or vendors of the respective products.
  • Page 3 2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed of as unsorted municipal waste in the European Union. For proper recycling, return this product to your local supplier upon the purchase of equivalent new equipment, or dispose of it at designated collection points.
  • Page 5: Table Of Contents

    Alarm inputs and outputs 52 Exception alarms 53 Audio exception detection 55 Intrusion detection 56 Cross line detection 58 Region entry detection 60 Region exiting detection 62 Unattended baggage detection 64 Object removal detection 66 TruVision 360° Camera Configuration Manual...
  • Page 6 Heat map statistics 88 Intersection analysis report 90 Camera operation 92 Log on and off 92 Live view mode 92 Play back recorded video 96 Snapshots 98 Search event logs 99 Operating PTZ control 101 Index 104 TruVision 360° Camera Configuration Manual...
  • Page 7: Important Information

    PRODUCTS), SOFTWARE, SERVICES OR OTHER OFFERINGS WILL NOT BE HACKED, COMPROMISED AND/OR CIRCUMVENTED. CARRIER DOES NOT ENCRYPT COMMUNICATIONS BETWEEN ITS ALARM OR OTHER CONTROL PANELS AND THEIR WIRELESS OUTPUTS/INPUTS INCLUDING BUT NOT LIMITED TO, SENSORS OR DETECTORS UNLESS REQUIRED BY TruVision 360° Camera Configuration Manual...
  • Page 8: Warranty Disclaimers

    CARRIER DOES NOT WARRANT THAT ANY PRODUCT (INCLUDING SECURITY PRODUCTS), SOFTWARE OR SERVICE MANUFACTURED, SOLD OR LICENSED BY CARRIER WILL PREVENT, OR IN ALL CASES PROVIDE ADEQUATE WARNING OF OR PROTECTION FROM, BREAK-INS, BURGLARY, ROBBERY, FIRE, OR OTHERWISE. TruVision 360° Camera Configuration Manual...
  • Page 9: Intended Use

    Note: Note messages advise you of the possible loss of time or effort. They describe how to avoid the loss. Notes are also used to point out important information that you should read. TruVision 360° Camera Configuration Manual...
  • Page 10: Introduction

    Introduction This is the configuration manual for the following TruVision IP camera models:  TVPA-S01-0601-360-G (TruVision 6MP 360° IP Dome, indoor)  TVPA-S01-1201-360-G (TruVision 12MP 360° IP Dome, indoor)  TVPA-S01-0602-360-G (TruVision 6MP 360° IP Dome, outdoor)  TVPA-S01-1202-360-G (TruVision 12MP 360° IP Dome, outdoor)
  • Page 11: Network Access

    This manual explains how to configure the camera over the network with a web browser. TruVision IP cameras can be configured and controlled using Microsoft Internet Explorer (IE) and other browsers. The procedures described use Microsoft Internet Explorer (IE) web browser.
  • Page 12: Activating The Camera

    There is no default password provided. You can activate a password via a web browser and via TruVision Device Manager. Warning: When the 360° camera is operating, the surface of the housing will be hot to the touch.
  • Page 13 To activate the camera via TruVision Device Manager: 1. Run TruVision Device Manager 9.1SP1 or newer to search for TruVision cameras on your local network. 2. After launching Device Manager, the number of inactive TruVision devices (unconfigured devices recently connected to the network) can be displayed by clicking the Activate Device button.
  • Page 14: Enabling Ie Mode In Microsoft Edge

    9. Type in the URL of the website you want to open in IE and press Enter. The website will open in a new tab within Edge, but it will be rendered using the IE engine. TruVision 360° Camera Configuration Manual...
  • Page 15: Overview Of The Camera Web Browser

