Operating Instructions
PRO-6000B
CAT5 Television Distribution System
- 1 -
Scion-Tech Ltd
2
3
4
7
8
12
13
14
Scion Tech Ltd
Advertisement
Related Manuals for Scion-Tech PRO-6000B Series
Summary of Contents for Scion-Tech PRO-6000B Series
-
Page 1: Table Of Contents
PRO-6000B Series Operating Manual Scion-Tech Ltd Operating Instructions PRO-6000B CAT5 Television Distribution System Table of Contents Product and Contents ---------------------------------- Important Information and Safety ------------------- Connecting Media Devices --------------------------- Connecting Receivers ---------------------------------- Software -------------------------------------------------- Changing Default Inputs ------------------------------ Specifications ------------------------------------------- Troubleshooting and Support ------------------------- Issue 1.1V –... -
Page 2: Product And Contents
PRO-6000B Series Operating Manual Product and Contents Included accessories Accessory Item PRO-6000B CAT5 Television Distribution Hub PRO-0202 12V 2.5amp Mains Adapter PRO-0209 Single IR Blink Emitter PRO-0203 RS232 Interface Cable CD-ROM Server Software ) Issue 1.1V – 17/06/2008 - 2 -... -
Page 3: Important Information And Safety
PRO-6000B Series Operating Manual Important Information Environment Private households This symbol on the products and/or Do not use this product near water. accompanying documents means that This product should be kept away used electrical and electronic products from heat sources such as radiators, should not be mixed with general cookers etc. -
Page 4: Connecting Media Devices
PRO-6000B Series Operating Manual Getting Started Once mounted and secured in your chosen location, power should be applied using the 12 volt mains adaptor supplied. Whe the unit is first switch on the green LED’s will illuminate to indicate power to each port, the amber LED’s will illuminate one at a time starting with port one. - Page 5 PRO-6000B Series Operating Manual Connecting IR Emitters Two 3.5mm jack sockets are provided on the front panel for connecting two Scion PRO- 0209 Single IR emitter. These are generally used to control the four media devices connected to inputs 6 – 9.
- Page 6 PRO-6000B Series Operating Manual PRO-6000B Input Connections DC Power 12Volt dc @ 2.5amp RS232 Interface (IN) 9-way D Socket, (OUT) 9-way D Plug Auxiliary 2 x J45 Sockets Video Inputs 9 x RCA Phono Sockets Left/Mono Audio 9 x RCA Phono Sockets...
-
Page 7: Connecting Receivers
PRO-6000B Series Operating Manual PRO-6001/6004 Receiver The RJ45 LED indicators illuminate when connection is made indicating power to the receiver. Unlike the PRO-6000B, both LED’s will illuminate if a good connection is made. In the event of a faulty CAT5 cable both LED’s will pulse until the cable is removed. -
Page 8: Software
PRO-6000B Series Operating Manual Software The PRO-6000B server software provides functions for configuring Channel and user names during installation channel baring and forcing. Installation your PRO-6000B Software Insert the PRO-1000 INSTALLATION CD-ROM into your CD-ROM drive. ® In the Windows taskbar, click Start. - Page 9 PRO-1000 16 x 16 Switch PRO-6000B Series Operating Manual Bar a room from individual channels Click the “Bar” icon. If the “Force” icon was previously selected, the “Bar” icon will change colour to red. Click the “Bar” icon again, the icon will now change to violet.
- Page 10 PRO-6000B Series Operating Manual Clearing forced channels Click the “Force” icon. If the “Bar” icon was previously selected, the “Force” icon will change colour to orange. Click the “Force” icon again, the icon will now change to yellow. Click the “Clear” icon under the room you wish to clear. The “selection” icon will change to blue.
- Page 11 PRO-6000B Series Operating Manual Cut, Copy and Paste your Configurations The Cut Copy and Paste options from the Edit menu may be used to modify the configuration. To copy a viewer’s settings to another viewer, click on either the Bar button or Force button to highlight it.
-
Page 12: Changing Default Inputs
PRO-6000B Series Operating Manual Changing default inputs The signal inputs of the PRO-6000B cab be changed to suite specific installations, making the IR handset more user friendly. For example. Should you choose not to use inputs 1 – 5 and have your signal inputs in 6 – 9, you can change the input by pressing the (+10) followed by 81 at any user position. -
Page 13: Specifications
PRO-6000B Series Operating Manual Specifications PRO-6000B Input Output Video Bandwidth 15MHz Video Bandwidth 15MHz Signal Level 1V p-p @ 75 ohm Signal 1V p-p level Balanced Format PAL/SECAM/NTSC Connector RJ45 Connector 9 x RCA Phono Audio Signal 0dB Balanced Auxiliary... -
Page 14: Troubleshooting And Support
PRO-6000B Series Operating Manual Troubleshooting Amber LED is pulsating on the PRO- See user interface connections 6000B And the PRO-6001 No Video / Audio signal at receiver Make sure the appropriate input is selected and that the RCA Phono plug is secure. If server software is in use, ensure the user is not barred. - Page 15 PRO-6000B Series Operating Manual For installations that include Virgin Plus boxes the following alternative codes are installed in the PRO-6000B and the PRO-0201 IR handset. This function exists as the Virgin Plus box uses the same IR codes as the Scion system. If you experience a problem with the Scion handset controlling the channels on the Virgin box please do the following listed below to stop the IR clash.
