Installation

1 Mount your brackets
Inside Mount
Outside Mount
2 Mount your shade
Outside Mount
Inside Mount
1. Insert the motor end of shade into Bracket [B], then press and insert the spring-loaded pin end of shade into Bracket [A]. The front of
motor interface should face towards you.
2. Slide on the bracket covers.
3 Assemble the Shade
Slide plastic slat through the hem.
Installation of the shade is now complete.
A B
(Remove Bracket Covers)
5
Brackets are universal and can be used for mounting both inside and
outside the window frame (shade is only suitable for use indoors). It
is important to remove bracket covers [C & Cʼ] to ease the mounting
process. Brackets are labeled A and B.
1. Measure and mark the location for the brackets.
2. For default (under-roll), install Bracket A on the left and Bracket
B on the right. For extra clearance (over-roll), install Bracket B
on the left and Bracket A on the right.
NOTE: The shade is set up by default for under-roll
installation. Forover-roll installation, the motor direction
will need to be reversed. Refer to remote control
instruction manual for more details.
(Front of Motor Interface)
Please contact 1-877-592-5233 for further assistance.
Siwtch
Up button
Type-C 5V / 1A charging port
Down button
