Philco PTF 862 Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
FREEZER
OWNER'S MANUAL
PTF 862

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PTF 862 and is the answer not in the manual?

Questions and answers

Related Manuals for Philco PTF 862

Summary of Contents for Philco PTF 862

  • Page 1 FREEZER OWNER’S MANUAL PTF 862...
  • Page 2 Dear customer, Thank you for buying a PHILCO brand product. So that your appliance serves you well, please read all the instructions in this user’s manual. Copyright © 2019, Fast ČR, a. s. Revision 05/2019...

  • Page 3: Table Of Contents

    CONTENTS PART 1: SAFETY INFORMATION........................3 PART 2: DESCRIPTION OF THE APPLIANCE ....................9 MAIN CONFIGURATION: (OPTIONAL) ............................9 PART 3: UNPACKING YOUR FREEZER ......................12 PART 4: CLEANING BEFORE USE ........................12 PART 5: SPACE REQUIREMENTS ........................12 PART 6: ELECTRICAL REQUIREMENT ......................13 RECOMMENDED EARTHING METHOD ...........................13 PART 7: LEVELING ............................13 PART 8: USE OF THE APPLIANCE ........................14 TEMPERATURE CONTROL (OPTIONAL) ...........................14...
  • Page 4 Dear customer: Thank you for buying this upright freezer. To ensure that you get the best results from your new freezer, please take time to read through the simple instructions in this booklet. Please ensure that the packing material is disposed of in accordance with the current environmental requirements.

  • Page 5: Part 1: Safety Information

    PART 1: SAFETY INFORMATION WARNING: RISK OF FIRE / FLAMMABLE MATERIALS THIS APPLIANCE IS INTENDED TO BE USED IN HOUSEHOLD AND SIMILAR APPLICATIONS SUCH AS STAFF KITCHEN AREAS IN SHOPS, OFFICES AND OTHER WORKING ENVIRONMENTS; FARM HOUSES AND BY CLIENTS IN HOTELS, MOTELS AND OTHER RESIDENTIAL TYPE ENVIRONMENTS;...
  • Page 6 WARNING! KEEP VENTILATION OPENINGS, IN THE APPLIANCE ENCLOSURE OR IN THE BUILT-IN STRUCTURE, CLEAR OF OBSTRUCTION. WARNING! DO NOT USE MECHANICAL DEVICES OR OTHER MEANS TO ACCELERATE THE DEFROSTING PROCESS, OTHER THAN THOSE RECOMMENDED BY THE MANUFACTURER. WARNING! DO NOT DAMAGE THE REFRIGERANT CIRCUIT. WARNING! THE COOLING SYSTEM CONTAINS REFRIGERANT UNDER HIGH PRESSURE.
  • Page 7 WARNING! DO NOT LOCATE MULTIPLE PORTABLE SOCKET- OUTLETS OR PORTABLE POWER SUPPLIES AT THE REAR OF THE APPLIANCE. WARNING! IF THE SUPPLY CABLE GETS DAMAGED, HAVE IT REPLACED BY A SPECIALIZED SERVICE CENTER IN ORDER TO AVOID DANGEROUS SITUATIONS. IT IS PROHIBITED TO USE AN APPLIANCE WITH THE SUPPLY CABLE DAMAGED.
  • Page 8 REFRIGERANT REFRIGERANT AND CYCLOPENTANE FOAMING MATERIAL USED FOR THE REFRIGERATOR ARE FLAMMABLE. THEREFORE, WHEN THE REFRIGERATOR IS SCRAPPED IT SHALL BE KEPT AWAY FROM ANY FIRE SOURCE AND BE RECOVERED BY A SPECIAL RECOVERING COMPANY WITH CORRESPONDING QUALIFICATION OTHER THAN BE DISPOSED BY COMBUSTION, SO AS TO PREVENT DAMAGE TO THE ENVIRONMENT OR ANY OTHER HARM.
  • Page 9 TO AVOID CONTAMINATION OF FOOD, PLEASE RESPECT THE FOLLOWING INSTRUCTIONS: – OPENING THE DOOR FOR LONG PERIODS CAN CAUSE A SIGNIFICANT INCREASE OF THE TEMPERATURE IN THE COMPARTMENTS OF THE APPLIANCE. – CLEAN REGULARLY SURFACES THAT CAN COME IN CONTACT WITH FOOD AND ACCESSIBLE DRAINAGE SYSTEMS.
  • Page 10 THIS APPLIANCE IS INTENDED TO BE USED IN HOUSEHOLDS AND SIMILAR PREMISES, SUCH AS – KITCHENETTES IN SHOPS, OFFICES AND OTHER WORKPLACES; – APPLIANCES USED BY GUESTS IN HOTELS, MOTELS, AND OTHER ACCOMMODATION FACILITIES; – APPLIANCES USED IN BED AND BREAKFAST FACILITIES; –...

  • Page 11: Part 2: Description Of The Appliance

    PART 2: DESCRIPTION OF THE APPLIANCE This type of refrigerator is widely used in places such as hotels ,offices, student dormitories and houses. It is mostly suitable for refrigerating and preserving foods such as fruits and beverage. It enjoys the advantages of small size, Lightweight, Low electric consumption and easy use.
  • Page 12 1 Thermostat 2 Drawer 3 Leveler leg EN - 10 Copyright © 2019, Fast ČR, a. s. Revision 05/2019...
  • Page 13 1 Thermostat 2 Drawer 3 Leveler leg EN - 11 Copyright © 2019, Fast ČR, a. s. Revision 05/2019...