    Help Click to find the function. Logout Click to log out from the system. This can be done at any time. Live view toolbar Click to manually capture the snapshot. Click to manually start/stop recording. TruVision 360° Camera Configuration Manual...
  • Page 16 They can be selected in both the Software, via IE or Edge browser in Internet Explorer compatibility mode, and Hardware tabs. There is a greater selection available for Software. Table 1: Description of the display control panel Name Description Mount Type Ceiling mount. Wall mount. Table mount. TruVision 360° Camera Configuration Manual...
  • Page 17 When the pan moves left, the real direction is right. When the pan moves right, the real direction is left. Some examples of the different software display modes: TruVision 360° Camera Configuration Manual...
  • Page 18 360° panoramic view Live view with one 360° view and eight PTZ views Live view with AR half-sphere view. Live view with a cylinder view Live view with one 360° view and three PTZ views TruVision 360° Camera Configuration Manual...
  • Page 19: Local Configuration

    MULTICAST: It’s recommended to select MCAST type when using the Multicast function. Live View Performance Set the live view performance to Shortest Delay, Auto, Fluent, or Custom. For Custom, you can set the frame rate for live view. TruVision 360° Camera Configuration Manual...
  • Page 20 Specifies the directory for saving snapshots in live view mode. View To Save Snapshots during Specifies the directory for saving snapshots in playback mode. Playback To Save Clips during Playback To Specifies the directory for saving video clips in playback mode. TruVision 360° Camera Configuration Manual...
  • Page 21: System Setup

    RS-485 serial port parameters, maintenance, and about the system. Basic information This menu displays the hardware and firmware-related information of the device. Only the device name and number values can be changed. TruVision 360° Camera Configuration Manual...
  • Page 22 Save 4. Click to save changes. Daylight savings time You can set up the start and end time of daylight-saving time (DST) in the year. DST is deactivated by default. TruVision 360° Camera Configuration Manual...
  • Page 23: Maintenance

    To reboot the camera through the web browser: 1. Under Camera Configuration > System, click the Maintenance tab. 2. Click the Reboot button to reboot the device. TruVision 360° Camera Configuration Manual...
  • Page 24 Only the new features are added with their default settings. The camera will select the corresponding firmware file automatically. Cookies and data in the web browser are automatically deleted when the firmware is updated. TruVision 360° Camera Configuration Manual...
  • Page 25 4. Click Upgrade. You will receive a prompt asking you to reboot the camera. 5. When the upgrade is finished, the device will reboot automatically. The browser will also be refreshed. To upgrade the firmware via TruVision Device Manager: 1. In the FW upgrade panel, select a device or hold the Ctrl or Shift key to select multiple devices for simultaneous upgrading.
  • Page 26: Security

    IP address and enter the address. Click Modify Delete to modify or delete the selected IP address. 3. Security service: Disable Live View Auto-logout Enable Failed Login Enable or disable the Lock. TruVision 360° Camera Configuration Manual...
  • Page 27: User Management

    Note: Keep the admin password in a safe place. If you forget it, please contact technical support.  Operator: This user can only change the configuration of his/her account. An operator cannot create or delete other users. TruVision 360° Camera Configuration Manual...
  • Page 28 4. Select the type of user from the drop-down list, User or Operator. 5. Assign the user a password. Passwords can have up to 16 alphanumeric characters. 6. Assign permissions to the user. Check the desired options: TruVision 360° Camera Configuration Manual...
  • Page 29 You can see who is currently accessing the camera online. Configuration Security User Management From the menu toolbar, click > > and then click the Online Users tab. The following user information is displayed: Username, Level, IP Address, and User Operating Time. TruVision 360° Camera Configuration Manual...
  • Page 30: Network Settings

