Pulsar DCDC10H Quick Start Manual

•
Power output 1A/12VDC
•
DC power supply range 18÷40V DC
•
Maximum current load 1A
•
high efficiency 87%
•
IP 67 enclosure
1. Technical description.
1.1. General description.
The DCDC converter is used for powering devices that require stabilized voltage of 12V DC. The maximum
current load is 1A (Pmax= 12W). This module does not have galvanic insulation between the input and output
(IN-AUX), and operates on a common ground potential. The unit is protected against short circuit, overload and
overheating.
1.2. Specifications.
Supply voltage
Supply power
Efficiency
Output voltage
Current consumption by converter systems
Output current
Output current t
AMB
Output current t
AMB
Ripple voltage
Overload protection OLP
IP protection class
Operating conditions
Dimensions (LxWxH)
Net/gross weight
Length of DC input cable
Length of DC output cable
Storage temperature
Chart 1.
Relation between output current and ambient
temperature
<30° C
=40° C
DCDC10H
12V/1A/55MM DC/DC converter
Edition: 3 from 03.09.2013
Supersedes edition 2 from 22.07.2013
Features:
•
protections:
•
•
•
warranty – 2 year from the production date
18 ÷40V DC
12W max.
87%
12V DC
10mA max.
1 A
1 A - refer to chart 1.
0,7 A - refer to chart 1.
100mV p-p max.
110% ÷ 150% (@25ºC) of converter Power – current limitation
with the PTC, manual restart (failure requires disconnection of
the DC output circuit)
IP67
o
temperature -10 C÷40
relative humidity 20%...90%
50 x 48 x 25 [mm]
0,10kg / 0,13kg
0,3m
0,5m + plug DC5,5/2,1 female
-20ºC...+60ºC
Fig.1. Mechanical view and dimensions of the converter.
1
overload protection OLP
overheating protection OHP
o
C
EN
