EZY-LAN Wireless alarm panel with Ethernet + Wi-Fi + GSM + LTE

1 General

EZY-LAN is an alarm control unit that combines
the best of the latest technologies available with
a pleasant, compact, modern and elegant design.
It manages up to 64 external devices, which can
be divided into a maximum of 8 freely partitionable
sectors.
Up to 32 different users can control the control
unit via App, keyfob or SMS messages. The
double radio section of the latest generation in the
868MHz bidirectional multi-channel band allows
safe, reliable and efficient communication.
EZY-LAN gives its best when connected to the
internet - via Ethernet cable, 2.4GHz Wi-Fi or LTE
data connection - and can be controlled in real
time from the App on any device.
Whether it is a smartphone or a tablet (Apple iOS
and Android), the management and programming
interface is presented in the same form: simple,
intuitive, immediate!
EZY-LAN integrates a video verification function -
usable both with radio photo sensors and with IP
cameras (Dahua, Sunell, Provision) - which
allows you to view within the same App animated
images relating to alarm events or captured at the
request of the user.
EZY-LAN also interfaces with Shelly Wi-Fi
modules for home automation control of lights,
shutters, gate openings, irrigation or other generic
electrical loads powered at 230Vac or 12Vdc.

2 Priority of connections

The channel used by the control panel for
connection to the internet follows a priority logic.
The Ethernet cable is the primary channel that is
used if a network cable is connected.
Wi-Fi (if enabled
alternative channel used when a network cable is
not connected.
The LTE connection with the SIM card (if enabled
in programming) is the channel used when the
Ethernet / Wi-Fi connection is absent or there is
no internet on one of the two connections.
in programming) is
EZY-LAN 23.04-M:2.0-H:3b/4a/4b-F:3.4.3+

3 Identification of the parts

1 – led power
2 – led Ethernet
3 – led Wi-Fi

4 Signals of the luminous ring

The luminous ring visible around the central
button (6), if enabled during the programming
phase, provides information on the status of the
system.
The luminous intensity of the ring (6) is reduced
after 60 seconds of inactivity of the control unit, to
reduce any disturbance at night. Return to
maximum brightness as soon as you perform an
operation on the control unit.
When the control unit is powered only by battery
(no external power supply), in order to reduce
consumption,
periodically.
Luminous ring signals meanings (6)
the
Green
Green / Blue
(blinking)
Green / Red
(blinking)
Red
Orange
Violet (blinking)
White (blinking)
Blue (blinking)
USER MANUAL
FRONTAL VIEW
4 – led GSM + LTE
5 – programmable central button
6 – multicolor led ring
the ring (6) only
Disarmed
Disarmed with door open
Disarmed with alarm memory
Totally armed
Partially armed
Exit time (flashing)
Entry time (flashing)
Alarm in progress
Panel in SETUP mode
Panel in TEST mode
1
2
3
4
5
6
flashes
