- Page 1 Scion Tech SC03.4200 User Manual 4:1 HDMI Switch, 18Gbps, 4K/60Hz, CAT6 Output User Manual Version 1.0 www.scion-tech.co.uk sales@scion-tech.co.uk Tel: +44 (0) 1635 226450...
-
Page 2: Table Of Contents
Scion Tech SC03.4200 User Manual Thank you for purchasing this product For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. Surge protection device recommended This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shock, lighting strikes, etc. -
Page 3: Introduction
● ARC (audio return channel) ● Control: Front panel, IR control, RS232 and TCP/IP Web GUI 3.0 Package contents 1. 1 x Main Unit (SC03.4200) 2. 1 x Power Adaptor 24V/1A 3. 1 x IR Remote 4. 2 x IR Transmitter Cable 5. -
Page 4: Specifications
Scion Tech SC03.4200 User Manual 4.0 Specifications Connectivity Inputs: 2 x HDMI Type A, 19-Pin Female, 1 x Type-C, 1 x VGA PC Audio Input: 1 x 3.5mm Stereo Jack Socket HDMI Audio Input: 1 x 3.5mm Stereo Jack Socket... -
Page 5: Panel Control And Connections
Scion Tech SC03.4200 User Manual 5.0 Panel Control & Connections 5.1 Front Panel SCION 18Gbps 4:1 HDMI Switch MENU ENTER www.scion-tech.co.uk Number Name Function / Description Switch status and function display Function Button Up, Down, Left and Right Function Button Menu and Enter... -
Page 6: Rear Panel
Scion Tech Scion Tech SC04.MX44+ SC03.4200 User Manual User Manual 5.2 Rear Panel Control Audio In RS232 IR-Out Audio Out HDMI IR-In IR-EXT SPDIF Out HDBT/PoC MIC In Ethernet DC/24V Type C-1 HDMI-3 HDMI-4 Line HDMI PC-2 Inputs Outputs Number... -
Page 7: Led Menu
Scion Tech SC03.4200 User Manual 7.0 LCD Menu Menu functions include Video Set, Audio Set, EDID Set, MIC input Volume Set, Analogue Output Volume Set, IP Query, UART Query, Reset. Press any button to activate the LCD screen, if no action is taken the screen turns off after 20 seconds. -
Page 8: Edid Set
Scion Tech SC03.4200 User Manual 7.3 EDID Set Select “EDID SET” and press the “ENTER” to confirm. Press “LEFT/RIGHT” arrow buttons to select the current input signal. Press the “ENTER” button again to return to the main menu. Supports 4K/60 (Default), 1080p (Default), Copy HDMI and Copy HDBaseT. -
Page 9: Ip Query
Scion Tech SC03.4200 User Manual 7.6 IP QUERY The default IP address is 192.168.1.168, DHCP is off. Use the “LEFT/RIGHT” buttons to select DHCP status, then press “ENTER” to confirm to back up one level. >> IP QUERY 192 . 168 . 1 . 168 DHCP: OFF 7.7 UART QUERY... -
Page 10: Pc Application Software
Scion Tech SC03.4200 User Manual 8.0 PC Application a. Install the “swe01b_4-Input HDMI Switcher.exe” software on your computer. b. Connect the switch to your computer using the USB to RS232 cable supplied. c. Press the “Search” button to find the correct COM port then click “Open Port”. -
Page 11: Control Interface
Scion Tech SC03.4200 User Manual 8.2 Control Interface Control Network Video Input TYPEC HDMI 1 HDMI 2 EDID Mode 4K60 1080P HDMI HDBT Audio Input HDMI Analogue Mute Analogue Output Setting Factory 1) Video Input: Switch Type-C, VGA, HDMI (1) and HDMI (2). -
Page 12: Network Interface
Scion Tech SC03.4200 User Manual 8.3 Network Interface Control Network Network INFO MAC Address: 192 . 168 . 1 . 168 IP Address: 255 . 255 . 255 . 0 Net Mask Address: 192 . 168 . 1 . 1... -
Page 13: Preparing Your Pc's Ip Address
Scion Tech SC03.4200 User Manual 9.0 Web Browser GUI To access the Web interface enter the matrix IP address in to your web browser address bar. The default IP address is 192.168.1.168 Note: If the IP address is unknown, use the RS232 interface command in section (r ip addr!) to discover the current IP settings or reset the matrix to it’s factory default settings. -
Page 14: Web Gui
Scion Tech SC03.4200 User Manual 10.0 Web Browser GUI Control 1. Enter the default IP Address (192.168.1.168) into the Web Browser 2. The following GUI will appear. Please see PC Application section for details. Control Network Video Input TYPEC HDMI 1... -
Page 15: Application Drawing
Scion Tech SC03.4200 User Manual 11.0 Application Drawing Speakers IR Extender Ethernet Web Browser Control IR Blaster Power Supply RS232 Panel Radio / Player Control Audio In RS232 Audio Out IR-Out HDMI IR-In IR-EXT SPDIF Out MIC In Ethernet HDBT/PoC... -
Page 16: Maintenance And Warranty
Scion Tech SC03.4200 User Manual 12.0 Maintenance Clean this unit with a soft, dry cloth. Never use alcohol, pint thinner of benzene to clean these devices. Servicing Damage requiring service: This product should be serviced by a qualified service engineer if: ●... - Page 17 Scion Tech SC03.4200 User Manual Limited warranty limits and exclusions This Limited Warranty ONLY COVERS failures due to defects in materials or workmanship, and DOES NOT COVER normal wear and tear or cosmetic damage. The Limited Warranty ALSO DOES NOT COVER damages...
