4-7. Volt-Ampere Curves

A Stick
100
80
MAX
60
40
MIN
20
0
0 100
B TIG
100
MAX
80
60
40
MIN
20
0
0 100
C MIG
100
80
60
MAX
40
20
MIN
0
0 100
.
Complete Parts List available at www.MillerWelds.com
200 300 400
DC AMPERES
200 300 400
DC AMPERES
200 300 400
DC AMPERES
The volt-ampere curves show the
minimum and maximum voltage
and amperage output capabilities of
the welder/generator. Curves of
other settings fall between the
curves shown.
500
500
500
269 547-A
OM-269114 Page 21
