RTL8763B Series
RTL8763BM, RTL8763BF, RTL8763BFR, RTL8763BS, RTL8763BA
BLUETOOTH 5 DUAL MODE SOC
PRELIMINARY DATASHEET
(CONFIDENTIAL: Development Partners Only)
Realtek Semiconductor Corp.
No. 2, Innovation Road II, Hsinchu Science Park, Hsinchu 300, Taiwan
Tel.: +886-3-578-0211. Fax: +886-3-577-6047
www.realtek.com
th
7
, December 2017
Track ID: JATR-8275-15
Rev. 0.93
Advertisement
Table of Contents
Related Manuals for Realtek RTL8763B Series
Summary of Contents for Realtek RTL8763B Series
- Page 1 RTL8763B Series RTL8763BM, RTL8763BF, RTL8763BFR, RTL8763BS, RTL8763BA BLUETOOTH 5 DUAL MODE SOC PRELIMINARY DATASHEET (CONFIDENTIAL: Development Partners Only) Rev. 0.93 , December 2017 Track ID: JATR-8275-15 Realtek Semiconductor Corp. No. 2, Innovation Road II, Hsinchu Science Park, Hsinchu 300, Taiwan Tel.: +886-3-578-0211.
- Page 2 Realtek’s new generation of audio solutions. These complete total solutions provide a fast and highly reliable development path with a very competitive R-BOM.
- Page 3 Wi-Fi Supports USB type-C audio Baseband Features Supports iAP2 40MHz main clock Realtek’s latest RCV (Real Clear Voice) technology for narrowband and wideband Supports serial flash for FW storage and voice connection, including wind noise parameter upgrade reduction...
- Page 4 96kHz are supported. capacitor for clock offset digital tuning (0~20pF), could save 2-compensation CL cap Built-in MIC bias generator following Realtek design guidelines Digital Audio Interface Supports two PDM digital MIC inputs 32-bit ARM Cortex-M4F Processor Supports 24-bit, 192kHz on I2S digital audio...
- Page 5 RTL8763B Series Datasheet Preliminary Dual switching mode regulator for digital core, Operating Condition radio and audio codec respectively Operating voltage: 2.8V to 4.35V (VBAT) Built-in LDO for the I/O and FLASH memory Temperature range: -40°C to +85°C Built-in Li-Ion battery charger with up to...
- Page 6 Realtek RTL8763B Bluetooth RF Test Tool RTLBTAPP User Manual Draft v0.2 2017/08/8...
-
Page 7: Revision History
Revision History Date Version 2017/07/11 Draft v0.1 Initial 2017/08/08 Draft v0.1 Add BLE DTM Test... - Page 8 Catalog Revision History ..........2 Figure List ............4 Overview ......................5 Files........................6 Hardware environment ..................6 Open RTLBTAPP....................7 DUT (Link) Test Mode ..................9 LE DUT TX/RX Test(MP) ................10 BLE Direct Test Mode ..................11 Appendix :FCC /IC /NCC Statement...
- Page 9 Figure List Figure 1 File List ............................6 Figure 2 Open BTLBTAPP ........................7 Figure 3 Check COM port number ......................8 Figure 4 Device opens successfully ....................... 8 Figure 5 Enter link test mode ........................ 9 Figure 6 LE Test............................10 Figure 7 Reference EVB board define ....................11 Figure 8 Connect to instrument by uart interface ................11 Figure 9 Connect to instrument for RS232 interface.................12...
- Page 10 Overview This document is used to introduce RF test tool “RTLBTAPP” for Realtek Bluetooth chip RTL8763B series. Customers should comply with the steps and requirements under this document. Contact Realtek Bluetooth FAE if any problem arises in RF test flow.
- Page 11 Files MP tool package is provided to customers in binary format: RTLBTAPP.exe MP executable file RtlBluetoothMP.dll MP dll library Figure 1 File List Double click “RTLBTAPP.exe” to open this tool. However, please use “Run Administrator” to open it in Vista/Windows7 or higher. Hardware environment Before use this tool, PC should direct connected UART port.
- Page 12 Open RTLBTAPP Figure 2 Open BTLBTAPP Step 1: Select correct interface. UART: If the module interface is UART, please select “UART” and check COM port number in Device Manager.
- Page 13 Figure 3 Check COM port number Step 2: Click “Open”. After clicking “Open” button, the up left corner changes to green means it is successful to open BT Device. Figure 4 Device opens successfully...
- Page 14 DUT (Link) Test Mode Figure 5 Enter link test mode Enter link test mode, please follow the below operations. Step 1: Click “HCI Reset” button to reset. Step 2: Click “Test Mode” button to enter DUT Test Mode (link test mode). ...
- Page 15 LE DUT TX/RX Test(MP) Figure 6 LE Test Step 1: Choose “LE Test”. Step 2: Choose “LE PKT TX” or “LE PKT RX” Step 3: Choose LE Test Parameters : (a) Channel :0~39. (b) Data length:0~0xFF (c) PayType: PRBS9, 1111_0000, 1010, PRBS15, ALL1, ALL0, 0000_1111, 0101 (d) PHY: LE 1M PHY, LE 2M PHY, LE Coded PHY with S=8, LE Coded PHY with S=2...
- Page 16 This Direct Test Mode MODE requires a direct connection to the Bluetooth measurement instrument.The Realtek Bluetooth Device uses the HCI UARTt interface to connect to the Bluetooth measurement instrument. Realtek defines the uart pin as shown in the table below: Interface Name...
- Page 17 if Bluetooth measurement instrument interface is RS232, Level shift is required also . Figure 9 Connect to instrument for RS232 interface if Bluetooth measurement instrument interface has support USB converter UART board, such as FTDI USB converter board. Figure 10 Connect to instrument for usb to uart converter boar ...
- Page 18 8. Appendix FCC Statement: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 19 FCC Label Instructions The outside of final products that contains this module device must display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains Transmitter Module FCC ID: TX2-RTL8763BA” or “Contains FCC ID: TX2-RTL8763BA.”...
- Page 20 IC Statement This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
- Page 21 Taiwan requlatory information(NCC) 低功率電波輻射性電機管理辦法 第十二條 經型式認證合格之低功率射頻電機，非經許可，公司、 商號或使用者均不得擅自變更頻率、加大功率或變更原設計 之特性及功能。 第十四條 低功率射頻電機之使用不得影響飛航安全及干擾合法通 信；經發現有干擾現象時，應立即停用，並改善至無干擾時 方得繼續使用。 前項合法通信，指依電信法規定作業之無線電通信。 低功率射頻電機須忍受合法通信或工業、科學及醫療用電波 輻射性電機設備之干擾。...