    Mac Address: Enter the MAC address of the devices. MTU: Enter the valid value range of MTU. Default is 1500. Multicast Address: Enter a D-class IP address between 224.0.0.0 to 239.255.255.255. Only specify this option if you are using the multicast TruVision 360° Camera Configuration Manual...
  • Page 31 Alarm Host Port: Specifies the port of the alarm host. See page 28 for setup information. A NAT (Network Address Translation) is used for network connection. Select the port mapping mode: auto or manual. See page 28 for setup information. TruVision 360° Camera Configuration Manual...
  • Page 32 QoS (Quality of Service) can help solve network delay and network congestion by configuring the priority of data sending. Enable the option to solve network delay and network congestion by configuring the priority of data sending. See page 31 for setup information. TruVision 360° Camera Configuration Manual...
  • Page 33 NO-IP: Enter the address of the NO-IP, the hostname for your camera, the port number, your username, and your password. 4. Under Host Name Configuration, select Enable Dynamic and enter the Register Name. 5. Click Save to save changes. TruVision 360° Camera Configuration Manual...
  • Page 34 2. Select the corresponding version of SNMP: v1 or v2c. 3. Configure the SNMP settings. The configuration of the SNMP software should be the same as the settings you configure here. 4. Click Save to save changes. TruVision 360° Camera Configuration Manual...
  • Page 35 Select the checkbox of the Attached Image if you want to send emails with attached alarm images. Interval: This is the time between two actions of sending attached images. Select between 2 and 5 seconds. TruVision 360° Camera Configuration Manual...
  • Page 36 Advanced Settings > HTTPS. 1. Click > > 2. Select Enable HTTPS and allow HTTP to access the camera using HTTPS and HTPP. 3. Check Enable HTTPS Browsing to access the camera only via HTTPS protocol. TruVision 360° Camera Configuration Manual...
  • Page 37 ONVIF from this interface. Refer to ONVIF standard for detailed configuration rules. To set up the integration protocol parameters: Configuration Network Advanced Settings Integration Parameters. 1. Click > > > 2. Select the Enable STD-CGI check box to enable the STD-CGI protocol. TruVision 360° Camera Configuration Manual...
  • Page 38 Certificate verification is required to ensure secure access. • SDK Service and Enhanced SDK Service: Enable these functions to be able to use the device with a VMS (like TruVision Navigator or a third-party software using the SDK). SDK Service uses the SDK protocol.
  • Page 39 IP or hostname. 4. Enable to activate Automatic Network Replenishment to have the camera send buffered events to the alarm host after the network connection is restored. 5. Click Save to save changes. TruVision 360° Camera Configuration Manual...
  • Page 40: Video/Audio Settings

    Note: Resolutions can vary depending on the camera model. Bit Rate Control: Specifies whether a variable or fixed bit rate is used. Variable produces higher quality results suitable for video downloads and streaming. Default is Constant. TruVision 360° Camera Configuration Manual...
  • Page 41 ROI whereas the background information is less focused. Display Info. When Dual-VCA mode is enabled, the camera sends video analytics results On Stream (metadata) to an NVR or other platforms to generate a VCA alarm. TruVision 360° Camera Configuration Manual...
  • Page 42 NVR or other platforms to generate a VCA alarm. For example, with a TruVision NVR (please check our website for the latest NVR models supporting this feature), you can draw a virtual line in the NVR playback window and search for the objects or people crossing this virtual line.
  • Page 43 4. Select the cropping resolution for the video display of the target area. A red rectangle is displayed on the live video to mark the target area, and you can click and drag the rectangle to locate the target area as desired. 5. Click Save to save the settings. TruVision 360° Camera Configuration Manual...
  • Page 44: Camera Image Settings

    The camera automatically switches between day and night modes. All image settings remain the same for both modes. The image settings are Image Adjustment, Exposure Settings, Day/Night Switch, and Video Adjustment. Default: Only use default settings. TruVision 360° Camera Configuration Manual...
  • Page 45 On: The IR LEDs are ON when the camera changes to night mode. Off: The IR LEDs are OFF when the camera changes to night mode Note: The IR LEDs are always OFF in day mode. TruVision 360° Camera Configuration Manual...
  • Page 46 Select PAL 50 Hz or NTSC 60 Hz. Select the value depending on the video standards; normally 50 Hz for PAL standard and 60 Hz for NTSC standard. Note: Click the Default button to default all the image settings. TruVision 360° Camera Configuration Manual...
  • Page 47: Osd (On Screen Display)

