- Page 1 RTL8852B User’s Manual (RTL8852B) 11ax RTL8852B M.2 1216 Combo module User’s Manual Preliminary Version 2021/05/13 Realtek Semiconductor Corp. No. 2, Innovation Road II, Hsinchu Science Park, Hsinchu 300, Taiwan Tel.: +886-3-578-0211. Fax: +886-3-577-6047 www.realtek.com...
-
Page 2: Table Of Contents
RTL8852B User’s Manual ONTENT ENVIRONMENTAL .......................... 3 ............................3 PERATING ..............................3 TORAGE MTBF ..........................3 CACULATION WARNING ............................4 Federal Communication Commission Interference Statement ...... 4 ......................11 NDUSTRY ANADA TATEMENT NCC 警語 ....................11... -
Page 3: Environmental
RTL8852B User’s Manual ENVIRONMENTAL Operating Operating Temperature: -20°C to +70 °C Relative Humidity: 5-90% (non-condensing) Storage Temperature: -40°C to +80°C (non-operating) Relevant Humidity: 5-95% (non-condensing) MTBF caculation Over 150,000hours... -
Page 4: Warning
RTL8852B User’s Manual Warning Federal Communication Commission Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. - Page 5 RTL8852B User’s Manual 15.407 of the FCC Rules. Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.
- Page 6 RTL8852B User’s Manual same type with equal or lower gain may also be used with this module. The antenna must be installed such that 20 cm can be maintained between the antenna and users. 2.8 Label and compliance information The final end product must be labeled in a visible area with the following: “Contains FCC ID:...
- Page 7 RTL8852B User’s Manual Manual Information To the End User The OEM integrator has to be aware not to provide information to the end user regarding how to install or remove this RF module in the user’s manual of the end product which integrates this module.
- Page 8 RTL8852B User’s Manual utilisé à plus de 20 cm entre le radiateur et votre corps. This device is intended only for OEM integrators under the following conditions: (For module device use) 1) The antenna must be installed and operated with greater than 20cm between the...
- Page 9 être installée et utilisée à plus de 20 cm entre l’antenne et les utilisateurs. Le produit final doit être étiqueté dans un endroit visible avec l'inscription suivante: "Contient des IC: 6317A-RTL8852B ". Manual Information To the End User The OEM integrator has to be aware not to provide information to the end user regarding how to install or remove this RF module in the user’s manual of the end...
- Page 10 Le présent émetteur radio [IC: 6317A-RTL8852B] a été approuvé par Innovation, Sciences et Développement économique Canada pour fonctionner avec les types...
-
Page 11: Industry Canada Statement
RTL8852B User’s Manual d'antenne non inclus dans cette liste, et dont le gain est supérieur au gain maximal indiqué pour tout type figurant sur la liste, sont strictement interdits pour l'exploitation de l'émetteur. NCC Statement 取得審驗證明之低功率射頻器材，非經核准，公司、商號或使用者均不得擅自變 更頻率、加大功率或變更原設計之特性及功能。 低功率射頻器材之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象 時，應立即停用，並改善至無干擾時方得繼續使用。前述合法通信，指依電信管 理法規定作業之無線電通信。低功率射頻器材須忍受合法通信或工業、科學及醫... - Page 12 RTL8852B User’s Manual This device complies with Directive 2014/53/EU and UK Radio Equipment Regulations 2017 SI 2017/1206. issued by the Commission of the European Community. - Declaration of Conformity...
- Page 13 RTL8852B User’s Manual The frequency and maximum transmitted power in EU are listed as belows, - WLAN 5GHz: Operations in the 5.15-5.35GHz band are restricted to indoor usage only.
- Page 14 RTL8852B User’s Manual Installing the Wireless NGFF module Hardware Installing PCIe NGFF2230 module to PCIe NGFF2230 connector and connect two external Wi-Fi antennas on I-PEX connectors.
- Page 15 RTL8852B User’s Manual Un-installing the Wireless NGFF module Hardware Remove 2 external Wi-Fi Antennas from the Wireless PCIe NGFF2230 module board and remove the Wireless PCIe NGFF2230 module board from PCIe NGFF2230 connector port...
- Page 16 RTL8852B User’s Manual Installing the WLAN & Bluetooth USB NGFF module Software Before you proceed with the installation, please notice following descriptions. Note1: The following installation was operated under Windows 7. Note2: If you have installed the WLAN driver & utility before, please uninstall the old version first.
- Page 17 RTL8852B User’s Manual C. Click “Next” button. D. Select “Complete” and click “Next” button.
- Page 18 RTL8852B User’s Manual E. Click “Install” button. F. Click “Finish” button.
- Page 19 RTL8852B User’s Manual G. Please click “下一步”to continue. H. Please click “下一步”to continue.
- Page 20 RTL8852B User’s Manual I. Please click “安装”to start installation. J. Please click “完成”to finish the installation.
- Page 21 Un-installing the Wireless NGFF module Software A. Uninstall the RTL8852BE WLAN Driver from “Start”→ “Control Panel”→ “Programs” Please select items as below and click “Uninstall” to remove RTL8852BE WLAN, BT driver and MP UI.
