BATTLE DEN GAMING BUNK BED
I MPORTANT - READ CAREFULLY - RETAIN FOR FUTURE REFERENCE
Dimensions
Width -197.5cm
Depth - 96cm
Height - 183cm
Please assemble in the same room where the product will be used
IMPORTANT: You must keep your original retail receipt as proof of purchase.
SXJ02-20220207
2 Person assembly
recommended
Need Help ? Contact X Rocker at :
www.xrockeruk.com/pages/support
2020118
1
Advertisement
Related Manuals for XROCKER BATTLE DEN GAMING BUNK BED
Summary of Contents for XROCKER BATTLE DEN GAMING BUNK BED
- Page 1 BATTLE DEN GAMING BUNK BED I MPORTANT - READ CAREFULLY - RETAIN FOR FUTURE REFERENCE 2 Person assembly Dimensions recommended Width -197.5cm Depth - 96cm Height - 183cm Please assemble in the same room where the product will be used Need Help ? Contact X Rocker at : www.xrockeruk.com/pages/support...
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly Check you have all the Assemble on a soft level Make sure you have enough components and tools listed on surface to avoid damaging the space to layout the parts before the following pages.
- Page 3 Safety and Care Advice Important - Please read these instructions fully before starting assembly WARNING THE MATTRESS SURFACE LEVEL SHOULD 160MM NOT BE ABOVE THIS LINE Important: Please note the maximun mattress height is indicated on the vertical bar on the left hand side of the opening at the top of the ladder.
- Page 4 PARTS 14 a...
- Page 5 Panels Post 01 x 1 Post 02 x 1 Post 03 x 1 Post 04 x 1 Rear Guard Rail x 1 Front Guard Rail x 1 End Guard Rail x 2 Shelf x 1...
- Page 6 Panels Rear Mesh Panel 01 x 2 Rear Mesh Panel 02 x 2 Front Mesh Panel 02 x 1 Front Mesh Panel 01 x 4 Side Mesh Panel x 8 Support Post 01 x 1 Support Post 02 x 1 Ladder x 1...
- Page 7 Panels Shelf Support Rail 02 x 1 Shelf Support Rail 01 x 1 TV Mount x 1 1 4a Slats x 24 Shelf Support Rail 03 x 2 Cable Cap x 1 Plastic Plug x 48 Bracket x 4 Slat Spacer x 23...
- Page 8 Fittings M6 Metal Washer x 8 45mm M6 Bolt x 5 30mm M6 Bolt x 21 M6 Plastic Washer x 8 4MM Allen Key x 1 25mm M6 Bolt x 79 Wrench x 1 17mm M6 Bolt x 15 M4 Metal Washer x 4 M6 Nut x 6 M6 Spring Washer x 8...
- Page 15 Twist the X cover to open the cable grommet. Then pass cables through the desktop as desired. Then reassemble the X cover and twist to close the cable grommet again...
- Page 16 The edgefolds on mesh panels should be towards inside of bed.
- Page 17 The edgefolds on mesh panels should be towards inside of bed.
- Page 18 14.2 14.1 The edgefolds on mesh panels should be towards inside of bed.
- Page 19 15.2 15.1 The edgefolds on mesh panels should be towards outside of bed.
- Page 20 1 4a 1 4a 1 4a 17.2 17.1...
- Page 21 1 4a 1 4a 1 4a 14 a 1 4a...
- Page 22 Assembly is complete Note: The TV mount mates with M6 screw. If you're using M4 screw to assemble the TV screen, please use part M washer as provided to make sure M4 screw could be also workable for it. 100%...