    Not transparent & Not flashing. The image is behind the text. This is default. • Not transparent & Flashing. The image is behind the text. The text flashes on and off. 8. Select the desired OSD size. 9. Select the desired font color. TruVision 360° Camera Configuration Manual...
  • Page 48: Privacy Masks

    3. Click Draw Area. 4. Click and drag the mouse in the live video window to draw the mask area. Note: You are allowed to draw up to four areas on the same image. TruVision 360° Camera Configuration Manual...
  • Page 49: Picture Overlay

    5. Enter the X and Y coordinate values to adjust the picture position on the image. Enter the picture width and height values to obtain the desired size. 6. Click Save to save settings. Note: The picture must be in RGB24 bmp format and the size no larger than 128*128. TruVision 360° Camera Configuration Manual...
  • Page 50: Event Settings

    You can also enable dynamic analysis for motion. When there is motion, the area will be highlighted as green. TruVision 360° Camera Configuration Manual...
  • Page 51 Event Event Motion Detection. 1. Click > > Basic > 2. Select the Enable Motion Detection check box. Select the Enable Dynamic Analysis for Motion check box if you want to see real-time motion events. TruVision 360° Camera Configuration Manual...
  • Page 52 Save 9. Click to save changes. 10. Click the Actions tab. Specify the linkage method when an event occurs. Select one or more response methods for the system when a motion detection alarm is triggered. TruVision 360° Camera Configuration Manual...
  • Page 53 Note: Disable Local Configuration > Metadata Overlay if you do not want the detected objects displayed with the green rectangles. 3. Click the Area Settings tab. Under Configuration, select Advanced mode from the drop-down list. TruVision 360° Camera Configuration Manual...
  • Page 54 Save 10. Click to save the changes for that area. 11. Repeat steps 5 to 9 for each area to be defined. 12. Click the Arming Schedule tab. TruVision 360° Camera Configuration Manual...
  • Page 55 If you want to send the event snapshot together with the email, select the Attached Snapshot option. Notify Alarm Recipient Send an exception or alarm signal to remote management software when an event occurs. TruVision 360° Camera Configuration Manual...
  • Page 56 Trigger external alarm outputs when an event occurs. Select “A->1” alarm output. Note: This option is only available if the cameras support alarm output. Trigger Recording Triggers the recording to start in the camera. Select “A1”. Save 16. Click to save changes. TruVision 360° Camera Configuration Manual...
  • Page 57: Video Tampering

    Camera button to save a reference snapshot to download locally. Sensitivity 7. Move the slider to set the sensitivity of the detection. All areas will have the same sensitivity level. TruVision 360° Camera Configuration Manual...
  • Page 58: Alarm Inputs And Outputs

    If you want to send the event snapshot together with the Attached Snapshot email, select the option. Notify Alarm Recipient Send an exception or alarm signal to remote management software when an event occurs. TruVision 360° Camera Configuration Manual...
  • Page 59: Exception Alarms

    • Network Disconnected: Disconnected network cable. IP Address Conflicted: Conflict in IP address setting. • • Invalid Login: Wrong user ID or password used to log in to the cameras. TruVision 360° Camera Configuration Manual...
  • Page 60 Trigger Alarm Output Trigger external alarm outputs when an event occurs. Select “A->1” alarm output. Note: This option is only available if the cameras support alarm output. Save 4. Click to save changes. TruVision 360° Camera Configuration Manual...
  • Page 61: Audio Exception Detection

    Sound Intensity Threshold: Range [1-100], it can filter the sound in the environment. The louder the environment sounds, the higher the value needs to be. You can adjust it according to the real environment. You can view the real-time volume of the sound on screen. TruVision 360° Camera Configuration Manual...
  • Page 62: Intrusion Detection

    You can set up an area in the surveillance scene to detect when an intrusion occurs. Up to four intrusion detection areas are supported. If someone enters the area, a set of alarm actions can be triggered. TruVision 360° Camera Configuration Manual...
  • Page 63 The range is between 1 and 100. Example: If you set the value as 60, the action can only be counted as a region entrance action when at least 40% of the object enters the region. TruVision 360° Camera Configuration Manual...
  • Page 64: Cross Line Detection

