Remote Control - Home Decorators Collection Smart Roller Shade Use And Care Manual

Remote Control

Pair your remote with your smart shade
①
② ⑥
③
④ ⑦
⑤
⑧
Entering Pairing / Setting Mode
①
Long press the motor [Up] [Down] key for 3 seconds, motor will
jitter and LED indicator will long light
②
Press the channel setting button on back of the remote control,
shade will jig and motor LED will flash 4 times, indicating the
pairing is completed. The motor LED will go out.
Removing Existing Pairing
Long press motor [up] & [down] button together for 10 seconds.
Motor will jitter, motor LED will go out, all existing remote control
pairings will be wiped on motor.
⑨
3S
7S
Part Description
①
LED Light
②
Left Channel Select
③
Up/Open
④
Up tilt/75%position
⑤
Down/Close
⑥
Right Channel Select
⑦
Down tilt/25% position
⑧
Stop/Horizontal 50% position
⑨
Channel setting
NOTE:
1.Before using remote control, each remote must be paired
with motor
2.Each motor can record up to 16 remote control channels.
Reversing Roll Direction
(only needed for over-the-roll direction shade install)
①
Long press the motor [up] [Down] key for 3 seconds to enter the
learning / pairing state. Motor will jitter and the LED will be long lit.
②
Hold the [channel left selection]+[Stop] button simultaneously. After
the signal has been received, the motor will shake once and the
motor LED will blink 3 times.
6
