CE-LAN
TECHNICAL MANUAL
2.2019
MT: 2.4
H: 1.0+
F: 2.9.3+
WIN: 1.0.7.0+
APP: 1.0.24+
ENG
BEFORE INSTALLING THE SYSTEM READ CAREFULLY ALL THE PARTS OF THIS MANUAL AND KEEP IT CAREFULLY FOR FUTURE
REFERENCE.
THE INSTALLATION OF THE PRODUCT MUST BE CARRIED OUT BY QUALIFIED TECHNICAL PERSONNEL. THE INSTALLER IS
TAKEN TO FOLLOW THE APPLICABLE RULES..