    Up to four cross lines are supported. The cross line direction can be set as unidirectional or bidirectional. Unidirectional crossing is crossing the line from left to right or from right to left. Bidirectional crossing is crossing the line from both directions. TruVision 360° Camera Configuration Manual...
  • Page 65 The range is between 1 and 100. Example: If you set the value as 60, the action can only be counted as a region entrance action when at least 40% of the object enters the region. TruVision 360° Camera Configuration Manual...
  • Page 66: Region Entry Detection

    Region entry detection function detects objects which enter a pre-defined virtual region from the outside place, and certain actions can be taken when the alarm is triggered. To define region entrance detection: Configuration Event Smart Event Region Entrance Detection. 1. Click > > > TruVision 360° Camera Configuration Manual...
  • Page 67 8. Repeat the above steps to configure other regions. Up to four regions can be set. You can click the Clear button to clear all pre-defined regions. 9. Click the Arming Schedule tab to set the arming schedule. See “To set up motion detection” on page 44 for more information. TruVision 360° Camera Configuration Manual...
  • Page 68: Region Exiting Detection

    Region exiting detection function detects objects which exit from a pre-defined virtual region, and certain actions can be taken when the alarm is triggered. To define region exiting detection: 1. Click Configuration > Event > Smart Event > Region Exiting Detection. TruVision 360° Camera Configuration Manual...
  • Page 69 “To set up motion detection” on page 44 for more information. Actions 10. Click and select the linkage methods. Select one or more response methods for the system when a cross line detection alarm is triggered. TruVision 360° Camera Configuration Manual...
  • Page 70: Unattended Baggage Detection

    A series of actions can be configured to occur when the alarm is triggered. To define unattended baggage detection: 1. Click Configuration > Event > Smart Event > Unattended Baggage Detection. TruVision 360° Camera Configuration Manual...
  • Page 71 The range is between 1 and 100. Example: If you set the value as 60, the action can only be counted as a region entrance action when at least 40% of the object enters the region. TruVision 360° Camera Configuration Manual...
  • Page 72: Object Removal Detection

