Scale Menu; Keynote Menu (Roote Note) - Flame CHORD MACHINE 2 Manual

3.4 SCALE MENU

Selecting the MENU:
SCALE P47
press SHIFT + SCALE to select the menu
PENTATONIC
The display shows the currently chosen scale. Turning the DIAL knob will load a new preset- or
user scale. The chosen scale is shown with the transposed root note as saved in the list.
If you want to create your own scale just press the according notes on the keyboard. A scale
exists of a maximum of 12 notes. If you should press more than 12 notes, the highest note will
be deleted automatically. If you want to save your scale press SHIFT + SAVE,
go to the menu SAVE SCALE and save your scale to one of the 16 user defined slots.
The octave range of the mini keyboard can be shifted for four octaves by pressing
SHIFT + OCTAVE & L/R.
Look out! If you should change the respective row of the (cv) playlist - for instance via
the program cv input - the scale of that new row will be loaded and your settings are lost.
3.5 KEYNOTE MENU (Root note)
Selecting the MENU:
KEYNOTE: C
to select press SHIFT + KEYNOTE
TRANSPOSE: +00
The display shows the root note of the current cv playlist's row.
Press a key in order to change the root note or to play live.
You can instantly hear the chord and scale changing.
The lower row shows the value of transposition via the TRANSPOSE CV-input
Look out! If you should change the respective row of the (cv) playlist - for instance via
the program cv input - the root note of the respective (cv playlist) row will be loaded and
your settings are lost.
7