  • Page 14: Part 3: Unpacking Your Freezer

    PART 3: UNPACKING YOUR FREEZER WARNING! Use two or more people to move Freezer. Failure to do so can result in back or other injury. · Remove tape and any labels from your Freezer before using(except the rating label). · To remove any remaining tape or glue, rub the area briskly with your thumb. ·...

  • Page 15: Part 6: Electrical Requirement

    PART 6: ELECTRICAL REQUIREMENT WARNING! DO NOT REMOVE GROUND PRONG. DO NOT USE AN ADAPTOR. DO NOT USE EXTENSION CORD. Failure to follow these instructions can result in death, fire or electrical shock. Before you move your Freezer into its final location, it is important to make sure you have the proper electrical connection.

  • Page 16: Part 8: Use Of The Appliance

    PART 8: USE OF THE APPLIANCE To obtain the best possible results form your Freezer, it is important that you operate it properly. Temperature Control (optional) The temperature in the freezer is controlled by the thermostat control knob. It is loaded in the top-front of the freezer.

  • Page 17: Freezing Fresh Food

    Freezing Fresh Food Ensure that your freezing operations are carried out under the most hygienic conditions as freezing alone does not sterilize the food. It is advisable to freeze the food by packing it into separate meal portions and not in bulk form.

  • Page 18: Part 9: Troubleshooting

    • Do not use soap, detergent, scrub powder, spray cleaner, etc., as these may cause odors in the interior of the refrigerator or contaminated food. • Clean the bottle frame, shelves and drawers with a soft cloth dampened with soapy water or diluted detergent. Dry with a soft cloth or dry naturally. • Wipe the outer surface of the refrigerator with a soft cloth dampened with soapy water, detergent, etc., and then wipe dry. • Do not use hard brushes, clean steel balls, wire brushes, abrasives(such as toothpastes), organic solvents (such as alcohol, acetone, banana oil, etc.), boiling water, acid or alkaline items, which may damage the fridge surface and interior.

  • Page 19: Part 10: Refrigerator Door Install Guidelines

    PART 10: REFRIGERATOR DOOR INSTALL GUIDELINES ABOUT SWAPPING LEFT&RIGHT (OPTIONAL) 1 Disassemeble the screws behind the fixed roof with cross-slot screwdriver and remove the cover from the refrigerator. 2 Remove the screws fixed the top-hinge with cross-slot screwdriver. The screws fixed the top-hinge EN - 17 Copyright ©...
  • Page 20 3 Replace the top-hinge and the door limit block and the door bearing bush to the other side A replace the top-hinge. B replace the door bearing bush and the limit block. EN - 18 Copyright © 2019, Fast ČR, a. s. Revision 05/2019...
  • Page 21 4 Disassemble the screws fixed the bottom-hinge with cross-slot screwdriver and replace the hinge to the other side then fix it with screws. NOTE! The refrigerator incline angle less 45°. The screws fixed the bottom-hinge 5 replace the leveler to the other side and adjust it to make sure the cabinet level. EN - 19 Copyright ©...
  • Page 22 6 Set the door right position,fix the top-hinge and then the roof cover. Ensure the Appliance is unplugged and empty. Adjust the two leveling feet to their highest position. We recommend you have someone to assist you. NOTE! To take the door off it is necessary to tilt the Appliance backward. You should rest the Appliance on something solid e.g.a chair just below the top panel.

  • Page 23: Energy Saving Tips

    Energy Saving Tips • The appliance should be located in the coolest area of the room, away from heat producing appliances or heating ducts, and out of the direct sunlight. • Let hot foods cool to room temperature before placing in the appliance. Overloading the appliance forces the compressor to run longer. Foods that freeze too slowly may lose quality, or spoil. • Be sure to wrap foods properly, and wipe containers dry before placing them in the appliance. This cuts down on frost build-up inside the appliance. • Appliance storage bin should not be lined with aluminum foil, wax paper, or paper toweling. Liners interfere with cold air circulation, making the appliance less efficient.

  • Page 24: Part 11: Information Sheet

    PART 11: INFORMATION SHEET INFORMATION SHEET: Philco Philco brand: Brand Philco Product number PTF 862 Type of appliance Energy efficiency class (A… low electricity consumption to G… high electricity consumption) Energy consumption over a 365 day period (kWh) Total available volume (l)
  • Page 25 INSTRUCTIONS AND INFORMATION REGARDING THE DISPOSAL OF USED PACKAGING MATERIALS Dispose of packaging material at a public waste disposal site. DISPOSAL OF USED ELECTRICAL AND ELECTRONIC APPLIANCES The meaning of the symbol on the product, its accessory or packaging indicates that this product shall not be treated as household waste.
  • Page 27 Manufacturer/Importer: Fast ČR, a.s. Praha 10, Černokostelecká 2111 CZ-10000; CZECH REPUBLIC is a registered trademark used under license from HU - 24 Electrolux Home Products., Inc. Copyright © 2019, Fast ČR, a. s. Ellenőrzés 05/2019...