    To define object removal detection: 1. Click Configuration > Event > Smart Event > Object Removal Detection. TruVision 360° Camera Configuration Manual...
  • Page 73 The range is between 1 and 100. Example: If you set the value as 60, the action can only be counted as a region entrance action when at least 40% of the object enters the region. TruVision 360° Camera Configuration Manual...
  • Page 74 Trigger external alarm outputs when an event occurs. Select “Select All” or each alarm output. Note: This option is only supported by cameras that support alarm output. Trigger Recording Triggers the recording to start in the camera. 13. Click Save to save the settings. TruVision 360° Camera Configuration Manual...
  • Page 75 > > 2. Click the Record Schedule tab and select the Enable check box to enable scheduled recording. 3. Set up the recording schedule. Select the desired record type to record from the drop-down list: TruVision 360° Camera Configuration Manual...
  • Page 76 5 seconds, the camera starts to record at 9:59:55. The pre- record time can be configured as No Pre-record, 5 s, 10 s, 15 s, 20 s, 25 s, 30 s, or Not Limited. TruVision 360° Camera Configuration Manual...
  • Page 77 Network > FTP tab for motion detection or alarm input, the snapshots will not be uploaded to the FTP if this option is disabled. To set up the schedule for snapshots: 1. From the menu toolbar, click Configuration > Storage > Schedule Settings > Snapshot > Snapshot Schedule. TruVision 360° Camera Configuration Manual...
  • Page 78 Save 5. Click to save changes. To set up the snapshot parameters: 1. From the menu toolbar, click Configuration > Storage > Schedule Settings > Snapshot Snapshot Schedule. > TruVision 360° Camera Configuration Manual...
  • Page 79 HDD of the NAS and the Memory card in the camera. You can also format these storage devices. Before formatting the storage device, stop all recordings. Once formatting is completed, reboot the camera otherwise the device will not function properly. TruVision 360° Camera Configuration Manual...
  • Page 80 To configure record settings, please ensure that you have the network storage device within the network. The NAS disk should be available within the network and correctly configured to store the recorded files, log files, etc. TruVision 360° Camera Configuration Manual...
  • Page 81 There are two metrics displayed about the card: Remaining Lifespan: Shows the remaining lifespan of the card. A card’s lifespan is influenced by several factors, such as its capacity and bitrate. Change the card if the remaining lifespan is inadequate. TruVision 360° Camera Configuration Manual...
  • Page 82 See “To set up motion detection” on page 44 for more information. Actions 3. Click the tab and select the linkage methods for the notification. 4. Click Save to save the settings. TruVision 360° Camera Configuration Manual...
  • Page 83 4. Set the detection line. Draw a detection line on the live video to detect and count the objects entering or exiting across the line. TruVision 360° Camera Configuration Manual...
  • Page 84 Save to save the settings. B. Arming schedule: Rule Arming Schedule 1. Under the submenu, click to edit the arming schedule. 2. Click on the time bar and drag the mouse to select the period. TruVision 360° Camera Configuration Manual...
  • Page 85 • You can upload people counting data to alarm recipient and client software through SDK and HTTP (if configured). To upload real-time data, select the Real-Time Upload Data check box. TruVision 360° Camera Configuration Manual...
  • Page 86 It displays real-time flow information on screen. You can select the displayed data type from the drop-down list: Enter, Leave, Enter/Leave, None. • Daily Reset Time You can set up a daily reset time or you can reset the counter manually by clicking Manual Reset. TruVision 360° Camera Configuration Manual...
  • Page 87 Max. Size: The maximum size of a valid target. Targets larger than this will not trigger detection. Min. Size: The minimum size of a valid target. Targets smaller than this will not trigger detection. TruVision 360° Camera Configuration Manual...
  • Page 88 8. Under the Actions tab, select the Linkage Method by enabling Notify the surveillance center if required. Shield Region, 9. Under the submenu draw a shielded area in which no heat map analysis will be done. TruVision 360° Camera Configuration Manual...
  • Page 89 Note: Shielded areas cannot be drawn if the live view stops. 10. Click Save to save the settings. Note: The heat map statistics are calculated under the Application tab. Go to Application to check the heat map statistics. TruVision 360° Camera Configuration Manual...
  • Page 90 (see page 29 for information on setting up email addresses). 4. Go to the Arming Schedule tab and click and drag the mouse on the time bar to set the arming schedule. TruVision 360° Camera Configuration Manual...
  • Page 91 5. Under the Actions tab, enable Notify Alarm Recipient if required. 6. Click Save to save the settings. Note: The intersection analysis statistics are calculated in the Application tab. Go to Application to check the reports. TruVision 360° Camera Configuration Manual...
  • Page 92 • The monthly report calculates the month in which your selected date belongs. • The annual report calculates the year in which your selected date belongs. Statistics Type: People Entered or People Exited. 3. Select the 4. Select the Start Time and then click Search. TruVision 360° Camera Configuration Manual...
