  • Page 1 FLAME CHORD MACHINE MODULE MANUAL Version 1.00...

  • Page 2: Table Of Contents

    MANUAL FLAME CHORD MACHINE Version 1.00 Content 1. Short description ..............3 2. Hardware / Connections ............3 2.1 Connection to the modular system 2.2 Module overview 3. Functions ................3.1 Mode 3.2 Chord select 3.3 Chord inversions 3.4 Second note (2ndTone) 3.5 Generate chord via CV input (incl.

  • Page 3: Short Description

    1. Short description The module generates maximum four part chords within a range of maximum 9 octaves. To your disposal are 32 chords in 2 banks which can be put additionally into the first or second inver- sion. As a further variation the respective second note of the set chord (CV gate 2) can be trans- posed down about one octave.

  • Page 4: Module Overview

    2.2 Module overview LEDs/button Arpeggiator play mode switch OCT (octaves) switch MODE LEDs/button chord variations LEDs chord bank left/right LEDs chords button <> select chord bank button select chord up/down button OK button/LED/input 2ndTone rotary switch KEYNOTE manually button Step Arpeggio manually LED Step Arpeggio Clock input Step Arpeggio Clock input Arpeggio direction...

  • Page 5: Functions

    3. FUNCTIONS 3.1 Mode Please choose one of the three modes with the switch: MANUALLY: Chords are set manually at the module. In this mode fundamental note, octave, chord and inversion are set manually. A changing of the chord (chord, inversion) is displayed by blinking of the LEDs. The adoption of the new adjusted chord happens with the OK switch.

  • Page 6: Chord Inversions

    3.3 Chord inversions With the push button you can set the inversion of a chord: ROOT: basic position 1st: first inversion 2nd: second inversion ROOT: In basic position the chord starts with the root as low-pitched note on the first CV-output. CV output: 1st: The first inversion transposes the root about one octave up.

  • Page 7: Second Note (2Ndtone)

    3.4 Second note ( 2ndTone) The second note of the chord can be transposed down about one octave. This offers a further chord variation. In contrast to the inversions here at the CV outputs the chord doesn`t remove. 2ndTone CV output: 2ndTone CV output: This affects also the arpeggio: The notes don`t go down equally any more (octave step in...

  • Page 8: Arpeggiator

    4. ARPEGGIATOR 4.1 Clock and playmode The CLOCK sets the notes of the chord serially on the arpeggiator output (depending on the playmode). You can set the clock manually with the key A-CLOCK or automatically with external clock. The playmode is set with the key A-DIR or automatically with clock impulse via A-DIR input. The arpeggiator has four playmodes: UP - LED up on - direction forward (loop=4 steps) DOWN - LED down on - direction backwards (loop=4 steps)

  • Page 9: Scale Mode (Quantizer)

    4.3 Scale mode (Quantizer) The arpeggiator can also work as a quantizer. Then you use the choosen chord as scale. The keynote is determined by the keytone. The scales are limited on the 4 tones of the chord. The scalemode cannot be played manually but gets active starting from a voltage of 5 volt at the CV input "INPUT".

  • Page 10: List Of Chords

    6. List of chords CHORD BANK LEFT NR NAME ROOT 1.INVERSION 2.INVERSION SCALE MAJOR 0,4,7,12 4,7,12,16 7,12,16,19 0,4,7,12 MAJ 6 0,4,7,9 4,7,9,12 7,9,12,16 0,4,7,9 MAJ 7 0,4,7,11 4,7,11,12 7,11,12,16 0,4,7,11 MAJ 7b5 0,4,6,11 4,6,11,12 6,11,12,16 0,4,6,11 MAJ 7#5 0,4,8,11 4,8,11,12 8,11,12,16 0,4,8,11 ADD 2...

  • Page 11: Appendix

    - heat damage caused by overexposure to sunlight or heating - electric damage caused by improper connecting (wrong power supply/ jacks/ MIDI connections/ voltage problems). If you have any complaints please contact your dealer or send an e-mail to: service@flame.fortschritt-musik.de Terms of production conformity: CE, RoHS, UL Disposal The device is produced with RoHS-conformity (subject to the regulations of the European Union) and is free of hazardous substances (like mercury, plumb, cadmium and hexavalent chrome).