  • Page 93 Line Chart to display the result in different ways. Example of the list format: Example of a bar chart: Example of a line chart: Note: If you select Table to display the statistics, click the Export button to export TruVision 360° Camera Configuration Manual...
  • Page 94 The closer the color is to the red end of the color scheme, the higher the number of visits. The duration displayed next to “High” or “Low” stands for the cumulative time of visit frequency for that area. TruVision 360° Camera Configuration Manual...
  • Page 95 Figure 16: Example of a time heat map weekly report Note: It is recommended that you do not adjust the electronic lens after the installation is completed as this may cause some inaccuracy to the data. TruVision 360° Camera Configuration Manual...
  • Page 96 Before you start: You need to configure the Intersection Analysis setting before you can view and download the intersection analysis data from the application tab. Refer to the section “Intersection analysis” on page 84 for detailed information. TruVision 360° Camera Configuration Manual...
  • Page 97 • The monthly report calculates the month in which your selected date belongs. • The annual report calculates the year in which your selected date belongs. Statistics Time 4. Select the for the dates during which you want the analysis done. 5. Click Search to start calculating. TruVision 360° Camera Configuration Manual...
  • Page 98 On the upper left corner of the login window, you can select the language of the Browser. It supports several languages. Figure 18: Login dialog box Live view mode Once logged in, click “Live View” on the menu toolbar to access live view mode. See Figure 19 below. TruVision 360° Camera Configuration Manual...
  • Page 99 Click to select the desired aspect ratio of the window: 1:1, 4:3, 16:9, Original, Auto. Display control. See Table 2 on page 94 for further information. PTZ control. See “Operating PTZ control” on page 101 for further information. TruVision 360° Camera Configuration Manual...
  • Page 100 Live view with one 360° view and three PTZ views. Live view with one 360° view and eight PTZ views. Live view with sphere view. Live view with AR half-sphere view. Live view with a cylinder view. TruVision 360° Camera Configuration Manual...
  • Page 101 When the pan moves right, the real direction is left. Some examples of the different software display modes: 180° panoramic view 360° panoramic view Live view with one 360° view and eight PTZ views Live view with AR half-sphere view. TruVision 360° Camera Configuration Manual...
  • Page 102 Start search. Timeline The timeline bar displays the 24 hours of the day being played back. It moves from left (oldest) to right (newest). The bar is color- coded to display the type of recording. TruVision 360° Camera Configuration Manual...
  • Page 103 1. While playing back a recorded file, click to start clipping. Click it again to stop clipping. A video segment is created. 2. Repeat step 1 to create additional segments. The video segments are saved on your computer. TruVision 360° Camera Configuration Manual...
  • Page 104 Make sure that the HDD, NAS, or memory card is properly configured before you carry out the snapshot search. • Make sure that the capture schedule is configured. Go to Configuration > Storage > Snapshot to set the capture schedule. Figure 25: Picture window TruVision 360° Camera Configuration Manual...
  • Page 105 Information. You can also search all logs. See Table 3 below for their descriptions. Minor type: Each major type has some minor types. See Table 3 below for their descriptions. Date and Time: Logs can be searched by start and end recording time. TruVision 360° Camera Configuration Manual...
  • Page 106 Migrate Cluster Business, NAS Information, Network Camera Connection Status, Start Capture, Start Cluster Management Service, Start Record, Stop Capture, Stop Record, System Running State, Time Sync, IPC Connection To search logs: 1. From the menu toolbar, click to display the Log window. TruVision 360° Camera Configuration Manual...
  • Page 107 A preset tour is a memorized series of presets. The camera stays at a preset for a set dwell time before moving on to the next preset. A preset tour can be configured with up to 32 presets. TruVision 360° Camera Configuration Manual...
  • Page 108 Note: Up to 32 patrol paths can be set, and each path supports up to 16 key points. To call up a preset tour: 1. Click to show the PTZ control panel. 2. Select the preset tour path number from the drop-down list. TruVision 360° Camera Configuration Manual...
  • Page 109 To delete a preset tour: 1. Select the preset tour path number from the preset tour list. 2. Click the icon to delete the selected preset tour path. TruVision 360° Camera Configuration Manual...
  • Page 110 53 detection IP address conflicted alarm, 53 audio exception, 55 cross line, 58 intrusion, 56 object removal, 66 language region entrance, 60 change, 92 region exiting, 62 live view unattended baggage, 64 start, 92 TruVision 360° Camera Configuration Manual...
  • Page 111 42 video parameters, 34 PTZ control, 101 video quality, 38 web browser setup, 31 overview of the interface, 9 web browser security level, 5 WebSocket/WebSockets, 32 white balance, 40 reboot camera, 17 record playback, 96 TruVision 360° Camera Configuration Manual...
